Technische Daten / Technical Date / Données Technique
Länge / Length/ Longueur ....................................................................................480mm
Breite / Width / Largeur ....................................................................................265mm
Höhe / Height / hauteur ....................................................................................150mm
Art.-Nr.: Item No.: 124000020 RTR / 122000017 KIT

Advertisement

loading
Need help?

Need help?

Do you have a question about the SC4 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ansmann Racing SC4

Summary of Contents for Ansmann Racing SC4

  • Page 1 Technische Daten / Technical Date / Données Technique Länge / Length/ Longueur ....………………………………………………………………480mm Breite / Width / Largeur …………………………………………………………………………265mm Höhe / Height / hauteur …………………………………………………………………………150mm Art.-Nr.: Item No.: 124000020 RTR / 122000017 KIT...
  • Page 2 K I T...
  • Page 3 Betrieb / Operation / D'exploitation Die benötigten Schrauben sind den jeweiligen Bauteilen in kleinen Tüten beigefügt. Schrauben, die für den weiteren Zusammenbau nicht mehr benötigt werden, bitte wieder zurück in den Beutel legen, aus dem sie genommen wurden. Somit entsteht beim Zusammenbau weiterer Komponenten kein Durcheinander! The required screws are attached to the respective compo- nents in small bags.
  • Page 4 Getriebebox, Motorhalter / Diff.gear Box, Motor Mount / boîte de vitesses, support moteur Upper 125000909 Below 125000900 125000908 125000959 M3x8 Screw 125000959 ………………4 125000959 M3x8 125000902 125000915 125000951 125000901 125000959 125000959 M3x8 M3x8 125000959 M3x8 125000959 M3x8 Screw Screw ………………15 Cement - 4 -...
  • Page 5 Diff. vorne/hinten / F/R Differential / différentiel avant arrière 125000930 125000983 10x15x4 Ball Bearing 125000966 125000983 125000941 …………4 125000958 125000958 10x12x0.2 Washer 125000982 ………………4 125000968 2.6x6x3 125000940 Stop push ball bearing ………………2 125000949 125000930 2.6x25 125000968 Diff Screw 125000927 125000930 125000958 125000930 4x1 O-Ring 125000983...
  • Page 6 Getriebebox, Mid. Getriebe / Gear Box, Mid Gear / Gear Box, engins de mi 125000960 M3x10 125000960 M3x8 125000960 M3x10 125000902 125000960 M3x8 125000901 125000960 M3x8 Screw ……………4 125000960 M3x10 Screw ……………6 125000960 125000960 M3x5 M3x5 125000929 125000983 125000929 125000928 125000983 125000949 2x8.8 Pin 125000928...
  • Page 7 Mittelgetriebe, Servo / Center Gear, Steering Servo / atterrisseur central, servo de direction 125000943 125000943 125000943 125000985 125000960 M3x10 125000960 M2.6x8 Screw 125000913 125000914 125000972 ……………1 3kg Steering Servo 125000960 M3x10 Screw ……………4 Select the servo horn matching the servo being used. 125000972 Ball stud-Short ……………1 125000960...
  • Page 8 Servo, Puffer / Steering Servo, Buffer / servo de direction, tampon 125000959 M3x8 Screw 125000959 ………………2 M3x8 125000911 125000950 125000911 125000971 125000971 125000911 125000912 125000961 125000950 125000961 125000971 Ball stud-Long 125000971 …………3 125000961 M3 Screw 125000950 Approx.5mm …………2 - 8 -...
  • Page 9 Halterung Querlenker / Front Upper Suspension Arm / Suspension avant Bras supérieur 125000924 125000939 17.5mm 125000924 125000955 125000955 125000950 125000959 M3x8 Screw ………………2 125000955 4x7x2.5 Contain Oil Ball Bearing …………………4 125000924 4.8mm Ball End-Long ……2 125000939 3x40 Turnbuckle 125000959 M3x8 …………1 125000960 M3x10...
