  • Page 1 MKU OCU User Manual...
  • Page 2 Cattron Holdings, Inc., or any of its affiliates or agents shall not be liable for incidental or consequential damages of any kind. All Cattron products are sold pursuant to the Terms and Conditions of Sale, a copy of which will be furnished upon request. When used as a tradename herein, Cattron means Cattron Holdings, Inc.

  • Page 3: Table Of Contents

    MKU OCU User Manual Contents Important Notes ..............................5 Warnings and Cautions ............................6 System Description .............................9 General ................................10 Radio Transmission ..........................10 4.1.1 Continuous Transmission ........................10 4.1.2 Radio Interference ..........................10 Telegram Security ............................ 10 4.2.1 Frame Type............................10 4.2.2...
  • Page 4 MKU OCU User Manual 11.1 Working Principle ............................. 26 11.2 Activating Programming Mode ........................ 27 CE Declaration of Conformity ........................32 Appendix I: Spare Parts and Accessories ....................... 33 Appendix II: Technical Data ............................. 34 OCU Technical Specifications ..........................34 Appendix III: System Configurations ........................

  • Page 5: Important Notes

    This manual is Confidential and Proprietary to Cattron. The entire document including any or all of the information contained therein is not to be reproduced, disclosed, or used in whole or in part for any purpose without prior written authorization from Cattron.

  • Page 6: Warnings And Cautions

    WARNING The use of unapproved components or accessories in the systems sold by Cattron and its subsidiaries is strictly prohibited. Unapproved components are defined as any component not inspected and sold by Cattron. This also includes any component modified from its intended use and/or any component exhibiting observable damage or defect.
  • Page 7 MKU OCU User Manual 9M02-7641-A003-EN Version 1.0...
  • Page 8 MKU OCU User Manual CAUTION Cattron MKU battery conditioners and external charging units are designed for use with Cattron Ni- Cad battery packs only. Battery packs must be removed or disconnected from battery conditioners/external charging units within 48 hours of achieving the fully charged state.

  • Page 9: System Description

    User Manual System Description A Cattron Portable Remote Control (PRC) system offers the safety and dependability required for industrial control applications such as overhead cranes, conveyors, machines, etc. A remote control system enables an operator to be in the safest and most efficient position for each and every operation, thereby reducing accidents with associated injury or material damage and simultaneously boosting efficiency and productivity.

  • Page 10: General

    MKU OCU User Manual General With an OCU and a matching MCU, a machine such as a crane or vehicle can be remotely radio controlled, avoiding the need for a wired connection between the human interface and the controlled device. A number of different control elements are integrated into the OCU housing so that commands to the device are securely encoded into a radio transmission.

  • Page 11: Frame Counter

    MKU OCU User Manual 4.2.4 Frame Counter Each message has an 8 bit embedded frame counter that changes on every data frame. This prevents frozen data and data frame hacking. System Parameters The system parameters, including the system address and the selected RF channel, are set by programming the TransKey.

  • Page 12: Operator Control Unit (Ocu)

    MKU OCU User Manual Operator Control Unit (OCU) The OCU is a lightweight, palm-sized, extremely rugged customizable controller for use with any CattronControl series MCU. Each OCU is designed to meet a specific control application. Two standard OCU options are available: one with a toggle select switch on the end cap and one without this switch.
  • Page 13 Appendix IV. A belt loop strap is provided with all Cattron MKU OCUs. This is quickly and simply installed to a ‘D’-ring located on the curved underside of the controller. Referring to Figure 3, an optional shoulder-carrying strap is available on request.

  • Page 14: General Information

    Figure 3: Optional shoulder-carrying strap General Information The MKU OCU is globally compliant when supplied with an appropriate radio module – additional certifications may be required for some regions; details are available on request. It has been designed with the latest generation dual-channel electronics and exceeds the Safety Related Systems requirements for ISO13849 Category 3 PLd.
  • Page 15 MKU OCU User Manual In Europe and other regions, the operating frequency will typically be in the 433-434 MHz license exempt band; again, other licensed and unlicensed frequency bands are available. Battery packs are easily and quickly replaced without the need for tools by turning two knurled thumbscrews and removing the battery cover-plate located within the confines of the bottom end-cap.

  • Page 16: Preparing The Ocu For Operation

    An operator should be aware that securely retaining the TransKey within the OCU top end-cap will not prevent unauthorized operation of the controller or its target machinery. Therefore, when not in authorized use, Cattron recommends that an OCU having a permanently retained TransKey be held in a suitable cabinet under lock and key.
  • Page 17 MKU OCU User Manual Indicators Referring to Figure 5, the OCU is a lightweight hand-held unit with twelve pushbuttons (function keys) on a single keypad, plus a rotary ON/OFF switch and a push/pull STOP switch. The OCU may be hand carried, held by a belt loop strap or worn with an optional shoulder-carrying strap. The OCU is powered by a disposable (alkaline) or rechargeable (Ni-Cad) battery pack.

  • Page 18: Ocu Operation

    A Cattron external battery charging adapter (Part # 70C-0003) will be required for battery charging or conditioning. A Cattron ‘Standard’ Battery Charger (Part # 70C-0001) enables a Ni-Cad battery pack to be charged within 10 hours. A Cattron Battery Conditioner/Charger (Part # 70C-0002) is also available. For details, refer to Section 7.4 below.

  • Page 19: Conditioning / Charger Use

    Inserting battery into adapter and initiating charging To charge a Ni-Cad battery pack, refer to Figure 7. Connect the Cattron battery charger to the power source by inserting the charging jack into the external battery charging adapter socket. Drop the battery pack into the battery charging adapter, ensuring the battery pack contacts are positioned as shown.

