Signature Hardware WIDESPREAD FAUCET Installation Instructions

WIDESPREAD FAUCET
INSTALLATION INSTRUCTIONS
Before installing, read entire Widespread Faucet Installation Instructions. Observe all local building and safety codes.
For the following installation instructions for your new Widespread Faucet it is assumed that any old fixtures have been
removed and any repairs or modifications to the water supply have been completed.
Unpack and inspect the product for any shipping damages. If you find damages, do not install. Contact Customer Service
at 1-866-855-2284. If you need assistance or have questions while installing your faucet, contact Customer Service.
We recommend consulting a professional if you are unfamiliar with installing kitchen fixtures. Signature Hardware
accepts no liability for any damage to the floor, walls, plumbing or for personal injury during installation.
Turn off the water supply at the sink where the new faucet is being installed.

TOOLS AND MATERIALS:

Adjustable Wrench
INSTALLATION
1. If your faucet comes with a brass T attached to the faucet body, remove the T and associated hardware.
2. Place the mounting washer and rubber sealing gasket on the faucet body.
3. Thread your faucet body through the center mounting hole.
4. From underneath the sink, screw the mounting hardware and brass T onto the faucet body and hand-tighten to
secure.
5. Check to make sure the faucet is properly aligned and adjust as needed. When the faucet is in the proper position,
finish tightening mounting hardware with your adjustable wrench.
6. Disassemble the handle body. You may need to remove set screws located in the side of the handle with a hex, or
Allen, wrench (provided).
7. Insert the handle body up through the mounting hole. Secure the handle assembly to the handle body. Make
sure that the rubber sealing gasket is between the handle and the mounting surface to ensure a water tight seal.
8. With the handle in the OFF position, tighten the set screw on the top or side of the handle with your Allen wrench.
9. Repeat steps 6-8 to install the remaining handle (if included).
10. If your faucet features a side spray, install by inserting the sprayer housing and rubber sealing gasket through the
appropriate mounting hole. Secure by tightening the lock nut from underneath the sink. If your faucet does not have
a side spray, move on to step 12.
Basin Wrench Allen Wrench (provided)
