mikroElektronika Click Boards IR distance click Manual page 2

5. Schematic
VCC
C3
100nF
PWR SEL2A
R2 R3 R4
10 10 36K
6. Dimensions
42.9 mm / 1690 mils
VCC
S1
1 20
2 19
3 18
4 17
VOUT
5 16
6 15
EN
7 14
8 13
9 12
10 11
GP2Y0A60SZ0F
C2 C4
100nF 100nF
mm mils
42.9 1690
LENGTH
25.4 1000
WIDTH
3.9 154
HEIGHT*
* without headers
VCC VCC-3.3V
R5
10K
VOUT
AN PWM
EN
RST INT
CS TX
SCK RX
SCL
MISO
C7
C5 MOSI SDA
100nF
10nF +3.3V +5V
GND GND
MIKROBUS_DEVICE_CONN.
C6
1uF
VCC VCC-5V
R1
1K
C1 E1
100nF 10uF
PWR
7. SMD jumpers
IR distance click features an SMD jumper
(zero ohm resistor) that let's you switch
between a 3.3V or a 5V power supply.
8. Code examples
Once you have done all the necessary
preparations, it's time to get your click board
VCC-5V
up and running. We have provided examples
for mikroC
compilers on our Libstock website. Just
download them and you are ready to start.
9. Support
VCC-3.3V
MikroElektronika offers free tech support
(www.mikroe.com/support) until the end of
the product's lifetime, so if something goes
wrong, we're ready and willing to help!
PWR SEL1A
10. Disclaimer
MikroElektronika assumes no responsibility
or liability for any errors or inaccuracies
that may appear in the present document.
Specification and information contained in
the present schematic are subject to change
at any time without notice.
Copyright © 2015 MikroElektronika.
All rights reserved.
™
