General View, Left Side - BMW Motorrad R 1200 GS Adventure Rider's Manual

General view, left side

1 Clutch fluid reservoir
( 100)
2 Headlight adjustment
(vertical), beneath instru-
ment panel ( 52)
3 Adjusting rear damping
( 58)
4 Seat lock ( 54)
5 Onboard socket (
6 Filler neck, engine oil
( 95)
7 Oil sight glass (
8 Adjusting front spring
preload ( 58)
9 Onboard socket (OA)
( 80)
10 Adjustable windshield
( 56)
80)
94)
