- Page 1 Sherpa Power Barrow Safety & Operating Instructions Model: SPB-500 Read and understand this manual and all instructions before operating this wheelbarrow! Sherpa Tools | SPB-500 | 2018...
-
Page 2: Product Specifications
SPB-500 Safety & Operating Instructions Product Specifications Max. speed: 3.5km/h Max. load: 120kg Motor: Carbon brush motor 230W / 50 min Brake: D180mm Adjustable disk brake Structure: Low carbon steel Surface coating: Powder coating ... -
Page 3: Components List
SPB-500 Safety & Operating Instructions Components List Before assembling theSPB-500 Electric Wheelbarrow, check that you have all the following module and parts available: 1. Tray x 1 2. Tray rack x 1 3. Base module (front wheel, handle, brake, and speed controller) x 1 4. - Page 4 SPB-500 Safety & Operating Instructions Assembling the SPB-500 Wheelbarrow Please read and follow the following instructions carefully. This procedure will guide you through the correct steps to assemble your wheel barrow and ensure safe use. Step 0: The first charge of the battery will take between 8 to 24 hours, we recommend that you start charging before assembling the wheelbarrow.
- Page 5 SPB-500 Safety & Operating Instructions Figure 6 Figure 5 Step 3: Now turn the handle into the correct orientation. Insert the tubes on both sides. Use hex bolts and nuts (Figure 7) for fastening (Figure 8). Your wheelbarrow should now look like Figure 9.
- Page 6 SPB-500 Safety & Operating Instructions Step 5: Fix the dangling wire of the speed controller on the handle tube with the tightening bend that has been pre-assembled to the tube. Figure 11 Step 6: At this point, you should make sure the wires are correctly tightened at the 5 locations circled in Figure 12.
- Page 7 SPB-500 Safety & Operating Instructions Figure 14 Figure 13 Figure 15-1 Figure 15-2 Figure 15-3 Step 8: Obtain the tray and 4 sets of bolts and nuts (Figure 16-1), fasten it to the tray rack like it is shown in Figure 16-2.
-
Page 8: Installing The Battery
SPB-500 Safety & Operating Instructions Congratulations! Now your SPB-500 has been completely assembled! Installing the Battery Step 1: Depress the brake stopper on the hand brake to stop the wheelbarrow without having to hold it (Figure 18). Stand at the side and lift the tray up (Figure 19). Please make sure there is no person in front of the barrow. - Page 9 SPB-500 Safety & Operating Instructions Step 3: Simply lift the brake slightly to de-activate the brake stopper (Figure 21). Figure 21 Operating the Wheelbarrow Starting the Wheelbarrow Switch on the power by pressing the power button. A red LED light lights up and indicates that you are ready to go (Figure 22).
- Page 10 SPB-500 Safety & Operating Instructions Stopping the Wheelbarrow Simply lift the brake handle to brake the wheelbarrow (Figure 21). Please refer to the “Install the Battery” section on how to stop the wheelbarrow using the stopper when you are on a slope or any other situations where you need to stop the wheelbarrow and be away.
-
Page 11: Charging And Caring For The Battery
SPB-500 Safety & Operating Instructions Charging and Caring for the Battery The SPB-500 comes with a sealed, lead acid battery installed. The battery is 24 volts and rated at 10 amp-hours. The battery is completely maintenance free. You should charge the battery before first use and after every use. The battery should also be charged out of the wheelbarrow to ensure safety. - Page 12 SPB-500 Safety & Operating Instructions Maintaining the Wheelbarrow Battery MUST BE REMOVED before any maintenance can be carried out! Lubricating the wheels We recommend you to lubricate the wheels every 100 hours of use. This is to ensure smooth operation of the Wheelbarrow.
- Page 13 SPB-500 Safety & Operating Instructions 2-Year Limited Warranty SPB-500has a two (2) year warranty from the date of purchase. This also covers wearing parts against defects in materials or workmanship when put to domestic use. The battery has a one (1) year limited warranty only.
- Page 14 SPB-500 Safety & Operating Instructions Sherpa SPB-500 Wheelbarrow is in compliance with the specification of the machine directive and subsequent modifications, 98/37/EC Sherpa Tools Magic House Station Road North Hykeham Lincoln LN6 9AL TEL: 01522 283 020 www.sherpatools.co.uk Sherpa Tools | SPB-500 |...
