- Page 1 v 1.0 OWNERS MANUAL & ASSEMBLY INSTRUCTIONS COCKTAIL TABLE 151-082-205 151-082-305...
- Page 2 WARNING WARNING! • Read these Warnings fully before use. • Do not sit, stand or jump on this item. • This item is designed for indoor use alone. • To avoid dangers of suffocation, ensure all polythene bags, wrapping materials, and parts that come with this item are kept out of reach and carefully disposed of.
- Page 3 PARTS PARTS LIST HARDWARE LIST DESCRIPTION DESCRIPTION JCBC BOLT - M6 x 35MM 16 PCS TABLE TOP 1 PC 2 PCS JCBC BOLT - M6 x 60MM 2 PCS TABLE LEG 2 PCS SPRING WASHER - M6 x 13MM MOUNTING PLATE 18 PCS 1 PC 4 PCS...
- Page 4 ASSEMBLY INSTRUCTIONS STEP 1 Place table top (A) face down on a down a clean and soft surface to prevent from being scratched. Remove mounting plate (C) from table top (A) Ponga la mesa (A) boca abajo en una superficie limpia y suave para que no se raye.
- Page 5 ASSEMBLY INSTRUCTIONS STEP 2 Assemble leg (B) to Mounting Plate (C) with bolts (F), Washer (H) and allen wrench (J). Una la pata (B) a la Placa de Montaje (C) con los Tornillos (F) y Arandelas (H) usando la Lave Allen (J). Assembler le pied (B) à...
- Page 6 ASSEMBLY INSTRUCTIONS STEP 3 Insert wood dowel (I) to the cross bar (D). Assemble table leg (B) with cross bar (D) together with bolt (G), spring washer (H) by using Allen wrench (J). Inserte la Clavija de Madera (I) en el Travesaño (D). Una la Pata de la Mesa (B) y el Travesaño (D) con los Tornillos (G) y Arandelas de Resorte (H) usando la Llave Allen (J).
- Page 7 ASSEMBLY INSTRUCTIONS STEP 4 Place table top (A) face down on a clean and soft surface to prevent from being scratched. Assembly table leg (B) with mounting place (C) to table top (A) use bolt (F) and spring washer (H) by using Allen Key (J). Install stopper (E) to legs (B). Ponga la mesa (A) boca abajo en una superficie limpia y suave para que no se raye.
- Page 8 MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE OR USE, ARE EXCLUDED AND DISCLAIMED. This Limited Warranty is made exclusively by Classic Brands and is not made on behalf of its distributors or any other party and no one is authorized to assume or undertake for Classic Brands any other liability in connection with the sale of the product. Some jurisdictions do not allow for the disclaimers of implied warranties or the exclusion of limitation of incidental or consequential damages, so the above limitations may not apply to you.
