Summary of Contents for LAPP PROFINET ETHERLINE ACCESS PNF04T
- Page 1 Quick Start Guide PROFINET switch 4/8/16 port Version as of FW 1.08 www.lappkabel.com/activenetworkcomponents...
-
Page 2: Table Of Contents
Contents 1. Safety instructions 2. Introduction 3. Preparing the PROFINET switch 4. Planning of the GSDML files 5. Setting the port properties 6. Topology detection 7. Assign the PROFINET switch a name 8. Media Redundancy Protocol (MRP) 9. Diagnosis and configuration via the web interface 10. -
Page 3: Safety Instructions
1. Safety instructions Target audience This description is only intended for trained personnel qualified in control and automation engineering who are familiar with the applicable national standards. For installation, commissioning, and operation of the components, compliance with the instruc- tions and explanations in this operating manual is essential. The specialist personnel is to ensure that the application or the use of the products described fulfills all safety requirements, including all applicable laws, regulations, provisions, and standards. -
Page 4: Introduction
2. Introduction This Quick Start Guide explains the basic settings for the initial commissioning of PROFINET P1 — P4: switches for use in a PROFINET project. For PROFINET devices or other You can find further information in the manual. You can find this under www.lappkabel.com/ Ethernet devices activenetworkcomponents or scan the QR code directly. -
Page 5: Preparing The Profinet Switch
3. Preparing the PROFINET switch 3.1 Connection Note: The housing of the PROFINET switch is not grounded. Please connect the functional grounding connection (FG) of the PROFINET switch correctly with the reference potential. The PROFINET switch must be supplied with 24 V DC at the wide range input 18 –... -
Page 6: Planning Of The Gsdml Files
Following installation, the PROFINET switch can be found in the hardware catalog under “Other field devices g PROFINET IO g Network Components g LAPP GmbH g LAPP PN switch”. Add the “PROFINET Switch, 4 port”, “PROFINET Switch 8 port” of “PROFINET Switch, 16 port”... -
Page 7: Setting The Port Properties
5. Setting the port properties Each port of the PROFINET switch can be individually configured. Transfer medium/duplex: “Activate” The port can be switched off here. This option is recommended when the port shouldn’t be used. Unauthorized trespass into the network is prevented. Transmission rate The port synchronizes itself automatically with the “Automatic”... -
Page 8: Assign The Profinet Switch A Name
The MAC address of the device can be found on the device front of the PROFINET switch. The IPSet tool, which can be downloaded at no charge from the LAPP website, can also be used to set the PROFINET name. -
Page 9: Media Redundancy Protocol (Mrp)
8. Media Redundancy Protocol (MRP) The PROFINET switch supports the optional media redundancy protocol (MRP) as MRP client. MRP enables ring wiring, which also makes operation of the PROFINET network possible in the event of the failure of a cable or of a participant. There must be at least one MRP master (e.g. -
Page 10: Diagnosis And Configuration Via The Web Interface
9. Diagnosis and configuration via the web interface The web interface is also accessible under the IP address assigned to the PROFINET switch in the PROFINET network. When the web interface is first called up, the password of the “admin” user is the serial number of the device. The serial number is indicated on the right housing side part (e.g. “50001234”). It is absolutely necessary to assign a new password following the first login: Quick Start Guide PROFINET switch 4/8/16 port... - Page 11 One goes to the system view following entry of the new password: Note: If the PROFINET switch is configured and used in a PROFINET network, settings in the web interface are only to be viewed as a diagnosis. A reconfiguration of PROFINET-related settings (Port Status, LLDP, DCP, Ring Redundancy) is then not possible in the web interface. Quick Start Guide PROFINET switch 4/8/16 port...
-
Page 12: Switch Diagnosis And Settings
10. Switch diagnosis and settings Extensive information and settings for the function of the switch are accessible in the Switch menu. 11. Port mirroring In order to be able to carry out frame analyses or recordings, Port Mirroring can be activated in the PROFINET switch. With Port Mirroring, the frame transfer from one “mirrored port”... -
Page 13: Statistics
12. Statistics Detailed statistics on the data transfer can be queried in the “Statistics” menu. Among other things, the quality of the transmission can be monitored in the sub-menu “Statistics by Error”. Quick Start Guide PROFINET switch 4/8/16 port... -
Page 14: Agents
13. Agents In order to already be able to view basic information about the switch at the start website, before or without having logged in, the option “System Status Without Login” can be selected. With “Web Session Timeout”, it can be established whether an automatic logout should take place in the event of inactivity at the website for security reasons. Quick Start Guide PROFINET switch 4/8/16 port... -
Page 15: Snmp
14. SNMP The PROFINET switch supports SNMP (“Simple Network Management Protocol”) in order to also enable the identification and diagnosis of the switch for IT administration tools. Quick Start Guide PROFINET switch 4/8/16 port... -
Page 16: Setting The Time
15. Setting the time The PROFINET switch contains a system clock for the issuing of logs and alarm messages. This can be set either manually or automatically by an SNTP server. Quick Start Guide PROFINET switch 4/8/16 port... -
Page 17: Resetting To Factory Settings
16. Resetting to factory settings In order to reset the PROFINET switch to the delivery status, the function “Factory Reset” can be used in the web interface under “System” g “Restart”. Alternatively, the PROFINET switch can be reset by pressing and holding the “FCN” button while the device restarts. A restart can be carried out by switching the power supply off and on or by activating the RST button. -
Page 18: Led Status Information
18. LED status information 19. Button functions The PROFINET switch can be reset to factory settings with the No power supply or device defective “FCN” button. Device is correctly supplied with voltage If the “FCN” button is pressed during the run-up time of the switch, the orange “SF”... -
Page 19: Technical Data
20. Technical data PROFINET switch, 4 port, managed PROFINET switch, 8 port, managed PROFINET switch, 16 port, managed ETHERLINE ACCESS PNF04T ETHERLINE ACCESS PNF08T ETHERLINE ACCESS PNF16T ® ® ® Dimensions (D x W x H) 32 x 59 x 76mm 32 x 82 x 76mm 32 x 146 x 76mm Weight... - Page 20 SIMATIC is a registered trademark of Siemens AG. Our customers are at the center of everything we do. We welcome all ideas and suggestions. U.I. Lapp GmbH | Schulze-Delitzsch-Straße 25 | 70565 Stuttgart | Germany | Phone: +49 (0)711-7838-01 | Fax: +49 (0)711-7838-2640 | info@lappkabel.de | www.lappkabel.com...
