Reset Button (located at the bottom part of the Kenmore Smart Thermostat)
KEY/TOUCH ACTION FUNCTION
Up Key
Down Key
System Key
Fan Key
Menu / Select Key
Back Key
Reset Button
P 3
FEATURES / OPERATION
Back
Menu or
Select
Fan
Increase set temperature for TEMP HOLD or PERM HOLD. Also used with Down key to
activate "Key Lock"
Decrease set temperature for TEMP HOLD or PERM HOLD. Also used with Up key to activate
"Key Lock"
Switching operating mode: AUTO, HEAT, COOL, OFF, & EMERGENCY HEAT
Switching fan mode: ON or AUTO
Press Menu / Select once and use Up/Down Key to navigate the following functions:
• Vacation
• Clock
When the thermostat shows the function you want to set up, press Menu/Select once again
•
to enter that function.
•
For modifying parameters, use Up/Down to change and Menu/Select to confirm the setup value.
•
At any time during Setup, pressing Back once will navigate backward one level and cancel
any setting change you have made.
Pressing and holding Back for 2 seconds while in a Menu screen will return the unit to the
•
Home Screen.
Pressing and holding Back for 2 seconds while on the Home Screen will cancel Temp Hold,
Perm Hold, Vacation mode, and Away mode. (Away mode is only available via the
Assurelink remote APP.)
Reset the thermostat. Can also used for installation setup and to remove the
thermostat from customer's Assurelink account. See Assurelink APP for details.
F
PM
F
F
/
Auto
Cool
Fan
Auto
• Program
Up Key
Down Key
System
• Settings
• Filter
