Summary of Contents for trendmedic TM-8500 Premium
-
Page 2: Table Of Contents
TABLE OF CONTENTS Introduction---------------------------------------------------------------------------------------- 1 Correct Measurement--------------------------------------------------------------------------- 1 Description of Parts------------------------------------------------------------------------------ 1 Power Supply-------------------------------------------------------------------------------------- 2 Operation------------------------------------------------------------------------------------------- 2 Accessories---------------------------------------------------------------------------------------- 4 Error and Troubles------------------------------------------------------------------------------- 4 Important Notes----------------------------------------------------------------------------------- 5 Specifications-------------------------------------------------------------------------------------- 5 Calibration and Record--------------------------------------------------------------------------6 Precautions-----------------------------------------------------------------------------------------6 Warranty---------------------------------------------------------------------------------------------7 Introduction The device is intended to measure alcohol in the human breath. Measurements obtained by this device are used in the diagnosis of alcohol intoxication. -
Page 3: Correct Measurement
0.20, 0.50 and 0.80‰ BAC. Preparation for Correct Measurement • Before testing, wait at least 15 minutes after your last drinking. Only use the device in a temperature10° C ~ 40° C or 50° F ~ 104° F. Description of parts Power Supply •... -
Page 4: Operation
• If the power is too low, the unit may display a battery symbol “ “and the device may not use correctly. You need to change a new battery. Operation (Test mode) • Insert one of the mouthpieces into the ‘blow in’ hole. •... - Page 5 • The BLOW displays on the screen, and displays “C” with flashing. Take a deep breath, blowing steady into the mouthpiece until beeping stops (about 6 seconds). • The device displays “WAIT” and flashing the “0” on the screen. • Your test result will be displayed on the screen for 20 seconds. •...
-
Page 6: Accessories
(Memory Recall) • After tested, the device displays the reading for 20 seconds. You press the memory button to check your last 5 tested records. • The device will be turn off after displaying 20 seconds. The memory button is only used at this mode. Accessories •... -
Page 7: Error And Troubles
Errors or Troubles Error Description Remarks message or Troubles -Press and hold the TEST button until power on. No display -Check the battery -Low battery Auto Off -Over the period of test stage -Blowing unsteady or interrupt -Blowing less than 6 seconds -Blowing flow too weak -No blow during BLOW mode. -
Page 8: Calibration And Record
Show “HI” if above the display range Accuracy: +/-0.05‰ at 0.50‰ Memory: 5 last records 5 mouthpieces included Warm up time: 10 seconds Testing Time: 10 seconds Repeat test: less than 60 seconds. Audible sound and change LCD color if above alarm point Selective alarm point for 0.02%, 0.05%(0.50‰;... -
Page 9: Precautions
The completed RMA form and description of the problem. b. Your name, return address (Not PO Box) c. Your phone number. d. A copy of your sales receipt or invoice. Manufactured for: Trendmedic Eric Schäfer Beethovenstr. 5 D-85622 Feldkirchen, Germany E-Mail: info@trendmedic.de Web: www.trendmedic.de AT571-110707-01...
