Ledco RM1 Manual

6-Key RF Remote Controller
Model No.: RM1/RM2
1 zone dimming/6-key/Wireless remote 30m distance/CR2032 batter y
RM1
1 Zone Dimming
Features
● Apply to single color or dual color LED controller.
● Each remote can match one or more receiver.
● R C 2032 attery powered. b
● Operate with LED indicator light.
Technical Parameters
Input and Output
Output signal RF 2.4GHz ( )
Working voltage 3VDC CR2032
( )
Working current ＜5mA
Standby current ＜2μA
Standby time 2 years
Remote distance 30m(Barrier-free space)
Environment
O O
Operation temperature Ta: -30 C ~ +55 C
Case temperature Max.
( ) T c: +85 O
C
IP rating
IP20
User Manual Ver 1.0.2
RM2
1 Zone CCT
LVD RED
Safety and EMC
EMC standard (EMC) EN301 489,EN 62479
Safety standard(LVD)
EN60950
Radio Equipment(RED)
EN300 328
CE,EMC,LVD,RED
Certification
Warranty
5 years
Warranty
Mechanical Structures and Installations
8.00 mm
47.00 mm
Match Remote Control (two match ways)
End user can choose the suitable match/delete ways. Two options are offered for selection:
Use the controller's Match key
Match:
Short press match key,
immediately press on/off key on the remote.
The LED indicator fast flash a few times
means match is successful.
Delete:
Press and hold match key for 5s to delete all match,
The LED indicator fast flash a few times
means all matched remotes were deleted.
RM1,RM2 6-Key RF Remote Controller
CR2032
Batter y
Note: Before the first use,
please remove the protective film on the battery.
Use Power Restart
Match:
Switch off the power, then switch on power again,
immediately short press on/off key 3 times on the remote.
The light blinks 3 times means match is successful.
.
Delete:
Switch off the power, then switch on power again,
immediately short press on/off key 5 times on the remote.
The light blinks 5 times means all matched remotes were
deleted.
Page 1
