Kimo KIRAY 300 User Manual

Infrared thermometer KIRAY 300 is a thermometer used to
diagnose, inspect and check any temperature. Thanks to its
elaborated optical system with a dual laser sighting, it allows easy
and accurate measurements of little distant targets. The KIRAY
300 instrument has an internal memory which can save up to 100
measurements. Compatible with thermocouple K probe.
Supplied with
thermocouple K
probe
DISTANCE FROM THE TARGET
Distance 1270
25.4
Diameter
YES
Make sure that the target is larger than the size of the laser sighting.
DigiParts GmbH
KIRAY 300
Infrared thermometer
2540 3810 mm
50.8 mm
76.2
D:S=50:1
50.8 mm to 2540 mm
NO

TECHNICAL FEATURES

Instrument features
●
Spectral response 8 -14 µm
Optical D.S : 50:1 (50.8 mm at 2540 mm)
Response time 150 ms
Temperature range From -50 to +1850 °C
Accuracy* From -50 to +20 °C : ±3 °C
From +20 to +500 °C : ±1% ±1 °C
From +500 to +1000 °C : ±1.5%
From +1000 to +1850 °C : ±2%
From -50 to +20 °C : ±1.5 °C
Infrared repeatability
From +20 to +1000 °C : ±0.5% or ±0.5 °C
From +1000 to +1850 °C : ±1%
Display resolution 0.1 C °
Emissivity Adjustable from 0.10 to 1.00 (pre-set at 0.95)
Over range indication Display indication : « ---- »
Dual laser sighting
Wavelength : from 630 nm to 670 nm
Output < 1mW, Class 2 (II))
Positive or negative Automatic (no indication for a positive temperature)
temperature indication (-) sign for a negative temperature
Display 3 lines, 4 digits with backlighted display LCD
Auto-extinction Automatic after 7 seconds of inactivity
High/low alarm Flashing signal on display and beep signal with
adjustable thresholds
Power supply Alkaline 9 V battery
Autonomy 95 h (inactive laser and backlight)
15 h (active laser and backlight)
Use temperature
From 0 to +10 °C for a short period
From 11 to +50 °C for a long period
Storage temperature From -10 °C to +60 °C
Relative humidity From 10% to 90%RH in operating mode and
>80%RH in storage
Dimensions 200 x 140 x 50 mm
Weight 320 g (included battery)
Memory 100 temperature values
*Accuracy for an ambient temperature from 23 to 25°C (with a relative humidity lower
than 80% RH)
Thermocouple K probe features
●
Temperature range
From -40 to +400 °C
Display range From -50 to +1370 °C
Resolution 0.1 °C
Accuracy ±1.5% of reading ±3 °C
Cable length 1 m
