Ansmann Racing deuce n Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
510 mm
3100mm
345mm
AR-21 RS 3.5ccm
Art.-Nr.: 114000011 RTR / 112000011 KIT
Betrieb

Advertisement

loading
Need help?

Need help?

Do you have a question about the deuce n and is the answer not in the manual?

Questions and answers

Related Manuals for Ansmann Racing deuce n

Summary of Contents for Ansmann Racing deuce n

  • Page 1 510 mm 3100mm 345mm AR-21 RS 3.5ccm Art.-Nr.: 114000011 RTR / 112000011 KIT Betrieb...
  • Page 2 Nitro...
  • Page 3 Betrieb / Operation / D'exploitation Die benötigten Schrauben sind den jeweiligen Bauteilen in kleinen Tüten beigefügt. Schrauben, die für den weiteren Zusammenbau nicht mehr benötigt werden, bitte wieder zurück in den Beutel legen, aus dem sie genommen wurden. Somit entsteht beim Zusammenbau weiterer Komponenten kein Durcheinander! The required screws are attached to the respective compo- nents in small bags.
  • Page 4 Servo Saver Turnbuckle Select the servo horn matching the servo being used. Approx.23mm 115000741 3x40 Turnbuckle …………1 ▲Projection.Note direction Futaba-25T Hitec-24T Sanwa/JR/KO-23T 115000706 5.8 Ball End 115000762 M3 115000706 …………2 5.8 Ball stud 115000706 5.8 Ball stud ……………………2 115000741 115000720 3x40 Turnbuckle Steering Servo Horn-F 115000706...
  • Page 5 Servo Saver Post/Side Plate 115000710 Side Plate-Right 115000742 Chassis 115000747 Servo Saver Post 115000710 Side Plate-Left 115000769 M3x10 115000769 M3x10 115000769 M3x10 Screw …………7 115000769 M4x10 Screw Screw Cement …………2 Screw Cement 115000769 M4x10 115000769 M4x10 Buffer Screw 115000769 M3x12 Cement Screw Cement...
  • Page 6 Front/Rear Differential 115000732 115000735 M3x12 115000732 20T Diff Gear 115000732 20T Diff Gear 2.5x11.5 Pin 115000732 2.5x11.5 ?? 115000732 3.6x12x0.2 10T Diff Gear 115000700 115000732 115000732 Differential Pads Diff Shaft 2.5x11.5 Pin 115000700 5.8x1.9 115000735 5.8x1.9 115000735 43T Diff Gear 115000700 Differential Housing 115000760 8x16x5...
  • Page 7 Front Swaybar 115000769 M2.5x8 Screw 115000706 6.8 Ball stud ………………3 …………………2 115000706 M3x3 115000701/115000706 M3x3 Screw Screw Cement 115000706 6.8 Ball End ……………………4 115000706 6.8 Ball stud ………………2 …………………2 115000706 115000706 M3x3 Screw Cement 115000701 Swaybar Mount 115000701 M2.5x8 115000769 Front Swaybar 115000701 M2.5x8 115000701 M3x3...
  • Page 8 Front Hub Carrie 115000770 M4x10 115000707 King Pin Bushing 115000770 M4x10 Screw 115000768 M4x16 ……………2 115000707 King Pin Bushing 115000707 ………4 Front Lower Arm 115000768 M4x16 Screw 115000768 M4x16 ……4 Front Suspension 115000743 4x73 Arm Pin ……2 115000769 M3x35 Screw 115000768 M3x16 …………2 115000860...
  • Page 9 Front Shock Tower 115000881 M4 115000871 Cover-Frong Shock 115000879 Shock absorber Mount 115000730 Front Shock Tower 115000768 M3x12 115000768 M3x12 Screw 115000881 M4 Nylon Nut ……4 ………2 Front Upper Turnbuckle Front Upper-Left 1:1 x1 Approx.32mm 115000706 7.8 Ball stud ▲Projection.Note direction 115000741 5x58 Turnbuckle 115000706...
  • Page 10 Steering Turnbuckle 115000706 Steering-Left 1:1 x1 6.8 Ball stud Approx.31.5mm ▲Projection.Note direction 115000706 6.8 Ball stud Steering-Right 1:1 x1 115000706 6.8 Ball End-Steering Approx.31.5mm 115000741 4x53 Turnbuckle 115000706 6.8 Ball End-Steering ▲Projection.Note direction 115000741 4x53 Turnbuckle 115000706 6.8 Ball stud 115000706 6.8 Ball stud 115000706 6.8 Ball End-Steering ………2...
  • Page 11 Front Suspension 115000769 M3x18 115000769 M3x18 Screw 115000769 M4x10 ……2 115000769 M4x10 Screw …………2 115000769 M4x14 Screw ………4 115000769 M4x14 115000711 Front Bumper 115000732 Center Differential 20T Diff Gear 115000735 M3x12 115000732 115000732 2.5x11.5 Pin 20T Diff Gear 115000732 115000732 3.6x12x0.2 10T Diff Gear 115000732 Diff Shaft...
  • Page 12 Brake 115000702 Center Differential Mount-Front Top 115000702 M3x15 Brake Screw ………4 115000702 Center Differential Mount-Rear Top 115000749 Disk Brake Plate 115000702 Center Differential Mount-Rear Bottom 115000702 M3x15 Brake Screw 115000749 Brake Disk Rotor 115000702 Center Differential Mount-Front Bottom Brake 115000750 M3x3 Screw Cement 115000875 5x8x2.5 Plastic Washer...
