Intercall L7700 IP16 Documentation page 4

L7700 LCD Display Menu Settings.
The on-board LCD screen, together with the Menu and OK buttons provides access to essential Local Area
Network and Power Supply status, together with control over the basic settings of the IP controller. In
quiescent condition, the LCD Displays INTERCALL IP and the date and time, to scroll through the menu
screens, press the Menu button to activate one of the settings press the Select/OK button.
Menu
INTERCALL IP16
17/3 10:32:12
IP ADDRESS:
192.168.0.192
SERIAL NUMBER:
1A7A0000083
FREE DISK SPACE:
100%
DC RAIL:
13.8V
BATTERY CHARGE:
DETECTED
UNIT TEMPERATURE:
25.6 Deg
FIRMWARE VERSION:
1.0.0.2
DEVICE RESET:
"OK" TO CONFIRM
FULL RESET:
"OK" TO CONFIRM
L7700 Revert to Factory Defaults.
The IP16 can be reverted to factory defaults switching the unit on while holding down the Menu button, the
following screens will appear on the LCD screen. If a new disk is inserted, the IP16 will automatically go
through this process, in which case you must press OK to the first two screens but you may retain the current
LAN settings.
Menu
DISK FORMAT
OK = Continue
CLEAR DATALOG
OK=continue MENU=skip
LAN DEFAULTS
OK=continue MENU=skip
Settings
In quiescent condition, the LCD Displays INTERCALL IP and the date and time. Press the
Menu button to move onto the next setting.
Displays the current IP address for the IP Controller. (The default IP Address when no
DHCP Server present is 192.168.0.192)
Displays the unique Serial Number / MAC Address
Displays the percentage of available Space on the Data Log,
Displays the voltage of incoming DC Supply Rail to the IP16 Printed Circuit Board
Displays the status of the sealed lead acid battery charger. A non-charging or not
connected battery will show as NOT DETECTED and a fault will be raised.
Displays the ambient temperature of the IP16 controller circuit board.
Displays the current installed software version of the IP16 controller.
Press OK button to reset all network devices connected to this controller.
Press OK button to reset IP16 controller and all network devices connected to this
controller.
Settings
Press OK to format the SD card and clear all user defined data. This screen will
automatically appear if a new SD card is fitted.
Clears all entries from the datalog, press MENU button to Skip or OK button to
continue. If this is a new SD card you must press OK to continue.
The LAN settings are held within the IP16 circuit board and not in the SD card, so if the
card is changed, the network settings can be retained. Press OK to load default
settings.
