PR electronics 5909 Manual

Loop link usb communications interface
Hide thumbs Also See for 5909:
Table of Contents

Advertisement

Quick Links

5 9 0 9
L o o p L i n k
U S B C o m m u n i c a t i o n s
I n t e r f a c e
N o . 5 9 0 9 V 1 0 3 - U K
F r o m s e r . n o . 0 5 9 9 9 9 9 9 9

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 5909 and is the answer not in the manual?

Questions and answers

Related Manuals for PR electronics 5909

Summary of Contents for PR electronics 5909

  • Page 1 5 9 0 9 L o o p L i n k U S B C o m m u n i c a t i o n s I n t e r f a c e N o . 5 9 0 9 V 1 0 3 - U K F r o m s e r .
  • Page 2 Vores motto »Signals the Best« er indbegrebet af denne filosofi – og din garanti for kvalitet. PR electronics A/S offers a wide range of analog and digital signal conditioning devices for industrial automation. The product range includes Isolators, Displays, Ex Interfaces, Temperature Transmitters, and Multifunctional Devices.

  • Page 3: Table Of Contents

    Installation from USB ............... PReset installation on Windows 7 / 8 / 10 ........5909 installation on Windows 7 ............5909 installation on Windows 8 ............12 Troubleshooting for Windows 7 & 8 ..........16 5909 installation on Windows 10 ........... 17 Configuration of USB communication in PReset ......

  • Page 4: Warning

    The following operations must only be carried out on a device that is not connected to SYSTEM 5000 and a PC: Troubleshooting the device. HAZARD- Repair of the device must be done by PR electronics A/S only. VOLTAGE WARNING The female communication connector of SYSTEM 5000 is connected to the input terminals on which dangerous voltages can occur.

  • Page 5: Safety Instructions

    Should there be any doubt as to the correct handling of the device, please contact your local distributor or, alternatively, PR electronics A/S www.prelectronics.com 5 90 9 V 1 03 - UK...
  • Page 6 When disconnected, the device may be cleaned with a cloth moistened with distilled water. LIABILITY To the extent that the instructions in this manual are not strictly observed, the customer cannot advance a demand against PR electronics A/S that would otherwise exist according to the concluded sales agreement. 5909V10 3 -UK...

  • Page 7: Application

    The PC program CD PReset ver. 5.0 or higher contains the necessary (unsigned) USB drivers. Loop Link 5909 is supplied from the USB port of the PC. If you want to conserve power on a laptop, the USB connector of the 5909 can be connected to an externally supplied hub.

  • Page 8: Installation From Usb

    Installation from USB 1. Plug in the USB. 3. Open File Explorer and locate the USB drive. Double-click on the file “setup.exe”’ to start the installation. 5909V10 3 -UK...

  • Page 9: Preset Installation On Windows 7 / 8 / 10

    PReset installation on Windows 7 / 8 / 10 To install PReset on Windows 7 / Windows 8 / Windows 10 it is necessary to be a local administrator on the PC. Install from the CD or the USB or download the software from www.prelectronics.com Run setup and follow the instructions on the screen.

  • Page 10: 5909 Installation On Windows 7

    5909 installation on Windows 7 To install 5909 on Windows 7 it is necessary to be a local administrator on the pc. 1. Connect your 5909 to a USB port on your machine. 2. Click [Close] in the following dialog: 3.
  • Page 11 5. Click [Browse my Computer for driver software]. 6. If your computer is running the 32 bit version of Windows 7, browse to “%ProgramFiles%\PR electronics\PReset\Drivers” 5 90 9 V 1 03 - UK...
  • Page 12 If your computer is running the 64 bit version of Windows 7, browse to “%ProgramFiles(x86)%\PR electronics\PReset\Drivers” 7. Click [Next]. 8. Now the driver for your 5909 will be installed. 5909V10 3 -UK...
  • Page 13 9. When you see this screen click [Close]. 10. The installation of 5909 driver is complete! 5 90 9 V 1 03 - UK...