  • Page 10 Halterung Querlenker / Front Upper Suspension Arm / Suspension avant Bras supérieur 125000904 125000960 M3x22 125000956 M3x12 125000956 M3 Nut …………………2 125000960 M3x8 Screw 125000960 …………2 M3x8 125000960 M3x12 Screw …………2 125000960 M3x22 Screw …………2 125000960 M3x10 125000960 M3x12 125000960 M3x12 125000919 125000903...
  • Page 11 Dämpferbrücke v+h / r+f Shock tower / Tour de choc avant et arrière 125000956 125000960 M3x22 125000904 125000960 M3x8 125000956 M3 Nut ………………2 125000960 M3x22 Screw …………2 125000960 M3x8 Screw …………4 125000960 M3x12 125000915 125000960 M3x12 Screw …………4 - 11 -...
  • Page 12 Achseneinbau / Front hub carrier / plaque tournante du transporteur avant 125000906 125000906 125000920 1.6x11 Spring Pin 125000907 125000907 ……………2 125000971 125000972 Ball stud-Short ……………2 125000972 125000971 Ball stud-Long 125000942 125000905 …………2 125000920 125000961 M3 Screw 125000984 …………4 125000915 125000984 5x10x4 Ball Bearing 125000984 ……………4...
  • Page 13 Querlenker vorne / Front suspension arm / bras de suspension avant 125000908 125000960 M3x12 125000959 M3x8 Screw 125000948 ………………2 125000960 M3x12 Screw …………4 125000960 M3x14 Screw ………2 125000959 125000948 3x51 Arm Pin M3x8 ………………2 125000960 M3x14 Front upper Rod-L 23.5mm 125000924 3x45 Turnbuckle 125000939...
  • Page 14 Radträger hinten / Rear hub carrier / Porte-moyeu arrière < R > 125000910 1.6x11 Spring Pin ……………2 125000971 Ball stud-Long 125000984 …………2 125000984 5x10x4 Ball Bearing 125000945 ……………4 125000984 125000971 125000910 125000910 - 14 -...
  • Page 15 Querlenker hinten / Rear suspension arm / bras de suspension arrière < L > 125000910 2.5x6x1 Washer …………………4 125000917 125000960 M2.5x4 Screw 125000910 2.5x6x1 …………………2 125000947 2.5x30 Arm Pin ………………2 < R > 125000960 M2.5x4 125000947 125000909 TR4058 M3x10 Screw 125000948 ……………2 125000948 3x51 Arm Pin...
  • Page 16 Dämpfer / Shock Absorber / Amortisseur 125000944 125000944 Front-Short Rear-Short 125001030 / 125001031 2.3 E-ring …………………………8 125000977 Put a little oil 125000978 Shock Piston 125000976 125000979 125000979 Put a little oil 125000979 …………………4 (2.8x1.9) 125001031 125000979 125000979 125001030 (3x1mm) (2.8x1.9) 125000979 2.8x1.9 O-ring 125000979 125000979...
  • Page 17 Dämpfer / Shock Absorber / Amortisseur 125000977 125001029 125000976 125001029 für vorne (kurz) for Front(Short) für hinten (lang) for Rear (Long) vorne lang hinten kurz Front-Long Rear-Short vorne kurz Front-Short zur Einstellung der Federvorspannung for adjusting the spring tension Compress the spring and install 125000976 125000965 125000953...
  • Page 18 Dämpfer / Shock Absorber / Amortisseur 125000925 125000986 125000960 M3x12 125000925 125000960 125000986 Shock cap ball-Short M3x12 Screw M3 Nylon Nut ………2 ………2 ……2 125000925 125000986 125000960 M3x12 125000925 Shock cap ball-Long …………2 125000986 M3 Nylon Nut …………………2 125000960 M3x12 Screw …………2 - 18 -...
  • Page 19 Motor, Akku/ Motor, Akku / Moteur, Akku 125000918 125000959 M3x10 Screw 125000918 ……………4 125000959 M3x10 540 Burushed Motor Brushless Motor 125000951 125000951 125000960 M3x8 125000960 M3x8 ……………………1 125000960 M3x8 Screw ……………2 - 19 -...
