DIGITAL Server Rackmount
Installation Guide
Part Number: ER-PCSRA-IA. E01
Digital Equipment Corporation

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ER-PCSRA-IA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Digital Equipment ER-PCSRA-IA

Summary of Contents for Digital Equipment ER-PCSRA-IA

  • Page 1 DIGITAL Server Rackmount Installation Guide Part Number: ER-PCSRA-IA. E01 Digital Equipment Corporation...
  • Page 2 The information in this document is subject to change without notice and should not be construed as a commitment by Digital Equipment Corporation. Digital Equipment Corporation assumes no responsibility for any errors that might appear in this document. The software described in this document is furnished under a license and may be used or copied only in accordance with the terms of such license.

  • Page 3: Table Of Contents

    Contents Preface Introduction........................Related Material......................Latest Product Information and Updates ............... Special Notices ......................viii Unpacking and Moving the Rackmount Before You Begin......................Dimensions........................Rackmounts Available ....................Torque Specifications ....................Unpacking........................Where to Unpack the Rackmount................How to Unpack the Rackmount ................Moving the Rackmount....................
  • Page 4 Contents Maximum Server Configuration ..................DIGITAL Server 5100/5200 and 7100 ..............2-10 DIGITAL Prioris XL Server..................2-12 DIGITAL Prioris LX Server..................2-14 DIGITAL Server 3100/3200 ..................2-16 DIGITAL Server 3100R/3200R and the 3300R............2-18 DIGITAL Server 7100R..................... 2-20 Preparing the Rackmount Introduction........................
  • Page 5 Contents Mounting the DIGITAL Server 3100R/3200R and the 3300R ........4-25 Marking the Installation Area on the Rackmount ............4-25 Attaching the Server Slide Rail Guides ..............4-27 Assemble the Slide Mounting Brackets..............4-28 Attaching Mounting Angles to the Rackmount ............4-31 Attaching Mounting Brackets with Slides to the Rackmount ........
  • Page 6 Contents Rackmount Systems and Options List Rackmount 900mm Enclosure (Base Configurations)........... Rackmount Mounting Options ..................Rackmount Shelf Options....................Rackmount Console Options..................Rackmount Cable Options..................... Rackmount - Other Options................... DIGITAL Server Mass Storage Devices................ Input/Output Devices ..................... Server Manager Platform Reset Cables................ Country Kits (Keyboard and Mouse) ................
  • Page 7 Contents 3-8. Removing the Shelf ..................... 3-15 3-9. Removing the Sliding Rail..................3-17 3-10. Removing the Shelf Support Bracket ..............3-18 3-11. Cable Management Arm on the Rackmount............3-19 3-12. Server Tray Mounting Kit..................3-20 3-13. Applying the Foam Mounting Tape..............3-21 4-1.
  • Page 8 Contents 4-33. RAID 310 Mounting Kit ..................4-56 4-34. Mounting a RAID 310 Tray and Storage Cabinet..........4-58 4-35. The DIGITAL Server 3100/3200 Split Shelf Kit............ 4-60 4-36. Attach Screws to the Shelf Support Brackets............4-62 4-37. Attach the Shelf Handles ..................4-63 4-38.

  • Page 9: Preface

    Preface Introduction This guide describes how to unpack the rackmount. It details the initial setup of the rackmount and demonstrates how to install various hardware needed to create a variety of rackmount server configurations. Information about installing various server components are also included in this guide. The information presented will help to familiarize you with all aspects of your rack and provide a reference tool for questions you might have in the future.

  • Page 10: Special Notices

    Preface Special Notices Three kinds of special notices are used in this Installation Guide to emphasize specific information. WARNING: Indicates the presence of a hazard that can cause personal injury if the hazard is not avoided. CAUTION: Indicates the presence of a hazard that might cause damage to hardware.

  • Page 11: Unpacking And Moving The Rackmount

    Unpacking and Moving the Rackmount Before You Begin Select a suitable area for assembly and use. Make sure your workspace: • Is free from excessive heat, dust, and direct sunlight • Allows at least 30 inches of clearance at the rear of the unit and 60 inches at the front of the unit •...

  • Page 12: Dimensions

    Unpacking and Moving the Rackmount Dimensions Description 800mm x 42U 900mm x 42U Width 61 cm (24 in.) 61 cm (24 in.) Height 213.4 cm (84 in.) 213.4 cm (84 in.) Depth 81.3 cm (32 in.) 90 cm (35.43 in.) Weight (with four shelves) 179.6 kg (396 lb) Weight (with two shelves)

  • Page 13: Unpacking

    Unpacking and Moving the Rackmount Unpacking The following sections describe where and how to unpack the rackmount. Where to Unpack the Rackmount Where you unpack the rackmount is dependent upon whether or not your facility has adequate door clearance to move it to the site without tilting it. If your facility has adequate door clearance, use a forklift to move the rackmount to the site before removing the packing material and rolling it off the pallet.

  • Page 14: How To Unpack The Rackmount

    Unpacking and Moving the Rackmount How to Unpack the Rackmount To unpack the rackmount: Remove the four corrugated corners, and then the plastic bag from the rackmount (see Figure 1-1). We recommend saving the packing material in case the unit needs to be repacked at a later date. The 800mm rackmount is banded to the skid.
  • Page 15 Unpacking and Moving the Rackmount 3. Pull down the hinged ramp and place it on the floor (see Figure 1-2). DEC02031 Figure 1-2. Pulling Down the Ramp...

  • Page 16: Moving The Rackmount

    Unpacking and Moving the Rackmount Moving the Rackmount The following sections describe how to move the rackmount, raise and lower the leveling feet, and tilt the rackmount. Moving the Rackmount to the Final Site The rackmount is equipped with rollers so it can be easily moved to the site. However, before moving the rackmount you must first raise the leveling feet to allow free movement of the rollers.
  • Page 17 Unpacking and Moving the Rackmount 2. Using at least two people, carefully roll the rackmount off the pallet (see Figure 1-4). DEC02032 Figure 1-4. Rolling the Rackmount Off the Pallet...