  • Page 14: 5909 Installation On Windows 8

    5909 installation on Windows 8 To install 5909 on Windows 8 it is necessary to be a local administrator on the pc. 1. Connect your 5909 to a USB port on your machine. Go to Windows control panel and click [System] and then [Device manager].
  • Page 15 3. Click [Browse my Computer for driver software]. 4. If your computer is running the 32 bit version of Windows 8, browse to “%ProgramFiles%\PR electronics\PReset\Drivers” 5 90 9 V 1 03 - UK...
  • Page 16 If your computer is running the 64 bit version of Windows 8, browse to “%ProgramFiles(x86)%\PR electronics\PReset\Drivers” 5. Click [Next]. 6. Click [Install]. Now the driver for your 5909 will be installed. 5909V10 3 -UK...
  • Page 17 7. When you see this screen click [Close]. The installation of 5909 driver is complete! 5 90 9 V 1 03 - UK...

  • Page 18: Troubleshooting For Windows 7 & 8

    Troubleshooting for Windows 7 & 8 If you are unable to install the USB Loop Link follow these steps: 1. Disconnect the 5909. 2. Go to the Control Panel. 3. Go to Devices and Printers. 4. Locate your PC (under devices).

  • Page 19: 5909 Installation On Windows 10

    5909 installation on Windows 10 To install 5909 on Windows 10 it is necessary to be a local administrator on the 1. Connect your 5909 to a USB port on your machine. 2. Windows 10 will automatically start the installation process.
  • Page 20 4. Right click the [Unknown device] and click [Update driver software]. 5. Click [Browse my Computer for driver software]. 5909V10 3 -UK...
  • Page 21 6. If your computer is running the 32 bit version of Windows 10, browse to “%ProgramFiles%\PR electronics\PReset\Drivers” If your computer is running the 64 bit version of Windows 10, browse to “%ProgramFiles(x86)%\PR electronics\PReset\Drivers” 7. Click [Next]. 5 90 9 V 1 03 - UK...
  • Page 22 8. Click [Install]. Now the driver for your 5909 will be installed. 9. When you see this screen click [Close]. The installation of the 5909 driver is complete! 5909V10 3 -UK...
  • Page 23 10. You can now see the 5909 USB to Loop Link device in the Device Manager. 5 90 9 V 1 03 - UK...

  • Page 24: Configuration Of Usb Communication In Preset

    1. Start the PReset program and choose [Tools] [Select COM port], and the ”Options” window is shown on screen. 2. Select PR electronics Loop Link. Click OK. 3. If you want to configure Loop Link for other USB ports, you must connect Loop Link to these ports and install the USB drivers for each port.

  • Page 25: Connection Of Pr Devices Using Ez-Mini-Hooks

    Connection of PR devices using EZ-Mini-Hooks Receiving Equipment Disconnect +Vsupply Yellow Input PR 5331, 5333, 5334, Green 5335, 5337 Black (21) (23) Connector * Connected only for on-line programming PR 6331, 6333, 6334, L oop 6335, 6337 L ink USB cable Connection of PR devices using a modular connector Programming cable with modular connector...
  • Page 26 Displays Programmable displays with a wide selection of inputs and outputs for display of temperature, volume and weight, etc. Feature linearization, scaling, and difference measurement functions for programming via PReset software. Ex interfaces Interfaces for analog and digital signals as well as HART signals between sensors / I/P converters / frequency signals and control systems in Ex zone 0, 1 &...
  • Page 27  www.prelectronics.se  sales@prelectronics.se  www.prelectronics.co.uk  sales@prelectronics.co.uk  www.prelectronics.com  sales@prelectronics.com  www.prelectronics.cn  sales@prelectronics.cn Head office Denmark www.prelectronics.com PR electronics A/S sales-dk@prelectronics.com Lerbakken 10 tel. +45 86 37 26 77 DK-8410 Rønde fax +45 86 37 30 85...
