3.2 Assembly/Panel Removal

3.2.1 IR board Control Unit

1. Unplug the connector from the SSB.
Caution: be careful, as these are very fragile connectors!
1. Remove all the fixation screws [1] and connector from the IR board control unit.
3. Remove the IR lens, IR board from the DECO_REAR_COVER.
When defective, replace the whole unit.
Ambilight (1062)
Back cover view (65" 6262 series)
Ambilight (1063)
EXA02
Ambilight (1061)
Ambilight (1061)
ECN02
Keyboard (1057)
