TD-W8960N Wireless N ADSL2+ Modem Router User Guide
4.4.9.3 RIP
Choose "Advanced Setup" "Routing" "RIP", you can see the RIP (Routing Information
Protocol) screen which allows you to configure the RIP (shown in Figure 4-51).
Figure 4-51
Note:
RIP cannot be configured on the WAN Interface which has NAT enabled (such as PPPoE).
To activate RIP for the device, configure an individual interface, select the desired RIP version and
operation, and select Enabled checkbox for the interface.
Click Save/Apply to save the configuration.

4.4.10 DNS

When you select the connection type PPPoE, PPPoA or IPoA for WAN configuration, you will see
the DNS menu in the Web-based Utility (shown in Figure 4-52). It includes DNS Server and
Dynamic DNS submenus.
Figure 4-52
4.4.10.1 DNS Server
Choose "Advanced Setup" "DNS" "DNS Server". You can see the DNS Server Configuration
screen, this screen allows you to configure the DNS Server Addresses (shown in Figure 4-53).
49
