Simple Table
Adjustable Table Frame
Kit Instructions
61-7
External Leg Pipes
10-6
133-6
Basic Installation Instructions
1.
Confirm that you have all the required parts.
2.
Assemble the parts according to the enclosed diagram.
3.
When you initially assemble the unit loosely tighten the fitting set screws. After
the unit is completely assembled, fully tighten all set screws.
4.
If installing plugs, place cloth over plug and hammer into place.
Troubleshooting
If the table seems wobbly, loosen the set screws and adjust the pipes until the table
is stable.
Depth Pipe
Width Pipe
Internal Leg Pipes
Parts
Standard Table Parts
Qty Part
4 61-7 Flanges
6 10-6 Single Socket Tees
4 133-6 Plastic Plugs
4 External Leg Pipes
4 Internal Leg Pipes
2 Depth Pipes
1 Width Pipe
Tools
• Allen Key (included)
• Hammer (for plugs)
• Screw Driver
• Level
Page 1
