- Page 1 ETHERLINE ACCESS SWITCH Hardware Installation Manual ETHERLINE ACCESS M06T-2GEN M08T-2GEN M08T02SFP M08T02GSFP V1.0, December 2019 For more information please visit: https://www.lappkabel.com/activenetworkcomponents...
- Page 2 ETHERLINE ACCESS M06T-2GEN/M08T-2GEN/M08T02SFP/M08T02GSFP Hardware Installation Manual Disclaimer: U.I. Lapp GmbH tries to keep the content of this manual as accurate and as updated as possible. This document is not guaranteed to be error-free, and we reserve the right to amend it without notice to users.
- Page 3 Please keep the manual for further reference. If the equipment is used in a manner not specified in this manual, the protection provided by the equipment may be impaired. LAPP is not liable to any personal or equipment damage caused by violation of this notice.
- Page 4 Dispose of the device in accordance with relevant national provisions, preventing environmental pollution. In the following cases, please immediately shut down your power supply and contact your LAPP representative: Water gets into the equipment. Equipment damage or shell damage.
-
Page 5: Table Of Contents
Contents 1 Product Overview .......................2 2 Structure and Interface .......................3 2.1 Front Panel ........................3 2.2 Top Panel ........................5 3 Mounting ..........................5 3.1 Dimension Drawing ......................5 3.2 Mounting ........................6 3.2.1 DIN-Rail Mounting ....................6 3.2.2 DIN-Rail Dismounting ....................7 4 Connection .........................7 4.1 10/100Base-T(X) Ethernet Port ..................7 4.2 100/1000Base-X SFP Slot ...................9 4.3 Console Port ...................... -
Page 6: Product Overview
PIS, petroleum and petrochemical, intelligent transportation and many other industries. The ETHERLINE ACCESS M06T-2GEN/M08T-2GEN/M08T02SFP/M08T02GSFP, with wide operating temperature of -40℃ to 75℃, IP40 rated metal housing and reset button for one- touch recovery, supports DT-Ring (recovery time<50ms), DRP/DHP (recovery time<20ms),... -
Page 7: Structure And Interface
2 Structure and Interface 2.1 Front Panel ETHERLINE ACCESS M08T-2GEN ETHERLINE ACCESS M06T-2GEN Figure 1 Front Panels of M08T-2GEN and M06T-2GEN (1) Power 1 LED (2) Power 2 LED (3) Running LED (4) Ring LED (5) Alarm LED (6) Reset button... - Page 8 ETHERLINE ACCESS M08T02GSFP ETHERLINE ACCESS M08T02SFP Figure 2 Front Panels of M08T02GSFP and M08T02SFP (1) Power 1 LED (2) Power 2 LED (3) Running LED (4) Ring LED (5) Alarm LED (6) Reset button (7) 10/100Base-T(X) Ethernet Port (8) Speed LED of 10/100Base-T(X) Ethernet port (yellow) (9) Link/ACT LED of 10/100Base-T(X) Ethernet Port (green) (10) Link/ACT LED of 1000Base-X SFP slot (11) Speed LED of 1000Base-X SFP slot...
-
Page 9: Top Panel
2.2 Top Panel Figure 3 Top Panel 3 Mounting 3.1 Dimension Drawing Figure 4 Dimensions (unit: mm) Caution: As part of the heat dissipation system, the housing of the switch becomes hot while working. Please do not touch or cover the housing while the switch is working. -
Page 10: Mounting
3.2 Mounting The device supports DIN-rail mounting. Mounting Environment: 1) The temperature, humidity and power supply is within the allowable range. 2) No direct sunlight, distant from heat source and areas without strong electromagnetic interference. 3) The switches are open type equipment for indoor use. 4) The switches are intended for use in a Pollution Degree 2 industrial environment 5) The switches are recommended to be mounted in an enclosure that provides a minimum protection rating of IP54. -
Page 11: Din-Rail Dismounting
3.2.2 DIN-Rail Dismounting Step 1: Use a screwdriver to release the spring locking piece at the bottom of the connecting seat by following the arrow 1 on Figure 6. Step 2: Move the device in arrow 2 until the bottom of the device is detached from the DIN rail. - Page 12 Pin Definition Figure 7 RJ45 Port Table 1 Pin Definitions of 10/100Base-T(X) Ethernet Port MDI-X Signal MDI Signal Receive Data+ (RD+) Transmit Data+ (TD+) Receive Data- (RD-) Transmit Data- (TD-) Transmit Data+ (TD+) Receive Data+ (RD+) Transmit Data- (TD-) Receive Data- (RD-) 4, 5, 7, 8 Unused...