  • Page 18: Tilting The Rackmount

    Unpacking and Moving the Rackmount 3. Roll the rackmount to the site. 4. Using a wrench, lower the leveling feet (turn the leveling feet clockwise). CAUTION: Make sure the rackmount is level and that its full weight rests on the leveling feet and not the rollers. Tilting the Rackmount If the rackmount must be tilted to gain access through a door, it is recommended that it be tilted backward to keep the shelves from sliding against the front door.

  • Page 19: Typical Rackmount Configurations

    Typical Rackmount Configurations Introduction This chapter provides typical rackmount configurations for the complete line of DIGITAL Servers. These typical configurations portray basic rackmount and shelf rackmount configurations. Your specific configuration might differ. NOTE: All measurements in the following sections are in units of “U.”...

  • Page 20: U" Requirements

    Typical Rackmount Configurations “U” Requirements Component “U” Measurement DIGITAL Server Rackmount DIGITAL Server 3100/3200 DIGITAL Server 3100R/3200R DIGITAL Server 3300R DIGITAL Server 5100/5200 DIGITAL Server 7100 DIGITAL Server 7100R DIGITAL Prioris XL Server DIGITAL Prioris LX Server BA356 storage cabinet RAID 310 storage cabinet RAID 450 storage cabinet 14-inch monitor...

  • Page 21: Digital Server Rackmount Components

    Typical Rackmount Configurations DIGITAL Server Rackmount Components The following sections describe the rackmount components, base configurations and rackmount options. A detailed system and options list, with part numbers, for the rackmount family is located in Appendix A. Figure Component Legend Fan tray Side panels (2) Cable management arms (4 with the RN/RA configuration)
  • Page 22 Typical Rackmount Configurations DEC02058 Figure 2-1. Basic Rackmount Components...

  • Page 23: 42U X 800Mm Base Configuration With Shelving

    Typical Rackmount Configurations 42U x 800mm Base Configuration with Shelving The following parts are included in the base configuration kit. Figure Component Legend Shelves (4) Documentation Cable rings (10) Grounding kit 19 inch mounting angles (four 12U and four 4U) Cable ties Posts (20) Keys...
  • Page 24 Typical Rackmount Configurations DEC01111 Figure 2-2. 42U x 800mm Base Configuration with Shelving...

  • Page 25: 42U X 900Mm Base Configuration

    Typical Rackmount Configurations 42U x 900mm Base Configuration The following parts are included in the base configuration kit (FR-PCSRA-RC/RD). Figure Component Legend Documentation Grounding kit Cable rings (10) Cable ties Posts (12) Keys Video (for assembly) Mounting angles, 12 (14U) total: three for each corner...
  • Page 26 Typical Rackmount Configurations DEC02059 Figure 2-3. 42U x 900mm Base Configuration...

  • Page 27: Maximum Server Configuration

    Typical Rackmount Configurations Maximum Server Configuration Without Monitor, With Monitor, Server Keyboard, and Console Keyboard, and Console Type in Rackmount in Rackmount DIGITAL Server 3100/3200 DIGITAL Server 3100R/3200R DIGITAL Server 3300R DIGITAL Server 5100/5200 DIGITAL Server 7100 DIGITAL Server 7100R DIGITAL Prioris XL Server DIGITAL Prioris LX Server...

  • Page 28: Digital Server 5100/5200 And 7100

    Typical Rackmount Configurations DIGITAL Server 5100/5200 and 7100 Figure 2-4 shows a typical rackmount configuration using three DIGITAL Servers, a monitor, console, keyboard, and mouse. The following table identifies each part. Figure Component Dimension Legend DIGITAL Server Rackmount 14-inch monitor 9U (may differ) Universal shelf (5) DIGITAL Server 5100/5200 and...

  • Page 29: Typical Digital Server 5100/5200 And 7100 Rackmount Configuration

    Typical Rackmount Configurations DEC01115-3 Figure 2-4. Typical DIGITAL Server 5100/5200 and 7100 Rackmount Configuration 2-11...

  • Page 30: Digital Prioris Xl Server

    Typical Rackmount Configurations DIGITAL Prioris XL Server Figure 2-5 shows a typical rackmount configuration using five DIGITAL Prioris XL servers, a monitor, console, keyboard, and mouse. The following table identifies each part. Figure Component Dimension Legend DIGITAL Server Rackmount 15-inch monitor 9.5U (may differ) Universal shelf (7) DIGITAL Prioris XL Server (5)

  • Page 31: Typical Digital Prioris Xl Server Rackmount Configuration

    Typical Rackmount Configurations DEC01117-3 Figure 2-5. Typical DIGITAL Prioris XL Server Rackmount Configuration 2-13...

  • Page 32: Digital Prioris Lx Server

    Typical Rackmount Configurations DIGITAL Prioris LX Server Figure 2-6 shows a typical rackmount configuration using five DIGITAL Prioris LX servers, a monitor, console, keyboard, and mouse. The following table identifies each part. Figure Component Dimension Legend DIGITAL Server Rackmount 15-inch monitor 9.5U (may differ) Universal shelf (7) DIGITAL Prioris LX Server (5)

  • Page 33: Typical Digital Prioris Lx Server Rackmount Configuration

    Typical Rackmount Configurations DEC01116-3 Figure 2-6. Typical DIGITAL Prioris LX Server Rackmount Configuration 2-15...

  • Page 34: Digital Server 3100/3200

    Typical Rackmount Configurations DIGITAL Server 3100/3200 Figure 2-7 shows a typical rackmount configuration using four DIGITAL Servers, a monitor, console, keyboard, and mouse. The following table identifies each part. Figure Component Dimension Legend DIGITAL Server Rackmount 15-inch monitor 9.5U (may differ) Universal shelf (2) Split shelf DIGITAL Server 3100/3200 (4)

  • Page 35: Typical Digital Server 3100/3200 Rackmount Configuration

    Typical Rackmount Configurations DEC02060-3 Figure 2-7. Typical DIGITAL Server 3100/3200 Rackmount Configuration 2-17...