  • Page 20 Motor, Empfänger / Motor, Receiver / Moteur, récepteur 125000960 M3x10 125000960 M3x14 125000951 125000960 M3x8 Screw ……………1 125000960 M3x10 Screw ……………1 203000208 125000923 125000960 M3x14 Screw 125000923 M2.5x13 125000960 ………1 M3x8 Tighten the screws with one sheet of paper inserted between both gears. 125000915 125000959 M3x8...
  • Page 21 Akku, Heckstoßstange / Battery, rear Bumper / batterie, pare-chocs arrière bâton 125000918 Small clip ……………2 125000918 125000918 Battery 125000657 M3x18 125000657 M3x18 Screw ………2 - 21 -...
  • Page 22 Heckstoßstange / Rear Bumper/ pare-chocs arrière bâton M3x12 125000659 125000659 M3x10 Screw ……………4 125000658 M3x12 Screw M3x10 ………4 M3x10 M3x10 M3x10 M3x14 125000657 M3x10 Screw ……………8 125000657 M3x14 Screw ………2 - 22 -...
  • Page 23 Karosseriehalter / Body mount / titulaire de la carrosserie 125000654 M3x8 Screw ……………4 M3x8 125000484 Small clip ……………4 125000654 M3x8 125000654 M3x8 Screw ……………4 M3x8 - 23 -...
  • Page 24 Räder / Wheel / roue hinten links vorne links Rear-Left Front-Left hinten rechts vorne rechts Rear-Right Front-Right After fitting wheels to tyres, apply instant glue as shown vorne links hinten links Front - Left Rear - Left vorne rechts hinten rechts Front - Right Rear - Right - 24 -...
  • Page 25 Räder, Karosserie / wheels, Body / roues, carrosserie 125000986 125000986 M4 Flanged Nylon Nut ……………4 125000484 Small clip ……………4 - 25 -...
  • Page 26 Explosionszeichnung / Exploded View / vue éclatée - 26 -...
  • Page 27 Ersatzteile / Spare Parts / Pieces detachees 125000654 125000649 125000652 125000659 Body Mount 1set Rear Fender Plates 1Set 2pcs 2pcs 1pcs 1pcs 2pcs Tyre-Sponge Left-tyre Right-tyre Front Rim Rear Rim 125000663/662 125000433 125000658 125000656 Rear bumper stick 2pcs 1pcs Rear Wheel 1Set Hex Mount 1.6x11 Spring Pin...
  • Page 28 Ersatzteile / Spare Parts / Pieces detachees 125000915 125000916 125000917 125000918 1pcs 2pcs 1pcs 1pcs 1pcs 2pcs Left - 1pcs 1pcs Right - 1pcs 1pcs Querlenker vorne Hauptzahnradbox Akkuhalter Querlenker hinten Front Lower Arm Center Gear-box Battery Holder Rear Lower Arm 125000919 1250009120 1250009123...
  • Page 29 Ersatzteile / Spare Parts / Pieces detachees 125000949 125000950 125000951 1pcs 2pcs 1pcs 1pcs 2pcs 2pcs 1pcs 1pcs 1pcs 2pcs Servo Saver Pfosten Pin Set Motorhalter Servo Saver Post Pin Set Motor Mount 125000952 125000953 125000955 125000956 hinten / rear 6pcs 6pcs vorne / front...
  • Page 30 Ersatzteile / Spare Parts / Pieces detachees 125000964 125000965 125000966 125000967 2pcs 1pcs 12pcs 2pcs Below Spring mount end 2pcs 5.8 Ball End Diff Feder 2.37mm Diff Kugeln 3.1x5.5x1 Beilagscheibe Differential Spring 2.37mm Ball 3.1x5.5x1 Aluminum Washer 125000968 125000703 Alu. Ritzel / Pinion 125000971 125000700 Alu Ritzel 15Z 1pcs...
  • Page 31 Ersatzteile / Spare Parts / Pieces detachees Driver Track / City Event Date Conditions Smooth Bumpy Low traction Med traction High traction Sandy Soft dirt Grass Hard soil Clay Dusty Other Front Suspension Shock Mounting&Camber link Toe-in (+)/Out (-) ° Bump Steep Spacer Washers Caster...
  • Page 32 Service: ANSMANN AG Division Racing Abt. Service Industriestr. 10 97959 Assamstadt Tel.: +49 (0) 629 4204 34 Fax.: +49 (0) 629 4204 47 ANSMANN AG DIVISION RACING Thomas-Mann-Str.63 D-90471 Nuernberg Germany Tel.: +49 (0) 911 817 44 0 Fax.: +49 (0) 911 817 44 22 email: info@ansmann-racing.com...
