Atlas Equipment 200 Series Installation & Operation Manual

Left assist arm
Hide thumbs

Advertisement

Quick Links

Advertisement

loading
Need help?

Need help?

Do you have a question about the 200 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Atlas Equipment 200 Series

Summary of Contents for Atlas Equipment 200 Series

  • Page 2: Table Of Contents

    CONTENTS INTRODUCTION PRODUCT DESCRIPTION GENERAL INFORMATION INSTALLATION MAINTENANCE 2 / 12 REV. 01...

  • Page 3: Introduction

    CHAPTER 1 - INTRODUCTION Thank you for purchasing a product from the line of accessories. The machine has been manufactured in accordance with the very best quality principles. Follow the simple instructions provided in this manual to ensure the correct operation and long life of the machine. Read the entire manual thoroughly and make sure you understand it.

  • Page 4: Product Description

    CHAPTER 2 - PRODUCT DESCRIPTION 1) Arm 1 2) Arm 2 3) Arm 3 4) Bead pressing too 5) Arm with bead lifting disk 6) Lifting/lowering control 7) Lifting/lowering control 8) Operating arm with roller tool 9) Arm with bead lifting disk 4 / 12 REV.

  • Page 5: General Information

    CHAPTER 3 – GENERAL INFORMATION INTENDED USE These accessories have been designed and manufactuered exclusively for being installed on a tire changer in order to faciliate removing and mounting of tires from/onto the rim. Any other use is to be considered incorrect and unreasonable. In particular the manufacturer cannot beheld responsible for any damage caused through the use for purposes other than those specified in this manual, and therefore inappropriate, incorrect and unreasonable.

  • Page 6: Installation

    CHAPTER 4 – INSTALLATION The accessories need to be connected to a compressed air system with values between 8 – 10bar. INSTALLATION ON TIRE CHANGER 4.1.1 MOUTING HELP • Unscrew the lubricator support (A); • Remove the side cover from the machine; •...
  • Page 7 4.1.2 MOUTING PRESS ARM • Mount the support (G) onto the frame by means of 2 screws M10X25 and relevant nuts; (fig.5) • Fix the column (L) to the back part of the frame by means of 3 screws M10X25 and relevant nuts;...
  • Page 8 COMPONENTS ASSEMBLY 4.2.1 HELP COMPONENTS ASSEMBLY • Let the arm with bead lifting disk (9) slide into its housing and tighten screw (P) with relevant washers; (fig. 11) • Remove screw (Q) and washer and loosen screws (R); (fig 11) •...
  • Page 9 4.2.2 PRESS ARM COMPONENTS ASSEMBLY • Let the arm with bead lifting disk (5) slide into its housing and tighten screw (S) with relevant washers; (fig. 13) • Connect the pneumatic hoses of control valve according to the plan; (fig. 14) •...

  • Page 10: Use

    CHAPTER 5 – USE REMOVAL OF EXTRALOW PROFILED TIRES OR RACING TIRES 5.2.1 UPPER BEAD • Lock the rim onto the turntable as shown in tire- changer’s installation, use and maintenance guide; • In case of difficulty, use the bead-pusher (4) of PRESS ARM for keeping the rim pressed onto the turntable clamps and facilitate its locking (fig.
  • Page 11 MOUNTING EXTRALOW PROFILED TIRES OR RACING TIRES 5.3.1 LOWER BEAD • Follow standard proceedings described in the installation, use and maintenance guide of tire changer. 5.3.2 UPPER BEAD • Position the tire as described by standard proceedings inside the installation, use and maintenance guide of tire changer;...

  • Page 12: Maintenance

    CHAPTER 6 – MAINTENANCE Unauthorized person is forbidden to carry out maintenance work. • Regular maintenance as described in the manual is essential for correct operation and long lifetime of the tire changer. • If maintenance is not carried out regularly, the operation and reliability of the machine may be compromised, thus placing the operator and anyone else in the vicinity at risk.
  • Page 14       ITEM CODE REF # DESCRIPTION         3014450 Rilsan hose 6X4 L=1500         4195524 Union D.6   3010896   Spiral hose 6X4 D.40 blue               3014817 YCP-3014817 Union connecting plate  ...
  • Page 15           4399228 GB/T5783 Screw M10X30 8.8   4399378   GB/T97.1   Washer D.10               3006886 YCP-3006886 Bead breaking disk   3007781   YCP-3007781   Fixing plate          ...
  • Page 16         3199601 Scraper ring 20X30X7   3008859   YCP-3008859   Piston rod               3015024 YC1-3015024 Front flange   4398146   YC1-4398146   Washer 24X30X0.5               3199599 GB/T893.1 Seeger D.30...

This manual is also suitable for:

700 series
