HDPlex 2nd Gen H5 Fanless Installation Manual

Htpc chassis
Hide thumbs

Advertisement

Quick Links

Download this manual
2
nd
Gen H5 Fanless HTPC Chassis
Installation Guide V 2.0
Page 1 of 24

Advertisement

loading
Need help?

Need help?

Do you have a question about the 2nd Gen H5 Fanless and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HDPlex 2nd Gen H5 Fanless

Summary of Contents for HDPlex 2nd Gen H5 Fanless

  • Page 1 Gen H5 Fanless HTPC Chassis Installation Guide V 2.0 Page 1 of 24...
  • Page 2 Paypal/Rü ckerstattung zu Ihrem Auftrag. Offre de remboursement HDPLEX Recevez 30 dollars US pour tout achat d'un boitier HDPLEX. Pour bé né ficier de cette offre, rien de plus simple: prenez deux ou trois photos de votre installation HDPLEX H5 accompagné es de vos commentaires ou suggestions (dans la langue de votre choix) puis postez-les sur un blog, sur Facebook, ou sur n'importe quel forum.

  • Page 3: Package Contents

    Package Contents H5 Chassis Body Top Plate Bottom Plate Left Side Panel Right Side Panel Back Plate*2 (Dual Slot and Low Profile) Four Feet with Rubber Cushion H5 Chassis Faceplate Faceplate (Silver or Black) H5 Heatsink System Aluminum Top Plate Heatpipe Installation Plate (H-9) x4 Copper Baseplate High Quality Thermal Paste 3.5g...
  • Page 4 C:M4*6 Flat Head HEX Screw-Black 18pcs For Feet/Top Plate/Bottom Plate/Side Panel/Back Panel Installation D:M3*5 Flat Head Screw –Black 18pcs For SSD mounting/AC IEC installation E: 7mm Hexagonal Copper Stud for Motherboard Installation 12pcs F: 6-32 Thread 6mm Screw- Silver 8pcs For 3.5” HDD Installation G: Hexagonal Copper Stud for HDD Rack:10mm-4pcs 30mm-8pcs 50mm-8pcs J: M3 Self-Tightening Nut-Silver 20pcs K: M3 Round Head 8mm Screw 8pcs Page 4 of 24...
  • Page 5 H5 Chassis Bottom Plate Installation Install four feet with rubber cushion to the bottom plate back side using 4pcs Install Hexagonal Copper Stud 7mm to the bottom plate, matching your motherboard installation position Install to the back side of the H5 bottom plate, lock the copper stud M3 exposed thread.
  • Page 6 internal side. Both PWR and PWR LED plug do not have polarity. PWR LED will light up in blue color once PC is turned on. Use two M3*8mm screw to install the USB 3.1 Type C cable. Please make sure the USB 3.1 Type C port is fully inserted and is even with external surface.
  • Page 7 Remove protection cover from the copper base plate and install two rack on the copper bottom plate using 4pcs Install the holder on to the tip of the two racks. Please make sure the direction of part H-8 is correct. Install 4pcs into the holder.
  • Page 8 Install the motherboard on the H5 bottom plate hexagonal copper stud using Install the copper base with rack onto the motherboard. Please make sure heatpipe slot direction is vertical to the side panel. Tighten the four screws in even fashion. Do NOT over tighten the H-3 screw or apply too much torque.
  • Page 9 Remove motherboard AMD socket mounting rack, keep the bottom plate on the back of the motherboard. Install the copper heatsink block using 4 Apply thermal paste to the heatpipe groove on both side panels using the dumbbell shaped tool. Apply a thin layer of thermal paste to the copper plate groove using the dumbbell tool.
  • Page 10 Install heatpipe 1 and 2. Install heatpipe 3 and 4. Page 10 of 24...
  • Page 11 Install heatpipe 5 and 6. Install heatpipe 7 and 8. Tighten the to the side panel using which goes through the hole on the side panel from outside of the H5 chassis. square shape and needs to be in the correct direction to match the mounting hole. Page 11 of 24...

