Safety advices:

 Do NOT use the device near water or in rooms with high humidity such
as humid cellars or near swimming pools.
 Do NOT use the device outdoors. All connections must be located inside
a building.
 Keep the device away from moisture, dust or corrosive liquids.
 Do NOT install the device, use it or perform maintenance during a
thunderstorm. There is a risk of electric shock during thunderstorm.
 Use ONLY the supplied AC adapter.
 Connect ONLY appropriate accessories to the device.
 Make sure that all cables are connected to the correct port.
 Carefully lay the Ethernet, antenna and electric cables to ensure that
nobody can step on or stumble over them.
 Do NOT cover the ventilation slots of the device since insufficient air
supply may result in damage to the device.
 Do NOT place any objects on the device. Do not place objects filled with
liquids such as vases on the device.
 Position the device in a place where NOBODY can step on it.
 In case of damage, interrupt the power supply IMMEDIATELY.
 Do NOT try to repair the device. This equipment should ONLY be serviced
or repaired by qualified service personnel. Contact your distributor for
more information.
 Do NOT open the device.
 Prior dismounting, disconnect the electric, Ethernet and antenna cable
from the device.
Hereby, AXING AG declares that the device is in compliance with the
essential requirements and other relevant regulations of directives
2014/53 / EU, 2009/125 / EC and 2011/65 / EU.
The long version of the CE declaration of conformity can be found in English
at http://download.axing.com/CE/CE_CMO00201.pdf
WEEE Nr. DE26869279 | Electrical and electronic components must not be
disposed of as residual waste, it must be disposed of separately.
State of the art 2020-02-18
Technical improvements, changes in design, printing- and other errors expected.

Technical data:

Type
Downstream
Frequency range
Channel bandwidth
Channel bonding
Input level
Demodulation
Data rate Max. 320 Mbps @ DOCSIS
Max. 400 Mbps @ EuroDOCSIS
Upstream
Frequency range
5...65 MHz @ EuroDOCSIS
Channel bandwidth 200/400/800/1600/3200/6400 KHz
Output level
8...53 dBmV @ S-CDMA
Channel bonding
Modulation QPSK, QAM8, QAM16, QAM32, QAM64, QAM128
Data rate
Interfaces
Ethernet 2 × RJ 45, IEEE 802.3 10Base-T | 802.3u 100Base-TX |
802.3ab 1000Base-T (GigE)
WiFi standard IEEE 802.11b/g/n | 2.4 GHz single-band
Wifi signal rate
WiFi encryption
General
Operation voltage
Operating temperature range
Operating humidity (non-condensing)
Dimensions (W × H × D) appr.
Note: You can find the complete technical data at www.axing.com.
Commission regulation (EU) 2019/1782
External plug-in power supply
Manufacturer's name or trademark Shenzhen Click Technology Co., Ltd.
Fl 1-4 Building 7 and Fl 2 Building 8
commercial registration number and
Zhengzhong Ind Park, Qiaotou Village, Fuyong Town,
address
Guandong 518103, P. R. China
Model identifier
Input voltage
Input AC frequency
Output voltage
Output current
Output power
Average active efficiency
Load condition 1 – 100 % ± 2 %
Load condition 2 – 75 % ± 2 %
Load condition 3 – 50 % ± 2 %
Load condition 4 – 25 % ± 2 %
Efficiency at low load (10 %)
No-load power consumption
Manufacturer EEA contact address
AXING AG Bechler GmbH
Gewerbehaus Moskau Am Rebberg 44
8262 Ramsen 78239 Rielasingen
CMO 2-01
108...1002 MHz
6 MHz @ DOCSIS
8 MHz @ EuroDOCSIS
≤8
-15 dBmV...+15 dBmV
QAM64, QAM256
CMO 2-01
5...42 MHz @ DOCSIS
premium-line
8...58 dBmV @ QPSK
8...54 dBmV @ 64 QAM
8...54 dBmV @ 32 QAM
DOCSIS/EuroDOCSIS
≤4
(SCDMA)
cable modem
120 Mbps @ TDMA
160 Mbps @ S-CDMA
WiFi
300 Mbps
Quick start guide
WPA/WPA2
12 VDC
0...40 °C
10...90%
167 × 125 × 38 mm
Boan District, Shenzhen
914403007576217064
CPSO24C120150V
100...240 V
50...60 Hz
12,0 V
1,5 A
18,0 W
84,1 %
85,1 %
86,3 %
86,0 %
82,2 %
0,04 W
