Liquid Instruments Moku:Lab Quick Start Manual

Moku:Lab
Quick start guide
Moku:Lab layout
Power button / status LED
Analog inputs
Powering on & off
Connect the power supply to the DC power port
1
on the rear of the Moku:Lab.
Press and hold the power button for two seconds
2
until the status LED turns orange.
Wait for the status LED to turn blue / white.
3
To turn your Moku:Lab off, press and hold the
X
power button for two seconds until the status
LED turns orange.
Connecting to your Moku:Lab
Ethernet
You can connect to your Moku:Lab using a wired
network connection. A wireless Access Point is
required in order to use the iPad.
Connect an Ethernet cable from your router to
1
the Ethernet port on the rear of the Moku:Lab.
Open the iPad's Settings app and select "Wi-Fi"
2
from the panel on the left and connect to an
Access Point on the same network.
©2018 Liquid Instruments
Analog outputs
DC power 10 MHz ref. output
SD card slot
Micro-USB data port
Ethernet port
Powered off Initializing /
Powering down
Wi-Fi
You can connect to your Moku:Lab using a wired
network connection. A wireless Access Point is
required in order to use the iPad.
Open the iPad's Settings app and select "Wi-Fi"
1
from the panel on the left.
Select the network called "Moku-#####", where
2
"#####" is your Moku:Lab's 5-digit serial number
printed on the bottom of the case. The default
password is "mokuadmin".
Kensington Lock slot
10 MHz ref. input
External trigger input
USB charge port
Powered on
1