  • Page 12: Power Supply Installation

    Power Supply Installation HDPLEX 400W AC-DC+400W DC-ATX NanoATX Combo HDPLEX 400W AC-DC is back mounted on the H5 bottom plate via the M2.5 screws come with the HDPLEX 400W AC-DC package. HDPLEX 400W AC-DC optional mounting ears are NOT used for H5 installation.
  • Page 13 The four M3 holes in the center on the back of the 400W AC-DC adapter are not used for H5 mounting. HDPLEX 400W DC-ATX is front mounted using M3 screws. One 24PIN extension cable is included in the H5 package.

  • Page 14: Hard Drive Installation

    If you are using standard ATX/SFX/FlexPSU inside H5 for ITX or narrow width ATX/microATX motherboard, attach the universal rack to the power supply using 2pcs first. Plug the AC extension cord to the power supply and install them to the PSU rack mounting hole on the top left of the H5 bottom plate using 2pcs D.
  • Page 15 SSD data and power connector will stick out a bit of the HDD rack for SATA cable easy access. If you are using HDPLEX 400W NanoATX Combo power supply, we recommend using 50mm length copper stud to install the HDD rack. You could install two SSD and one 3.5”...
  • Page 16 HDD rack on the copper stud and lock the copper stud exposed M3 thread on the outside of the HDPLEX bottom plate. Backplate and PCI-E Card Installation If you are using the H5 backplate with dual full height horizontal PCI-E slot and...
  • Page 17 If you are using 7.4*5.0mm self-lock connector, please install the DC Adapter Plate using 2pcs to the AC adapter plate. HDPLEX ATX Modular Bridge Input Board (This product is included with 500W ATX linear PSU and could also be purchased separately). Install 4pcs...
  • Page 18 ATX Modular bridge board will conflict with H5 side heatsink panel if installed incorrectly. Below is the view from external side of the H5 backplate. Install the left heatsink panel on the H5 bottom plate using 2pcs Attached motherboard I/O shield plate to the H5 back plate and install the back plate using 4pcs to two side panel and two pcs to the bottom plate.
  • Page 19 First, please connect the PCIEx16 riser card to your video card and turn on PC to test. If test fine and PCIEx16 card is showing the correct PCIE version (3.0) and speed (x16) under benchmark or load test, disconnect everything. HDPLEX GPU heatsink system parts list: Eight 6mm OD Copper Heatpipes Aluminum Top Cover Copper Base Plate High Quality Thermal Paste 3.5g...
  • Page 20 V-1: M3*14mm M3 screws 16pcs V-2: M4*10mm CUP Head M3 screws 8pcs V-3: M2.5*7mm screws w/spring 4pcs Uninstall the original heatsink from the video card and install the copper plate using 4pcs V-3. Please make sure the copper base slot facing the correct direction.
  • Page 21 Install the video card to the H5 back plate. Slide the dual bracket tip inside and using 1pcs firmly attach the video card bracket to H5 back plate. Apply thin layer of thermal paste to the side panel groove and install eight heatpipes following the below pattern.

  • Page 22: Faceplate Installation

    Install the 3pcs aluminum plate on the side panel using first and aluminum top cover using 8pcs Faceplate Installation If you don’t need front handle, just mount the faceplate using 4 HEX Socket Cap Head M5*12mm to the two H5 side heatsink panel. Page 22 of 24...
  • Page 23 To install optional handle. First use 4pcs Hex Socket Cap Head M4*14mm install the front handle from the back of the faceplate. Use 4pcs Hex Socket Cap Head M5*8mm to mount the faceplate onto side heatsink panel mounting ear from the back. Use M5 HEX key Allen wrench to tighten it. Test PC thoroughly and make sure heatsink system functions well.
  • Page 24 For suggestions and advice on HDPLEX fanless chassis, please visit our community at https://www.hdplex.com/forum Copyright 2019-2020 HDPLEX LTD. All rights reserved. All trademarks are the property of their respective owners. Reproduction in whole or in part without written permission is prohibited.
