- Page 1 Hybrid...
- Page 2 english Product manual...
- Page 3 Thank you for choosing NOBACCO Hybrid as your personal vaping device. Please make sure that you have read the manual supplied with the product and that you have fully understood it. NOBACCO Hybrid is an innovative device that combines the atomizer tank and the battery in a uni-body design.
- Page 4 Device characteristics Built in Battery: 1500mah Atomizer tank capacity: 2ml Airflow Control USB charging port with Pass-through function Removable 510 type mouthpiece SS316 0,6ohm coil head with organic cotton Dimensions -Weight Height: 118.05 mm Width: 19 mm Weight: 70.2 gram...
- Page 5 Device Components Hybrid Mouthpiece Atomizer Base Hybrid Head (coil) Hybrid Battery...
- Page 6 Package Content* 1 x Device NOBACCO Hybrid 1 x USB charging cable 1 x Clear mouthpiece 2 x Coil Heads User Manual Authenticity card *The company in order to improve the product has the right to change the content of the package or the specifications without any prior notice.
- Page 7 Device Preparation The device is, usually, shipped partly charged and deactivated. To start using your device, please follow the steps described below: 1. Remove the upper part of the atomizer by pressing the airflow ring downwards and twisting it counter- clockwise.
- Page 8 4. Fill the tank with e-liquid up to the max point or the color indicator of the bicolor version as shown below Screw clockwise the atomizer onto the tank 5. Do not use the device for at least five (5) minutes to allow the coil head to saturate properly.
- Page 9 Your device needs refilling when the e-liquid level reaches below the dented part of the coil head. NOBACCO Hybrid supports the Airflow Control System (ACS) technology. To adjust the atomizer’s airflow, turn the ring on the atomizer’s base clockwise or counterclockwise The two dots provide the user with an indication of the airflow.
- Page 10 Charging your Device NOBACCO Hybrid features a gauge that provides an indication of the remaining battery capacity. After the user presses the activation button, the frequency with which the LED light blinks corre- sponds to a different remaining battery level.
- Page 11 Do not use a USB port or any wall adapter with an output higher than 1.2 Ah/1200mAh. In the event of incorrect charging, warranty may not be valid. Color Indications Your device allows you to change the indicator color, or its full deactivation. In power-off condition, long press the fire button until the indicator light is on, then press the but- ton to shift among the color of red, yellow, green, blue, indigo, white, purple or light-off.
- Page 12 When the resistance is greater than 5ohm, the light flashes slowly if you press the fire button. When the resistance is lower than 0.3ohm, the light flashes quickly for 5 times, suggesting the ohm is too low or potential short circuit. Atomizer protection: As a safety feature the device has a 15 second run time protection.
- Page 13 • Do not pierce or in any way damage the device housing. If the device housing is damaged in any • way, directly contact NOBACCO Company. Do not carry or store the device with other metal objects. • Use only the dedicated for device parts and accessories to avoid any malfunction.
-
Page 14: Warranty
For more information about the warranty period, please visit the product’s official webpage at www.nobacco.gr or ask your local reseller. NOBACCO COMPANY CANNOT BE HELD RESPONSIBLE FOR DAMAGES THAT MAY OCCUR DUE TO... - Page 15 No part of this guide may be reproduced, translated or transmitted in any form or by any means without the prior written permission of NOBACCO Company.
- Page 16 www.nobacco.gr...
