Application note
4G LTE access with Mikrotik wAP
Versions:
Revision
Note
0.1
Initial creation
0.2
Added screenshots
0.3
Language Correction
0.4
Updated Wifx logo
Application note – 4G LTE access with Mikrotik wAP revision 0.4
Date
30/10/2017
30/11/2017
05/12/2017
17/01/2020
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LORIX one and is the answer not in the manual?

Questions and answers

Summary of Contents for Wifx LORIX one

  • Page 1 LORIX One Application note – 4G LTE access with Mikrotik wAP revision 0.4 COMPACT AND ROBUST PROFESSIONAL GRADE LoRaWAN™ GATEWAY Application note 4G LTE access with Mikrotik wAP Versions: Date Revision Note Initial creation 30/10/2017 Added screenshots 30/11/2017 05/12/2017 Language Correction...
  • Page 2 LORIX One Application note – 4G LTE with Mikrotik wAP revision 0.4 UMMARY Summary ................................2 Introduction ................................. 3 Material ................................3 Setup ..................................4 Hardware ..............................4 Software ..............................4 4.2.1 Configure your wAP LTE .......................... 4 4.2.2 Check the configuration .......................... 7...
  • Page 3 NTRODUCTION This document shows what materials you need and how to connect all elements together to use the LORIX One with with LTE. How to configure the wAP LTE from a web interface with the SIM Card and other parameters. To configure your LORIX One, please refer to document sent with your LORIX One product.
  • Page 4 The yellow, blue and grey Ethernet patch cables in the following pictures are not included in the LORIX One’s kit. Connect the wAP to the left port (Port 1) of the splitter and the LORIX One Lora Gateway to the middle port (Port 2) of the splitter then connect the injector PoE in the last port (Port 3) of the splitter.
  • Page 5 LORIX One Application note – 4G LTE access with Mikrotik wAP revision 0.4 2. Connect your computer to the Wi-Fi network Mikrotik-XXXXX, for example Mikrotik-3B137B: For the following steps please check the screenshot on the next page. 3. Launch your preferred web browser and type in http://192.168.88.1...
  • Page 6 LORIX One Application note – 4G LTE with Mikrotik wAP revision 0.4 Default wAP network address Configuration mode of the wAP WiFi network password wAP interface password...
  • Page 7 LORIX One Application note – 4G LTE with Mikrotik wAP revision 0.4 4.2.2 C HECK THE CONFIGURATION Once the configuration applied, the new parameters will be effective. If you choose to change the Wi-Fi network name and/or password, you will be disconnected and will need to login again.
  • Page 8 Support e-mail: support@lorixone.io And for more information, feel free to visit the LORIX One website at www.lorixone.io To launch the ping command, open a terminal by typing “Win+R“ then write “cmd” and press enter. In the terminal (black window), type “ping <domain>“, e.g. ping lorixone.io or any working IP address.