  • Page 36: Digital Server 3100R/3200R And The 3300R

    Typical Rackmount Configurations DIGITAL Server 3100R/3200R and the 3300R Figure 2-8 shows a typical rackmount configuration using two DIGITAL Servers, a monitor, console, keyboard, mouse, tape backup, disk storage array, and an optional Uninterruptible Power Supply (UPS). The following table identifies each part. Figure Component Dimension...

  • Page 37: Typical Digital Server 3100R/3200R And The 3300R Rackmount Configuration

    Typical Rackmount Configurations DEC02065-2 Figure 2-8. Typical DIGITAL Server 3100R/3200R and the 3300R Rackmount Configuration 2-19...

  • Page 38: Digital Server 7100R

    Typical Rackmount Configurations DIGITAL Server 7100R Figure 2-9 shows a typical rackmount configuration using two DIGITAL Servers, a monitor, console, keyboard, mouse, tape backup, disk storage array, and an optional Uninterruptible Power Supply (UPS). The following table identifies each part. Figure Component Dimension...
  • Page 39 Typical Rackmount Configurations DEC02068-2 Figure 2-9. Typical DIGITAL Server 7100R Rackmount Configuration 2-21...

  • Page 40: Preparing The Rackmount

    Preparing the Rackmount Introduction This chapter describes how to open the rackmount’s front and rear doors, remove side panels, adjust shelves, and install shelves as required. Required Tools • Medium Phillips screwdriver • Medium slotted (flat-head) screwdriver • Adjustable wrench •...

  • Page 41: Unlocking The Rackmount Front And Rear Doors

    Preparing the Rackmount Unlocking the Rackmount Front and Rear Doors To open the front and rear door of the rackmount unit: 1. Push the slide unit up (1, Figure 3-1). 2. Insert the key and turn it clockwise (2, Figure 3-1). 3.
  • Page 42 Preparing the Rackmount DEC01118 Figure 3-1. Opening the Rackmount Front and Rear Door...

  • Page 43: Removing The Rackmount Side Panels

    Preparing the Rackmount Removing the Rackmount Side Panels WARNING: Be extremely careful when removing the side panels, especially if you have components mounted in the rackmount. Removing the side panels causes the rackmount to lose some structural integrity which can result in severe personal injury or equipment damage.

  • Page 44: Removing The Rackmount Side Panels

    Preparing the Rackmount Figure 3-2. Removing the Rackmount Side Panels...

  • Page 45: Adding Side Panel Locks

    Preparing the Rackmount Adding Side Panel Locks The side panels have six captive screw retainers which hold the panels to the cabinet. Side panel key locks allow you to make your cabinet more secure. Two side panel key locks are used for each panel. NOTE: Put one lock on each side of the cabinet panel.

  • Page 46: Adding A Side Panel Lock

    Preparing the Rackmount DEC02033 Figure 3-3. Adding a Side Panel Lock...

  • Page 47: Installing Universal Shelves

    Preparing the Rackmount Installing Universal Shelves To install a universal shelf: 1. Choose the correct bracket for your rackmount. There are two bracket sizes supplied, a shorter one for the 800mm rackmount and a longer one for the 900mm rackmount. 2.

  • Page 48: Installing The Shelf Support Bracket (800Mm Rackmount Shown)

    Preparing the Rackmount DEC01125-2 Figure 3-4. Installing the Shelf Support Bracket (800mm Rackmount Shown)
  • Page 49 Preparing the Rackmount 6. Perform the following to attach the sliding rails: Engage the latch at the rear of the slide into the 6 th hole from the rear of the shelf support bracket. For the 900mm bracket, use the middle row of holes.

  • Page 50: Installing The Sliding Rails

    Preparing the Rackmount DEC01139-2 Figure 3-5. Installing the Sliding Rails 3-11...
  • Page 51 Preparing the Rackmount 7. Extend the sliding rails all the way out and securely place the shelf onto them. Attach the rail using the four screws (two on each side). 8. Attach the cable management arm to the back of the shelf (see Figure 3-7). 9.

  • Page 52: Adjusting Shelves (800Mm Rackmount)

    Preparing the Rackmount Adjusting Shelves (800mm Rackmount) The 42U x 800mm version of the rackmount comes with four movable shelves. Before adjusting any shelf, check to see if it is already in a place that fits your particular mounting configuration. To adjust a shelf: 1.
  • Page 53 Preparing the Rackmount DEC01126A Figure 3-7. Removing the Cable Management Arm from the Shelf 3-14...
  • Page 54 Preparing the Rackmount 4. Remove the four screws (A, Figure 3-8) holding the shelf to the sliding rail (two screws on each side). NOTE: The shelf has to be out all the way on the slides to be able to get at the screws. 5.
  • Page 55 Preparing the Rackmount 6. Remove the sliding rail by: Lifting up the front part (A, Figure 3-9) so that the latch disengages from the shelf support bracket. Pulling the rail towards the front of the rackmount to disengage the rear latch (B, Figure 3-9) . Pulling off the side rail (C, Figure 3-9).
  • Page 56 Preparing the Rackmount DEC01139-3 Figure 3-9. Removing the Sliding Rail 3-17...
  • Page 57 Preparing the Rackmount 7. Remove the screws holding the shelf support bracket to the U-nuts to remove the shelf support bracket. Turn each of the four screws (A, Figure 3-10) counterclockwise. 8. Remove the shelf support bracket (B, Figure 3-10) 9.
  • Page 58 Preparing the Rackmount 10. Remove the two screws securing the cable management arm and bracket to the U-nuts (A, Figure 3-11). 11. Adjust the U-nuts to the desired position. 12. Secure the cable management arm to the U-nuts using the previously removed screws.

  • Page 59: Server Mounting Tray(S) Assembly

    Preparing the Rackmount Server Mounting Tray(s) Assembly Server mounting kits can be used with the DIGITAL Server 5100/5200 and 7100 and the DIGITAL Prioris LX and XL Servers. The following table identifies each kit part. Figure Component Legend Wing nuts Flat washers Lock washers Tray (trays for each model are different sizes)
  • Page 60 Preparing the Rackmount 1. Cut the foam to size as required. 2. Apply the foam mounting tape to the tray as shown. DEC02035 Figure 3-13. Applying the Foam Mounting Tape 3-21...