-
Page 13: 100/1000Base-X Sfp Slot
Note： The color of the cable for RJ45 connector meets the 568B standard: 1-orange and white, 2- orange, 3-green and white, 4-blue, 5-blue and white, 6-green, 7-brown and white, and 8-brown. 4.2 100/1000Base-X SFP Slot In the front panel of ETHERLINE ACCESS M08T02SFP and ETHERLINE ACCESS M08T02GSFP, there are two SFP slots, which respectively accept 100Base-X SFP optical transceiver and 1000Base-X SFP optical module, as shown in Figure 9. -
Page 14: Console Port
Figure 11 Connecting the SFP Optical Module Note： The switch supports DDM (Digital Diagnostic Monitor) function which need to be used together with the SFP optical module that also supports DDM function. Caution: The device uses laser to transmit signals in fibers. The laser meets the requirements of level 1 laser products. -
Page 15: Grounding
A DB9-RJ45 Console cable is provided together with the switch as shown in Figure 13. One end of the cable is a DB9 connector to be inserted into the 9-pin serial port of a PC, and the other end is a crimped RJ45 connector to be inserted into the console port of the switch. Figure 13 Wiring Sequence of DB9-RJ45 Console Cable Table 2 Pin Definitions of DB9 Port (9-Pin Serial Port) and RJ45 Port (Console Port) DB9 Port (9-Pin Serial Port) -
Page 16: Power Terminal Block
Note： Cross-sectional area of the chassis grounding cable>2.5mm ; grounding resistance<5; torque range is from 0.76Nm to 0.83Nm. 4.5 Power Terminal Block There is a power terminal block on the top panel of the device. You need to connect the power wires to the terminal block to provide power for the device. -
Page 17: Alarm Terminal Block
Step 4: Plug the terminal block with the connected wires into the terminal block socket on the device. Step 5: Connect the other end of the power cable to the external power supply system within the allowed power range. If the corresponding power LED on the front panel of the switch turns on, the power supply is connected properly. -
Page 18: Reset
Figure 15 Alarm Terminal Block (socket) Wiring and Mounting Step 1: Remove the alarm terminal block from the switch. Step 2: Tighten the three wires into the alarm terminal block by following the instructions above. Step 3: Plug the alarm terminal block into its socket. Table 5 Wiring and Mounting Specifications Terminal Type Required Torque... -
Page 19: Leds
6 LEDs Table 6 Front Panel LEDs State Description Power 1 is connected and operates properly P1 LED Power 1 is not connected or operates abnormally Power 2 is connected and operates properly P2 LED Power 2 is not connected or operates abnormally Blinking The CPU is running properly Run LED... -
Page 20: Switch Access
Effective port connection Link/ACT LED (green) Blinking Ongoing network activities No effective port connection 1000Base-X 1000M working state (1000Base-X) Speed LED (yellow) 100M working state (100Base-FX) or no connection Effective port connection Link/ACT LED (green) Blinking Ongoing network activities No effective port connection 7 Switch Access You can access and manage the switch through console port, web and Telnet. - Page 21 Figure 17 Selecting a Serial Port Note： → [Property] → [Device Manager] To find out which COM port in use, right-click [My Computer] → [Port]. Step 5: Set COM port parameters (Bits per second: 115200, Data bits: 8, Parity: None, Stop bits: 1, and Flow control: None), as shown in the following figure.
-
Page 22: Access Through Telnet
Table 7 CLI Commands View Command Description Privileged mode SWITCH#show interface vlan 1 Query the IP address of the switch Privileged mode SWITCH#show version Query the version of the switch Privileged mode SWITCH#reboot Restart the switch Privileged mode SWITCH#load default Restore the factory default settings Privileged mode SWITCH#config terminal... -
Page 23: Access Through Web
Make sure that the switch and the PC are in the same subnet before login through Web. 8 Basic Features and Specifications Power Supply Voltage Range 24-48VDC (18-60VDC), SELV ETHERLINE ACCESS M06T-2GEN: 0.62A (MAX) ETHERLINE ACCESS M08T-2GEN: 0.62A (MAX) Input Current ETHERLINE ACCESS M08T02SFP: 0.67A (MAX) ETHERLINE ACCESS M08T02GSFP: 0.67A (MAX) Terminal block 5-pin 5.08 mm-spacing plug-in terminal block... -
Page 24: Accessories
ETHERLINE ACCESS M08T02SFP ETHERLINE ACCESS M08T02GSFP Physical Characteristics Housing Metal, fanless Protection class IP40 Installation DIN-Rail Mounting Dimensions (W×H×D) 66mm×135mm×107.5mm (excluding the connector, DIN rail) Weight 1.1kg Environmental Limits Operating temperature -40℃~+75℃ Storage temperature -40℃~+85℃ Ambient relative humidity 5%~95% (non-condensing) Altitude 2000m 9 Accessories...
