Technical Specifications
Power supply
18 ... 28VDC
typ. 45mW, max. 2.6W
Power consumption
Power loss
max. 2.6W
Loxone Tree:
Interface
Connection with Miniserver /
Tree Extension
Ambient temperature
-40 ... 55°C / -40 ... 131°F
Humidity
max. 95% r.H. (non condensing)
Acoustic
Alarm
93dB / 1m
83.5dB / 3m
optical:
flashing red light
Yes
Tamper detection
Safety rating
IP44
Dimensions
250x150x65mm /
9.84x5.91x2.56" (LxWxH)
This device is free of
Maintenance & Cleaning
maintenance and may only be
cleaned with a dry cloth.
Need Help?
loxone.com/support
Loxone Electronics GmbH
Smart Home 1
4154 Kollerschlag
Austria
loxone.com
Alarm
Siren
Tree
Part No: 100313
Advertisement
Related Manuals for LOXONE Alarm Siren Tree
Summary of Contents for LOXONE Alarm Siren Tree
- Page 1 Tamper detection Safety rating IP44 Tree Dimensions 250x150x65mm / 9.84x5.91x2.56” (LxWxH) Loxone Electronics GmbH This device is free of Maintenance & Cleaning Smart Home 1 maintenance and may only be 4154 Kollerschlag cleaned with a dry cloth. Part No: 100313 Austria loxone.com...
- Page 2 About the product Connection 1st) The Alarm Siren Tree with strobe light serves as an external clasp into warning device, for example, as part of the burglar alarm. housing and Wire cross-section When triggered, the device gives out an acoustic and optical 0.4 …...