  • Page 61: Mounting Server Components

    Mounting Server Components Introduction This chapter describes how to mount your DIGITAL Servers, monitor, console, keyboard, and mouse into the rackmount. Note that the following procedures are based on the typical rackmount configurations described in Chapter 2 and that your specific configuration might differ.

  • Page 62: Mounting The Digital Server 5100/5200 And 7100

    Mounting Server Components WARNING: Make sure you extend the rackmount stabilizer before you install any component. Also, make sure you install the heaviest components starting at the bottom. Failure to do so may cause the rackmount to tip forward which could result in severe personal injury or equipment damage.
  • Page 63 Mounting Server Components DEC01127 Figure 4-1. Attaching a DIGITAL Server 5100/5200 and 7100 Mounting Tray WARNING: Use extreme care when lifting the server. Due to its weight, two people are required to lift it. Failure to use at least two people may result in severe personal injury as well as violate certain safety regulations.
  • Page 64 Mounting Server Components 6. Using two people, carefully lift and place the servers onto the appropriate mounting trays. Make sure the stabilizer (A, Figure 4-2) is positioned as shown. Also, note that the servers are not bolted to the trays. 7.

  • Page 65: Mounting The Digital Prioris Xl Server

    Mounting Server Components Mounting the DIGITAL Prioris XL Server To install the DIGITAL Prioris XL Server into the rackmount, do the following: 1. Open the front and rear doors. 2. Extend the rackmount stabilizer and adjust the leveling feet as required. 3.
  • Page 66 Mounting Server Components 5. Attach the server mounting trays (A, Figure 4-3) onto the appropriate universal shelves in the rackmount. DEC01137 Figure 4-3. Attaching a DIGITAL Prioris XL Server Mounting Tray...
  • Page 67 Mounting Server Components 6. Carefully lift and place the servers onto the appropriate mounting trays. Make sure the stabilizer (A, Figure 4-4) is positioned as shown. Also, note that the servers are not bolted to the trays. 7. Return the rackmount stabilizer to its original position. 8.

  • Page 68: Mounting The Digital Prioris Lx Server

    Mounting Server Components Mounting the DIGITAL Prioris LX Server To install the DIGITAL Prioris LX Server into the rackmount, do the following: 1. Open the front and rear doors. 2. Extend the rackmount stabilizer and adjust the leveling feet as required. 3.
  • Page 69 Mounting Server Components DEC01129 Figure 4-5. Attaching a DIGITAL Prioris LX Server Mounting Tray...
  • Page 70 Mounting Server Components 6. Carefully lift and place the servers onto the appropriate mounting trays making sure that the stabilizer is positioned as shown. Note that the servers are not bolted to the trays. 7. Return the rackmount stabilizer to its original position. 8.
  • Page 71 Mounting Server Components DEC01130 Figure 4-6. Installing a DIGITAL Prioris LX Server Server into the Rackmount 4-11...

  • Page 72: Mounting The Digital Server 7100R

    Mounting Server Components Mounting the DIGITAL Server 7100R To install the DIGITAL Server 7100R into the rackmount, do the following: 1. Open the front and rear doors. 2. Extend the rackmount stabilizer and adjust the leveling feet as required. 3. Remove the two slide inserts from the slides that came with your server. Marking the Installation Area on the Rackmount 1.
  • Page 73 Mounting Server Components DEC02072 Figure 4-7. Marking the Installation Area on the Rackmount 4-13...

  • Page 74: Assemble The Slide Mounting Brackets

    Mounting Server Components Assemble the Slide Mounting Brackets 1. Attach the two sets of mounting brackets to each end of the slide making sure that the two holes are exposed at the end (Figure 4-8). At the other end of the slide (Figure 4-9), insert the screws through the large hole, one screw at a time.
  • Page 75 Mounting Server Components DEC02071 Figure 4-8. Attaching the Rear Mounting Bracket 4-15...
  • Page 76 Mounting Server Components 3. Attach the front mounting bracket: a. Move the slide assembly down so that the two holes are visible (Figure 4-9). b. Place the two screws through the 3-inch slot of the mounting bracket. c. Place the two screws through each hole in the slide. d.

  • Page 77: Attaching Mounting Angles To The Rackmount

    Mounting Server Components Attaching Mounting Angles to the Rackmount If the rackmount does not already have pre-installed mounting angles, complete the following steps: 1. Attach the mounting angles (see Figure 4-10) to the rackmount: a. Locate three equally distributed points for attaching each angle to the rackmount (A, Figure 4-10).
  • Page 78 Mounting Server Components DEC02081 Figure 4-10. Attaching the Mounting Angles 4-18...

  • Page 79: Attaching Slide Mounting Brackets To The Rackmount

    Mounting Server Components Attaching Slide Mounting Brackets to the Rackmount 1. Attach the two slides to the mounting angles: a. Locate the position for the slides at the front and rear mounting angles. b. Insert two screws and plastic cup washers through the washer plate, through the mounting rail, and then through each end of the slide bracket (see Figure 4-11).
  • Page 80 Mounting Server Components DEC02075 Figure 4-11. Attaching the Slides to the Mounting Angles 4-20...

  • Page 81: Inserting The Digital Server 7100R Into The Rackmount

    Mounting Server Components Inserting the DIGITAL Server 7100R into the Rackmount 1. Attach the two slide rail guides to the server using four screws. DEC01332 Figure 4-12. Attaching the Slide Rail Guides 4-21...
  • Page 82 Mounting Server Components WARNING: Use extreme care when lifting the server. Due to its weight, two people are required to lift it. Failure to use at least two people may result in severe personal injury as well as violate certain safety regulations. This could also result in equipment damage.

  • Page 83: Attaching The Digital Server 7100R Cable Management Arm

    Mounting Server Components Attaching the DIGITAL Server 7100R Cable Management Arm To attach the cable management arm: 1. Install the cable arm bracket to the inside of the chassis using three flat-head screws (A, Figure 4-14). 2. Attach the shorter of the cable management arms to the bracket using two pan-head screws (B, Figure 4-14).
  • Page 84 Mounting Server Components DEC02064 Figure 4-14. Attaching the DIGITAL Server 7100R Cable Management Arm 4-24...

