Low cost LoRa IP43/IP65 gateway
Quick start guide
I
NTRODUCTION
Thank you for purchasing the LORIX One low cost LoRa gateway made by Wifx Sàrl. This quick start
guide is made to help you to quickly install and use your product. It includes in addition the warranty
terms.
O
VERVIEW
Ethernet connector
PoE injection
Reset button
microSD
slot
C
INSTALLATION AND
The product is designed to be placed vertically with the antenna upwards. Mounting the product
differently doesn't ensure waterproofing or could decrease thermal performance.
In addition, the product needs the IP65 antenna to be well fixed to guarantee a global IP65 level.
To install, it begins by opening the low side cap, remove the cable gland and pass the cable
connector through the hole.
ONSTRAINTS
C
ONTENT
The package contains:
• LORIX One LoRa gateway
Status
LED
(IP43 or IP65)
• UV resistant zip ties (x2)
• Passive PoE injector
USB service
connector
• 24VDC/12W switching adapter
HNP12-240L6
• Indoor 2dBi antenna
• Outdoor 4.15dBi IP65 antenna
• Quick start guide
WARNING : Please
never power on the
gateway without an
antenna plugged in.
or
