Page 2: Table Of Contents
TABLE OF CONTENTS Introduction-----------------------------------------------------------------------------------------1 Correct Measurement----------------------------------------------------------------------------1 Description of Parts-------------------------------------------------------------------------------1 Power Supply-------------------------------------------------------------------------------------- 2 Operation and Setup----------------------------------------------------------------------------- 2 Accessories-----------------------------------------------------------------------------------------6 Error and Troubles--------------------------------------------------------------------------------6 Important Notes------------------------------------------------------------------------------------7 Specifications---------------------------------------------------------------------------------------7 Calibration and Record---------------------------------------------------------------------------8 Precautions------------------------------------------------------------------------------------------9 Warranty----------------------------------------------------------------------------------------------9... -
Page 3: Introduction
Introduction The device is intended to measure alcohol in the human breath. Measurements obtained by this device are used in the diagnosis of alcohol intoxication. Preparation for Correct Measurement • Before testing, wait at least 15 minutes after your last drinking. •... -
Page 4: Power Supply
Power Supply • Slide back the battery cover on the back of the device. • Insert 1 piece 9V battery, making sure that the “+/-“symbols are correctly. • If the power is too low, the unit may display a battery symbol “ “and the device may not use correctly. - Page 5 • The WAIT displays on the screen and countdown 15, 14, and 13… to zero. • The BLOW displays on the screen, and displays “C” with flashing. Take a deep breath, blowing steady into the mouthpiece until beeping stops (about 6 seconds). •...
- Page 6 • It will show error when incorrect blowing. Refer to the chapter of the “Errors and Troubles” in detail. The device will be turned off after indicated error. (Setup Date/time) • Press SET button for 2 seconds to enter the SETUP mode. •...
-
Page 7: Accessories
• Press SET to go to next stage. (Print) • Connect the specific portable printer to the unit. • Press PRINT button 2 seconds to print the last record. Accessories • Mouthpieces • Carrying pouch (option) Errors or Troubles Error message Description Remarks or Troubles... -
Page 8: Important Notes
Auto Off -Low battery -Over the period of test stage -Blowing unsteady or interrupt -Blowing less than 6 seconds -Blowing flow too weak -No blow during BLOW mode. -Change temperature suddenly -Low battery indication -Need to change new battery -Use alkaline battery -Blowing mode Alarm sound -Error message indication... -
Page 9: Calibration And Record
• Blowing time: 6 seconds • Blowing flow: 10L/min • Display range: 0.000-2.000‰BAC • Show “HI” if above the display range • Accuracy: +/-0.05‰BAC at 0.50‰BAC • Memory: 10 records (no download) • 5 mouthpieces included • Warm up time: 15 seconds •... -
Page 10: Precautions
Precautions • Your blood alcohol content (BAC) may change some minutes later. • You should have your alcohol tester calibrated every 12 months. Failure to do so may cause your readings to be inaccurate. • Do not use this device to determine if you can drive. •... - Page 11 If a defect arises and we receives a valid claim within the Warranty Period, at its option, we will either (1) Repair the unit, (2) Exchange the unit, which is new or used functionally equivalent to the original unit, (3) Refund the purchase price of the unit. For warranty service please follow these instructions: 1.