  • Page 85: Mounting The Digital Server 3100R/3200R And The 3300R

    Mounting Server Components Mounting the DIGITAL Server 3100R/3200R and the 3300R To install the DIGITAL Server 3100R/3200R and the 3300R into the rackmount, do the following: 1. Open the front and rear doors. 2. Extend the rackmount stabilizer and adjust the leveling feet as required. Marking the Installation Area on the Rackmount 1.
  • Page 86 Mounting Server Components DEC02072 Figure 4-15. Marking the Installation Area on the Rackmount 4-26...

  • Page 87: Attaching The Server Slide Rail Guides

    Mounting Server Components Attaching the Server Slide Rail Guides 1. Secure one of the slide rail guides to the server using three screws. 2. Attach the remaining slide rail guide. DEC02069 Figure 4-16. Attaching the Slide Rail Guides 4-27...

  • Page 88: Assemble The Slide Mounting Brackets

    Mounting Server Components Assemble the Slide Mounting Brackets 1. Attach the two sets of mounting brackets to each end of the slide making sure that the two holes are exposed at the end (Figure 4-17). At the other end of the slide (Figure 4-18), insert the screws through the large hole, one screw at a time.
  • Page 89 Mounting Server Components DEC02071 Figure 4-17. Attaching the Rear Mounting Bracket 4-29...
  • Page 90 Mounting Server Components 3. Attach the front mounting bracket: a. Move the slide assembly down so that the two holes are visible (Figure 4-18). b. Place the two screws through the 3-inch slot of the mounting bracket. c. Place the two screws through each hole in the slide. d.

  • Page 91: Attaching Mounting Angles To The Rackmount

    Mounting Server Components Attaching Mounting Angles to the Rackmount If the rackmount does not already have pre-installed mounting angles, complete the following steps: 1. Attach the three mounting angles (see Figure 4-19) to the rackmount by: a. Locating three equally distributed points for attaching each angle to the rackmount (A, Figure 4-19).
  • Page 92 Mounting Server Components DEC02081 Figure 4-19. Attaching the Mounting Angles 4-32...

  • Page 93: Attaching Mounting Brackets With Slides To The Rackmount

    Mounting Server Components Attaching Mounting Brackets with Slides to the Rackmount Attach the two slides to the mounting angles: 1. Locate the position for the slides at the front and rear mounting angles. 2. Insert two screws and two plastic cup washers through the washer plate, through the mounting rail, and then through each end of the slide bracket (see Figure 4-20).
  • Page 94 Mounting Server Components DEC02082 Figure 4-20. Attaching the Slides to the Mounting Angles 4-34...

  • Page 95: Inserting The Digital Server 3100R/3200R And The 3300R Into The Rackmount

    Mounting Server Components Inserting the DIGITAL Server 3100R/3200R and the 3300R into the Rackmount WARNING: Use extreme care when lifting the server. Due to its weight, two people are required to lift it. Failure to use at least two people may result in severe personal injury as well as violate certain safety regulations.
  • Page 96 Mounting Server Components DEC02073 Figure 4-21. Inserting the DIGITAL Server 3100R/3200R and 3300R into the Rackmount 4-36...

  • Page 97: Attaching The Digital Server 3100R/3200R And 3300R Cable Management Arm

    Mounting Server Components Attaching the DIGITAL Server 3100R/3200R and 3300R Cable Management Arm Attach the cable management arm: 1. Install the cable management arm bracket to the inside of the chassis using two pan-head screws (M4x10mm lg) (A, Figure 4-22). 2.
  • Page 98 Mounting Server Components DEC02074 Figure 4-22. Attaching the DIGITAL Server 3100R/3200R and 3300R Cable Management Arm 4-38...

  • Page 99: Mounting A Monitor, Console, Or Keyboard (800Mm Rackmount)

    Mounting Server Components Mounting a Monitor, Console, or Keyboard (800mm Rackmount) The monitor, keyboard, and console are not attached to the shelf, they sit on the shelf and are braced for stability with the enclosed posts. To install a monitor, console, or keyboard, do the following: 1.
  • Page 100 Mounting Server Components DEC01170 Figure 4-23. Mounting a Monitor, Console, and Keyboard (800mm Rackmount) 4-40...

  • Page 101: Mounting A Mouse Shelf (800Mm Rackmount)

    Mounting Server Components Mounting a Mouse Shelf (800mm Rackmount) To attach a mouse shelf, do the following: 1. Place the lock washer (B, Figure 4-24), washer (C, Figure 4-24), and non- threaded nylon spacer (H, Figure 4-24) on the bolt (I, Figure 4-24). 2.

  • Page 102: Mouse Shelf Parts

    Mounting Server Components Mouse Shelf Parts Figure Component Legend Lock washers (2) Washers (2) Spacer (threaded) Ball bearings (2) Spring Mouse shelf Spacer (non-threaded) Bolt 4-42...
  • Page 103 Mounting Server Components DEC02036 Figure 4-24. Mounting the Mouse Shelf (800mm) 4-43...

  • Page 104: Installing A Keyboard Drawer (900Mm Rackmount)

    Mounting Server Components Installing a Keyboard Drawer (900mm Rackmount) Install a keyboard drawer for the 16-inch keyboard and mouse into a 900mm rackmount by attaching the keyboard drawer to the two front mounting angles. The following components make up the keyboard drawer. Figure Legend Component Mouse shelf...
  • Page 105 Mounting Server Components DEC02080 Figure 4-25. Installing the Keyboard Drawer 4-45...