  • Page 13 Brake/Throttle 115000762 M2.5 115000718 115000718 M3x3 Screw 115000720 115000718 Throttle Servo Arm ……………………5 1.8x58 Rod Screw Cement 115000718 M3x3 115000762 M2.5 Nylon Nut 115000718 Screw Cement 115000718 M3x3 …………………1 115000762 3.1x7x1 Plastic Washer 115000718 115000762 3.1x7x1 115000718 …………………2 Screw Cement 115000718 M3x3 115000771 M2.5x8 Screw ……………1...
  • Page 14 115000706 Rear Swaybar 115000706 6.8 Ball stud 115000706 M3x3 …………………2 Screw Cement 115000706 6.8 Ball End ………………2 115000706 M3x3 115000769 M2.5x8 Screw ………………3 Screw Cement 115000701/115000706 115000701 M3x3 Screw Swaybar Mount ……………………4 115000701 M2.5x8 115000706 6.8 Ball stud 115000745 Rear Swaybar 115000701 M2.5x8 …………………2 115000701 M3x3...
  • Page 15 Rear Suspension 115000769 M3x35 115000855 86mm Drive Shaft 115000860 Rear Arm Mount-R 115000851 4x77 115000855 115000762 M4 Nylon Nut 86mm Drive Shaft ………………2 115000768 M3x16 Screw ……2 115000769 M3x12 115000769 M3x12 Screw 115000762 M4 …………2 115000860 Rear Arm Mount-F 115000769 M3x35 Screw 115000768 M3x16 ……………2 115000851 4x77 Arm Pin...
  • Page 16 Wing 115000712 Wing Mount 115000768 M3x16 115000768 M3x18 115000762 M3 115000768 M3x16 115000768 M3x16 115000762 M3 Nylon Nut …………………2 115000768 M3x16 Screw ……6 115000768 M3x18 Screw …2 Rear Upper Turnbuckle 115000706 7.8 Ball End-Rear Upper Approx.12.5mm Rear Upper-Left 1:1 x1 115000706 ▲Projection.Note direction 7.8 Ball End-Rear Upper...
  • Page 17 Rear Upper Turnbuckle Rear Upper Turnbuckle-Right 115000771 M3x25 Rear Upper Turnbuckle-Left 115000762 M3 115000769 M4x12 115000762 M3 115000771 M3x25 115000768 M4x22 115000771 M3x18 115000762 M3 115000719 Rear Chassis Stiffener Mount 115000719 Rear Chassis Stiffener 115000762 M4 Nylon Nut 115000762 M3 Nylon Nut 115000768 M4x22 Screw ……………4 ………………1...
  • Page 18 Shock 115000882 1.2mm Plastic Washer 115000883 …………………4 Shock Bottom cover Front-Short 115000882 3mm Plastic Washer Rear-Long 115000882 1.2mm Plastic Washer …………………4 115000882 M3 115000882 115000882 3.8x2.3 O-ring 115000882 3.8x2.3 O-ring Shock Piston ……………………8 115000882 3mm Plastic Washer 115000882 3.1x7x0.4 115000883 7x1.5 O-ring 115000883 7x1.5 O-ring …………………4...
  • Page 19 Shock 115000885 Adjust Ring 115000884 Top Spring Mount ……………4 115000886 Front Shock Spring-Short 115000885 Rear Shock Spring-Long Spring Adjuster Front-Short Rear-Long 115000884 Below Spring Mount Front Shock 115000888 M3 115000888 Plastic Bushing 115000888 M3 Flanged Nylon Nut …………………2 115000888 Plastic Bushing ………………………2 115000768 M3x18 115000768 M3x18 Screw...
  • Page 20 Rear Shock 115000888 M3 115000888 Plastic Bushing 115000888 M3 Flanged Nylon Nut …………………2 115000888 Plastic Bushing 115000768 M3x18 ………………………2 115000768 M3x18 Screw ……2 Radio Plate 115000768 M3x8 Screw ……………4 115000768 M3x8 115000714 Receiver Box 115000863 Radio Plate 115000714 Battery Box Assemble both Left and Right...
  • Page 21 Air Filter 115000721 M3x8 Screw 115000721 M3x8 ……………1 115000721 Air Filter End Cap 115000721 115000721 Air Filter Body 115000721 Air Filter Sponge-Outer 115000721 115000721 Air Filter Boot Air Filter Sponge-Inner Air Filter/Tunedpipe 115000887 Spring 225000024 223000040 Manifold exhaust Seal Enclose 115000721 201000002 Silicon exhaust coupler...
  • Page 22 Engine Screw Cement 115000751 M4x4 115000751 Screw Cement 115000751 Pipe Mount 115000769 M4x10 115000769 M4x10 Screw 115000768 M4x10 Screw 115000751 M4x4 Screw ……4 ……1 …………………2 Screw Cement 115000768 M4x10 Oil Pipe 115000767 Oil Pipe Must be purchased separately Apply threadlocker(screw cement) Screw Cement...
  • Page 23 115000768 M3x12 Wing 115000768 M3x12 Screw 115000767 Wing Screw Washer ……………2 115000767 Wing <L> Tyre 115000864 <L> Tyre Sponge 115000864 Tyre 115000890 <R> <R> 115000890 115000864 Tyre 115000864 Tyre Sponge Assemble as many times as specified...
  • Page 24 Tyre 115000746 17mm Hex Nut ……4 115000746 17mm Hex Nut Body 115000870 Body Assemble both Left and Right...
  • Page 25 Body Mask the windows from the inside. Paint the body shell from the inside using spray colors. Body 203000081 Mid Clip 203000081 Mid Clip 115000768 M3x6 Screw ……2 115000768 M3x6 Screw ………………1...

