- Page 1 SQUID CAST USER MANUAL v 1.8...
- Page 2 Congratulations on purchasing the Squid from Spot X Underwater Vision. The Squid is the world’s most flexible, live underwater camera system, enabling you to get the most out of your GoPro Hero or Garmin Virb. We think you’ll find the Squid an invaluable accessory for your camera if you work or play on the water.
- Page 3 What will we do to correct problems? Spot X Underwater Vision will either repair the product at no charge, or replace the product at no charge. How long does the coverage last? The Warranty Period for Physical Goods purchased from Spot X Underwater Vision is one year from the date of purchase.
-
Page 4: Table Of Contents
CONTENTS Setup.........................1 General Setup....................1 Squid Modes.....................7 Drift mode.....................7 Trolling Mode....................10 Deployment.....................11 O-ring Care......................12 Safety and General Care..................13 Troubleshooting....................14 Get in Touch!....................14... -
Page 5: Setup
SETUP The setup described below is applicable for GoPro Hero 3-7 cameras, as well as Garmin Virb Ultra 30, with some minor difference noted throughout. As with any underwater equipment, it is advisable to test the system prior to full immersion. Therefore, for first time users, we recommend you skip to Step 9, and install the o-ring and lens and test the Squid in a shallow tub of water prior to installing the camera. - Page 6 3. For GoPro 3 and 3+ users, a battery must be installed. For GoPro Hero 4/5/6/7 and Garmin Virb Ultra 30 users, please remove the battery from your camera. 4. Attach your camera to the tray using the supplied strap (Figure 1). Slide the tray partially into the Squid housing.
- Page 7 FIGURE 2 7. Connect the DC power socket on the topside box (Figure 3) to the cigarette lighter-style lead (Figure 4) and plug into a 12 volt DC power source (if you do not use the supplied lead, please ensure any lead you use includes a 3 amp fuse.
- Page 8 Connect or Garmin Virb apps. Note: GoPro Hero 6/7 Black users- the 2.4GHz WiFi band must be used when using the Squid Cast. You can select this by swiping down, tap Connections>WiFi band >2.4GHz 9. Lightly grease one o-ring with the supplied silicone grease. Install into the rearmost o-ring groove, marked in green on the diagram (Figure 5-note, your unit may be supplied with o-ring preinstalled).
- Page 9 FIGURE 5 10. Lightly grease the inside of the Squid lens where the lens will mate with the o-ring; this will ensure a smooth installation. Attach the Squid lens and screw clockwise as far as possible so that the lens meets the body of the Squid.
- Page 10 Depending on your device, the antenna may need to be touching the device (Figure 6). Use the WiFi strength indicator within the app (or use a separate WiFi signal strength app) to find the best position. Once you find the ideal location, you can secure the antenna if required with velcro or similar.
-
Page 11: Squid Modes
SQUID MODES The Squid can operate in two modes: 1. Drift mode 2. Trolling mode For both modes, a kevlar cable grip is affixed to the cable 100 cm from the end of the Squid housing to aid rigging. Drift mode Drift mode sets the camera to look forward and can be used at slow speeds. - Page 12 FIGURE 8 Before deployment, a tethering system must be installed to reduce strain on the cable connections. Using the supplied nut and bolt, attach the supplied short tether (Figure 7) at the appropriate Squid hole for desired viewing angle. Hole 1 (closest to lens) will give you an upwards view, hole 4 (closest to cable) will give you a slightly downwards view.
- Page 13 FIGURE 9 This setup is designed to maintain the integrity of your cable; the drop tether keeps a proper bend radius and reduces strain on the cable connections; the tow line reduces heaving strain on the cable by dispersing the force over the entire length of the cable.
-
Page 14: Trolling Mode
Trolling Mode Trolling mode is used to tow the Squid close to the surface of the water, looking backwards to view surface lures. In this mode, the top stabiliser wing (Figure 10) should be affixed with the shoulder bolt using the supplied 3/32” Allen key (note, this is a different size to the 2.5 mm size supplied for the countersunk bolts). -
Page 15: Deployment
This will reduce bowing of the cable, minimising drag and improving trolling performance. If you do this, be sure to place regular knotted loops along the tow line to place over cleats etc to secure the unit during towing. For towing deeper than 2 metres we recommend you replace the Squid keel with a small downrigger bomb (eg 5 lbs). -
Page 16: O-Ring Care
O-RING CARE O-rings compress under pressure to create a strong watertight seal. It is very important that o-rings are inspected prior to each use to ensure: o-rings are clean and free of grit, salt, hair or other contaminants; o-rings are undamaged without any nicks, cuts or wear;... -
Page 17: Safety And General Care
SAFETY AND GENERAL CARE For your safety and care of your camera system: Do not leave the lens sealed on the Squid for any longer than the days use, otherwise it becomes very difficult to remove. Ensure that the topside box, power source and Squid internals remain dry at all times. -
Page 18: Troubleshooting
Ensure camera LEDs are switched off Use included black silicone camera case to mask the GoPro GET IN TOUCH! If you have any queries about your Squid or want to connect with other Squid users: spotx_ info@spotx.com.au spotx_ Spot X Underwater Vision...