  • Page 106: Mounting Ba356 Storage Cabinets

    Mounting Server Components Mounting BA356 Storage Cabinets To install BA356 storage cabinets, do the following: 1. Open the front and rear doors. 2. If necessary, adjust all required shelves. 3. Attach the four 19-inch mounting angles at each corner of the rackmount (A, Figure 4-26).
  • Page 107 Mounting Server Components DEC01198 Figure 4-26. Attaching the 19-inch Mounting Angles and Chassis Support Rails 4-47...
  • Page 108 Mounting Server Components 5. Mount the supplied bracket (A, Figure 4-27) to the 19-inch mounting angle by placing the threaded bar behind the 19-inch mounting angle (B, Figure 4-27), and using the supplied screws (C, Figure 4-27). Mount the clamp to the rear of the unit (D, Figure 4-27) with the supplied screw (E, Figure 4-27).
  • Page 109 Mounting Server Components 7. Slide the BA356 storage cabinet into the bracket. 8. Mount the clamp to the front of the unit (E, Figure 4-28) using the supplied screw (F, Figure 4-28). DEC02002 Figure 4-28. Mounting a BA356 Storage Cabinet 4-49...

  • Page 110: Mounting Ba356 Storage Cabinets (Alternate Method)

    Mounting Server Components Mounting BA356 Storage Cabinets (Alternate Method) To install BA356 storage cabinets, do the following: 1. Open the front and rear doors. 2. Review the rackmount for space availability. Allow a distance of at least 4U for each BA356 storage cabinet. 3.
  • Page 111 Mounting Server Components DEC02081 Figure 4-29. Attaching the 19-inch Mounting Angles 4-51...
  • Page 112 Mounting Server Components 5. Mount the supplied bracket (2, Figure 4-30) to the 19-inch mounting angle by placing the rail behind the 19-inch mounting angle (1, Figure 4-30), and using three self-threaded screws and washers (1, Figure 4-30). DEC02077 Figure 4-30. Attaching a BA356 Storage Cabinet Mounting Bracket 6.
  • Page 113 Mounting Server Components DEC02078 Figure 4-31. Attaching a BA356 Storage Cabinet Mounting Bracket 4-53...
  • Page 114 Mounting Server Components 8. Slide the BA356 storage cabinet into the bracket (1, Figure 4-32). 9. Mount the clamp to the front of the unit (2, Figure 4-32) using the supplied screw. DEC02079 Figure 4-32. Mounting a BA356 Storage Cabinet 4-54...

  • Page 115: Mounting Raid 310 Storage Cabinets

    Mounting Server Components Mounting RAID 310 Storage Cabinets The RAID 310 mounting kit includes hardware necessary to install a RAID 310 tray and storage cabinet onto a universal shelf. The following table identifies each kit part. Figure Component Legend RAID 310 storage box RAID 310 tray Aluminum spacers (4) Lock washers (4)
  • Page 116 Mounting Server Components DEC02037 Figure 4-33. RAID 310 Mounting Kit 4-56...
  • Page 117 Mounting Server Components To install RAID 310 cabinets, do the following: 1. Place the RAID 310 tray on the universal shelf to locate the mounting holes. 2. Slightly lift each corner and slide the aluminum spacers over the threaded studs on the bottom of the RAID 310 tray (C, Figure 4-34). 3.
  • Page 118 Mounting Server Components DEC02000 Figure 4-34. Mounting a RAID 310 Tray and Storage Cabinet 4-58...

  • Page 119: Installing A Digital Server 3100/3200 Split Shelf

    Mounting Server Components Installing a DIGITAL Server 3100/3200 Split Shelf The DIGITAL Server 3100/3200 requires installation of a special split shelf. The following table identifies each split shelf kit part. Figure Component Legend System bar with installing brackets (1) Shelf support bracket for 900mm rackmount (2) Shelf support bracket for 800mm rackmount (2) Split shelf with cable management arms (1) Shelf handles (2)
  • Page 120 Mounting Server Components DEC02038 Figure 4-35. The DIGITAL Server 3100/3200 Split Shelf Kit 4-60...
  • Page 121 Mounting Server Components Perform the following procedure to install the DIGITAL Server 3100/3200 split shelf: 1. Attach the screws that hold the two shelf support brackets to the cabinet using U- nuts. Use a torque value of 4.9 N . m when adding this CAUTION: bracket to prevent skewing of the rackmount.
  • Page 122 Mounting Server Components DEC01125-2 Figure 4-36. Attach Screws to the Shelf Support Brackets 4-62...
  • Page 123 Mounting Server Components 3. Using 4 screws (two for each tray), attach the two shelf handles to the sliding trays. DEC02039 Figure 4-37. Attach the Shelf Handles 4-63...
  • Page 124 Mounting Server Components 4. Attach the split shelf to the two shelf support brackets using the eight bolts and nuts in the kit. DEC02040 Figure 4-38. Attach the Split Shelf to the Brackets 4-64...
  • Page 125 Mounting Server Components 5. Push the two brackets for the system bar in and back to secure (A, Figure 4-39). You may need to tap each bracket into place. Screw in self tapping screw into shelf support brackets (B, Figure 4-39). Using two flat washers (D, Figure 4-39), bolts (C, Figure 4-39), and threaded blocks (E, Figure 4-39), install the system bar (F, Figure 4-39) onto the back of the shelf support brackets.
  • Page 126 Mounting Server Components 6. Using two self tapping screws (A, Figure 4-40), attach the back bracket of the cable management arm (B, Figure 4-40) to the system bar (C, Figure 4-40). NOTE: The cable management arm should line up straight between the tray and the management arm.
  • Page 127 Mounting Server Components 7. Attach the two brackets to the bottom of the server using the four screws contained in the kit. DEC02043 Figure 4-41. Attach Bottom Brackets 8. With the two brackets on the bottom of the server, push the four threaded studs through the four holes in the tray.
  • Page 128 Mounting Server Components DEC02044 Figure 4-42. Attach Server to Tray 4-68...

  • Page 129: Connecting Rackmount Bays Together

    Mounting Server Components Connecting Rackmount Bays Together Larger structures can be constructed by combining two or more rackmount bays together. The following table identifies each part. Figure Component Quantity Legend U-nuts Screws Lock washers Baying brackets Foam tape 1 roll DEC02045 Figure 4-43.
  • Page 130 Mounting Server Components To connect two or more rackmounts together, perform the following procedure: NOTE: Before you begin, make sure the rackmounts are level with each other. 1. Open the front and rear doors of the rackmounts. 2. Remove the side panels from the sides that will be joined. 3.
  • Page 131 Mounting Server Components DEC02001 Figure 4-44. Connecting Rackmounts Together 4-71...