  • Page 26: Exploded View

    Exploded View 115000856 115000768 203000081 115000750 115000702 115000769 115000702 115000769 115000702 115000717 115000702 115000720 115000714 115000714 115000767 115000717 115000717 115000859 115000702 115000762 115000760 115000772 115000880 115000771 115000750 115000750 115000749 115000875 115000771 115000879 115000750 115000712 115000771 115000717 115000702 115000862 115000717 115000768 115000717 115000714 115000879...
  • Page 27 Parts list for Deuce nitro 115000850 115000851 115000852 115000853 115000854 M4x4 Screw M4x4 Screw 2pcs 2pcs 2pcs 2pcs Buffer Screw 3.6x7x0.8 Washer 3x51.5 Arm Shaft 2pcs 1pcs Chassis 4x77 Arm Shaft 95.5mm Front CVD Steering Rack Rear Wheel Shaft 1pcs 2pcs 2pcs 2pcs...
  • Page 28 Parts list for Deuce nitro 115000708 115000709 115000710 115000711 Left 1pcs Left 1pcs Rear Chassis Stiffener Mount Side Plate-Right 1pcs 1pcs Top 1pcs Dirtcover Rear-Left Dirtcover Rear-Right Bottom 1pcs 1pcs 1pcs Right 1pcs Front Bumper Buffer Plate-Plastic Side Plate-Left Rear Lower Arm 1pcs Buffer Plate-Aluminium 2pcs...
  • Page 29 Parts list for Deuce nitro 115000762 115000763 115000766 115000767 M3.5 Nylon Nut 6pcs M2.5 Nylon Nut 6pcs 3.6x12x0.2 Washer 3.5x9x1.0 Washer 6pcs M4 Nylon Nut M3 Nylon Nut Oil Pipe-Short Oil Pipe-Long 6pcs 1pcs 1pcs 6pcs 6pcs 242000016 115000770 115000771 M3x3 Screw M3x12 Screw M2.5x8 Screw...
  • Page 30 Parts list for Deuce nitro 115000775 115000891 115000892 3x7x0.8 Washer 10pcs 115000776 M3 Spring Washer Rear Shock Absorber 6pcs Front Shock Absorber 2Set 2Set 115000867 115000893 3.1x7x0.4 Washer 6pcs Body rtr 1pcs...

  • Page 31: Setup Sheet

    Driver Track / City Event Date SETUP SHEET Conditions Smooth Bumpy Low traction Med traction High traction Sandy Soft dirt Grass Hard soil Clay Dusty Other Front Suspension Front Shocks Shock Mounting&Camber link Anti-roll bar: ° Camber Ride height Piston # Rear Suspension Rear Shocks Shock Mounting&Camber link...
  • Page 32 Service: ANSMANN AG Division Racing Abt. Service Industriestr. 10 97959 Assamstadt Tel.: +49 (0) 6294-4204-34 Fax.: +49 (0) 6294-4204-47 ANSMANN AG DIVISION RACING Thomas-Mann-Str.63 D-90471 Nuernberg Germany Tel.: +49 (0) 911 817 44 0 Fax.: +49 (0) 911 817 44 22 email: info@ansmann-racing.com...