  • Page 132: Installing The Raid 450 Storage Cabinet

    Mounting Server Components Installing the RAID 450 Storage Cabinet Perform the following steps to install the RAID 450 storage cabinet. WARNING: The RAID 450 storage cabinet is heavy. Use two people to install it. You must mount the RAID 450 storage cabinet on the bottom of the rackmount.
  • Page 133 Mounting Server Components 2. Attach two mounting angles to the front, and two to the back of the cabinet. DEC02062 Figure 2-46. Attach Mounting Angles 4-73...
  • Page 134 Mounting Server Components 3. Select the proper hole placements. See Figure 4-47 for the front of the cabinet and Figure 4-48 for the rear of the cabinet. DEC2050A Figure 4-47. Front of Cabinet 4-74...
  • Page 135 Mounting Server Components DEC2050B Figure 4-48. Rear of Cabinet 4-75...
  • Page 136 Mounting Server Components 4. Attach the two slide rails to each side using the locations shown in step 3. DEC02048 Figure 4-49. Attach Slide Rails (Rear View) 4-76...
  • Page 137 Mounting Server Components 5. Attach the slide rails as shown in Figure 4-50. a. Insert and secure two front screws into the mounted nuts (A, Figure 4-50). b. Insert and secure one rear screw with the supplied washers and nuts (B, Figure 4-50).
  • Page 138 Mounting Server Components 6. With at least two people, lift the RAID 450 storage cabinet. Connect the internal part of the slides (the ones that are attached to the cabinet) to the external part of the sliding rails (the ones that are attached to the rackmount) and then push the unit to the rear until it stops.

  • Page 139: Installing Blanking Panels

    Mounting Server Components Installing Blanking Panels Four blanking panels are available that allow you to cover unused space in the front of the rackmount. These blanking panels are currently available: 1U, 2U, 4U, and 8U. To cover unused space with a blanking panel do the following: 1.

  • Page 140: Connecting Components

    Connecting Components Introduction This chapter describes how to connect your DIGITAL Servers, monitor, keyboard, and mouse to the console. Note that the following procedures are using a DIGITAL Server 7100 as an example, your specific configuration might differ. NOTE: The intent of this section is to provide an overview of connecting DIGITAL Servers to a console.

  • Page 141: Connecting The Ps/2 Mouse Cable

    Connecting Components Connecting the PS/2 Mouse Cable To connect the PS/2 mouse cable to your server or console, do the following: 1. Open the rear door. 2. Connect the PS/2 mouse cable connector (C, Figure 5-1) to the left-most PS/2 mouse port (A, Figure 5-1) at the rear of the 8-port console. 3.
  • Page 142 Connecting Components DEC01131 Figure 5-1. Connecting the PS/2 Mouse Cable...

  • Page 143: Connecting The Video And Keyboard Cable

    Connecting Components Connecting the Video and Keyboard Cable To connect the video and keyboard cable to your server or console, do the following: 1. Open the rear door. 2. Connect the top video and keyboard cable (A, Figure 5-2) to the video and keyboard ports at the rear of the top and middle servers (a DIGITAL Server 7100 is used as an example).
  • Page 144 Connecting Components DEC01132 Figure 5-2. Connecting the Video/Keyboard Cables...

  • Page 145: Connecting A Remote Masterconsole (Single)

    Connecting Components Connecting A Remote MasterConsole (Single) A MasterConsole Remote panel (MCPRMT) may be connected to a MasterConsole as follows. For more information on connecting RemoteMaster consoles, see the MasterConsole User’s Manual. Cable Kit MCPRMT16M for Single Remote MasterConsole (Remote) Figure Component Legend...
  • Page 146 Connecting Components Remote Local DEC02053 Figure 5-3. Connecting a Remote MasterConsole...

  • Page 147: Connecting The Power Cords

    Connecting Components Connecting the Power Cords Connect the power cords to the servers and console as shown in Figure 5-4. Connect the power cords to the servers first, then connect the other end of the power cords to the distribution panel. NOTE: To maximize power supply redundancy, connect the power supply cords for each server to different power...
  • Page 148 Connecting Components DEC01134 Figure 5-4. Connecting Power Cords...

  • Page 149: Cabinet Grounding

    Connecting Components Cabinet Grounding The cabinet grounding kit contains pre-cut and crimped wires of various lengths with a combination of open end, slide, and round end crimps. The following table identifies each kit part. NOTE: Many of the parts may not be needed or can be used at a later time.
  • Page 150 Connecting Components Figure Component Quantity Legend A8.4 M8x20 Crimp Ground decal M6x16 mounting screw DEC02056 Figure 5-5. Cabinet Grounding Kit Use the following procedure to connect the ground strip to your cabinet: 1. Screw the plastic ground strip mounts (A, Figure 5-6) to the cabinet frame using U-nuts.
  • Page 151 Connecting Components 3. Connect one of the ground wires (C, Figure 5-6) to the cabinet frame by using a U-nut. DEC02057 Figure 5-6. Grounding the Cabinet 5-12...

  • Page 152: Connecting The Monitor, Keyboard, And Mouse To A Console

    Connecting Components Connecting the Monitor, Keyboard, and Mouse to a Console Figure 5-7 shows how to connect the monitor, keyboard, and mouse to the console. DEC01135 Figure 5-7. Connecting the Monitor, Keyboard, and Mouse 5-13...

  • Page 153: Routing Your Cables

    Connecting Components Routing your Cables Figure 5-8 shows how to route your cables after connecting your DIGITAL Servers, monitor, console, keyboard, and mouse. NOTE: The cable management arm has holes that are used to secure the cables with the tie-wraps. This ensures that the cables are not damaged when the shelf is pulled out.
  • Page 154 Connecting Components DEC01136 Figure 5-8. Rackmount Cable Routing 5-15...

  • Page 155: Power Requirements

    Power Requirements Introduction WARNING: Do not overload the ac power circuit that provides power to the rackmount. Contact the electrician responsible for your facility wiring and installation requirements. You must have the electrician responsible for your facility wiring to: • Supply ac power •...

  • Page 156: Power Ratings

    Rackmount Systems and Options List Power Ratings Server/Storage Voltage Range Voltage Rated Input Operation Device (V ac) Maximum (V ac) Current (A) Frequency Range (Hz) DIGITAL Server 100 - 120 88 - 132 47 - 63 3100/3200 220 - 240 176 - 264 47 - 63 DIGITAL Server...

  • Page 157: Rackmount Systems And Options List

    Rackmount Systems and Options List Rackmount 900mm Enclosure (Base Configurations) Part Number Description FR-PCSRA-RC Rackmount (81-inch H/42U) 115 V ac RETMA 900mm deep FR-PCSRA-RD Rackmount (81-inch H/42U) 240 V ac RETMA 900mm deep FR-PCSRA-RA Rackmount 230 V ac RETMA 800mm deep with side panels and shelves FR-PCSRA-RB Rackmount 230 V ac RETMA 800mm deep FR-PCSRA-RM...

  • Page 158: Rackmount Mounting Options

    Rackmount Systems and Options List Rackmount Mounting Options Part Number Description FR-PCSRA-CT BA356 mounting kit FR-PCSRA-CS 19-inch steel mounting angles (12U) FR-PCSRA-DP 19-inch steel mounting angles (4U) FR-PCSRA-DZ 19-inch steel mounting angles (2U) FR-PCSRA-DJ 800mm chassis support rails FR-PCSRA-EP 900mm chassis support rails FR-PCSRA-EA 19-inch mounting angle (17U) for RAID 450 rackmount Rackmount Shelf Options...

  • Page 159: Rackmount Console Options

    Rackmount Systems and Options List Rackmount Console Options Part Number Description FR-PCSRA-CY 4-port desktop console (mulitplexes four DIGITAL Servers into one desktop console) FR-PCSRA-CZ 8-port desktop console (mulitplexes eight DIGITAL Servers into one desktop console) FR-PCSRA-CW Rackmounting kit for 4-port console FR-PCSRA-CX Rackmounting kit for 8-port console Rackmount Cable Options...

  • Page 160: Digital Server Mass Storage Devices

    Rackmount Systems and Options List DIGITAL Server Mass Storage Devices Part Number Description FR-PCXCR-AR CD-ROM 12x CD-ROM SCSI Dbl 1800 bps FR-PCXRJ-AD Floppy 3.5-inch 1.44 MB frost white FR-CDCBA-CA 2 GB 7200 RPM UW SCSI SBB FR-CECBA-CA 4 GB 7200 RPM UW SCSI SBB FR-CFCBA-CA 9 GB 7200 RPM UW SCSI SBB FR-CECCA-CA...

  • Page 161: Server Manager Platform Reset Cables

    Rackmount Systems and Options List Server Manager Platform Reset Cables Part Number Description FR-PCXCK-AF Server manager/DIGITAL Server cable kit FR-BN21H-02 Ext. SCSI cable, 2 m SCSI-2, 50-pin HD-to-50 HD FR-BN21K-02 Ext. SCSI cable, 2 m SCSI-2, 68-pin HD-to-68 HD right angle FR-BN37A-02 VHDCI to VHDCI cable, 2 m FR-BN38C-02...

  • Page 162: Line Cord Kits

    Rackmount Systems and Options List Line Cord Kits Part Number Description FR-PCSRA-DS US/Canada line cord kit (eight cords) FR-PCSRA-DT Norway line cord FR-PCSRA-DU UK/Ireland line cord FR-PCSRA-DV Central Europe line cord FR-PCSRA-DW Israel line cord FR-PCSRA-DX Switzerland line cord FR-PCSRA-DY Australia line cord FR-PCSRA-CA US/CAN power outlet strip...
  • Page 163 Index 800 mm mouse shelf mounting, 4-41 800 mm rackmount BA356 storage cabinets base configuration, 2-5 mounting, 4-46 900 mm rackmount BA356 storage cabinets (alternate method) base configuration, 2-7 mounting, 4-50 900mm rackmount base configuration installing keyboard drawer, 4-44 800 mm rackmount, 2-5 900 mm rackmount, 2-7 blanking panels installing, 4-79...
  • Page 164 Index video/keyboard cable, 5-4 components, 2-3 connecting components DIGITAL Servers 5100/5200/7100 mounting, 4-2 rackmount, 5-1 connecting two or more rackmounts together, dimensions 4-69 rackmount, 1-2 console connecting a monitor, keyboard, and mouse, 5-13 example configurations mounting, 4-39 rackmount, 2-1 DIGITAL Prioris LX server how to unpack rackmount, 1-4 mounting, 4-8 DIGITAL Prioris XL...
  • Page 165 Index country kits (keyboard and mouse), A-5 DIGITAL Server mass storage devices, A- leveling feet input/output devices, A-4 raising/lowering, 1-6 line cord kits, A-6 rackmount 900mm enclosure, A-1 rackmount cable options, A-3 rackmount console options, A-3 rackmount mounting options, A-2 maximum server configurations rackmount other options, A-3 rack, 2-9...
  • Page 166 Index mounting DIGITAL Prioris XL, 4-5 mounting, 4-55 mounting DIGITAL Server 3100R/3200R RAID 450 storage cabinet installing, 4-72 and 3300R, 4-25 mounting DIGITAL Server 7100R, 4-12 remote masterconsole mounting DIGITAL Servers connecting, 5-6 5100/5200/7100, 4-2 removing mounting monitor, console, keyboard, 4-39 standard side panel retainer, 3-6 mounting RAID 310 storage cabinets, 4-55 removing side panels, 3-4...
  • Page 167 Index U requirements video/keyboard cable rack, 2-2 connecting, 5-4 universal shelves installing, 3-8 unpacking how to, 1-4 where to unpack rack, 1-3 rack, 1-3 where to, 1-3 IN-5...

Table of Contents