  • Page 20: Trickle Charger Use

    Figure 9: Battery pack conditioning / charging unit to adapter – interconnection details Trickle Charger Use The Cattron Battery Trickle Charger (Part # 70C-0001) is available for use only with Ni-Cad battery packs and a power supply of 120V 60Hz.

  • Page 21: Alkaline Battery Adapter

    Figure 10: Battery trickle charger and adapter Alkaline Battery Adapter Referring to Figure 11, a Cattron Battery Adapter (Part # 60C-0062MK-001) is available that accepts two ‘AAA’ size alkaline 1.5-volt batteries. It should be noted that when using ‘AAA’ size alkaline 1.5-volt batteries with this adapter, battery life will only be 40% of that provided by a Cattron Alkaline Battery Pack.

  • Page 22: Operating The Ocu

    MKU OCU User Manual Operating the OCU Note that dual pressure (DP) function key pushbuttons are pre-assigned through TransKey programming for two- step operation. In other words, a second output is tied to the second level of button depression. Typically, dual pressure OCUs send one of two output commands to the MCU from a single button. DP buttons are paired to opposite directions of the same output (i.e., forward and reverse).

  • Page 23: If The Stop Switch Verification At Startup Is Disabled

    MKU OCU User Manual If the Stop switch verification at Startup is disabled 1. The ‘STATUS’ LED will illuminate flashing GREEN at an approximate rate of 2 cycles per second. The OCU is ready for use and a power up message has been sent to the target MCU. The targeted MCU will respond by energizing the mainline contactor of your controlled machine.

  • Page 24: Maintenance Instructions

    Before use, visually inspect the OCU and MCU for cleanliness, physical damage and security of external parts (screws, switches, rubber grips, etc.). Cattron emphasizes that regular visual inspections not only mean quickly locating a source of potential problems, but also may prevent serious problems from developing later.

  • Page 25: Changing The Rf Channel

    MKU OCU User Manual 10. Changing the RF Channel • With the OCU in 'Programming Mode’ (see Section 11.2), pressing the first level of the ‘UP’ and ‘DOWN’ pushbuttons selects the next higher or next lower RF channel respectively. •...

  • Page 26: Rf Channel Change Option

    MKU OCU User Manual 11. RF Channel Change Option To ensure interference-free operation of the radio control system, it may be necessary to change the RF channel previously assigned by the manufacturer. Changing the RF channel may be necessary due to interference, or in the event that an RF channel is already in use by another system.

  • Page 27: Activating Programming Mode

    MKU OCU User Manual 11.2 Activating Programming Mode Refering again to Figure 12, set the OCU to 'Programming Mode', as follows: • With the OCU switched off, hold the ‘ENTER’ pushbutton fully down (second step) and switch on the OCU using the rotary ON/OFF switch.
  • Page 28 MKU OCU User Manual Table 1: RF Channel Color Code Table for 433 MHz Band, continued LED Color Channel Frequency 433,3025 Green green 433,3275 Green orange 433,3525 Orange 433,3775 Orange 433,4025 Orange green 433,4275 Orange orange 433,4525 433,4775 433,5025 green...
  • Page 29 MKU OCU User Manual Table 1: RF Channel Color Code Table for 433 MHz Band, continued LED Color Channel Frequency 434,4275 orange orange 434,4525 orange green 434,4775 orange green 434,5025 orange green green 434,5275 orange green orange 434,5525 orange orange...
  • Page 30 MKU OCU User Manual Table 3: RF Channel Color Code Table for 915 MHz Band 902 - 928 MHz LED Color Channel Freq. 904.2 green 905.4 orange 906.6 907.8 green 918.6 orange 919.8 green green 922.2 green green 923.4 green orange 903.2...
  • Page 31 MKU OCU User Manual Table 3: RF Channel Color Code Table for 915 MHz Band, continued 902 - 928 MHz LED Color Channel Freq. 904.8 green orange green 907.2 green 908.4 green green 909.6 green orange 919.2 green green 920.4...

  • Page 32: Ce Declaration Of Conformity

    MKU OCU User Manual 12. CE Declaration of Conformity Hereby Cattron declares that the radio equipment is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: www.cattron.com...

  • Page 33: Appendix I: Spare Parts And Accessories

    MKU OCU User Manual Appendix I: Spare Parts and Accessories Contact the Cattron sales department at www.cattron.com/contact for availability and pricing of the spare parts and accessories that are listed in Table 4. Table 4: Spare Parts and Accessories Item...

  • Page 34: Appendix Ii: Technical Data

    MKU OCU User Manual Appendix II: Technical Data OCU Technical Specifications Table 5: OCU Technical Specifications OCU Data Description Case material Extreme duty, dust and water resistant, aluminum housing Approximate weight 1.4 lb / 634 gm (including battery pack) Dimensions 8.0"...

  • Page 35: Appendix Iii: System Configurations

    MKU OCU User Manual Appendix III: System Configurations MKU System Identifier MKU systems may be ‘Standard’ or pre-configured; they may also be fully engineered. Figure 14 identifies some of the Standard versions. Figure 14: MKU System Identifier for Standard Versions...
  • Page 36 MKU OCU User Manual Figure 15: Example Configuration Sheet for System Model UN3HS5D2A...
  • Page 37 MKU OCU User Manual Figure 16: Example Configuration Sheet for System Model UN3H06D2...
  • Page 38 MKU OCU User Manual Figure 17: Example Configuration Sheet for System Model UN4H03D2...
  • Page 39 MKU OCU User Manual Figure 18: Example Configuration Sheet for System Model UN5H02S2...

  • Page 40: Appendix Iv: System Fault / Status Messages

    Hardware fault Change OCU board* Return OCU for repair *Cattron customer trained technicians only. If necessary, contact the factory for the replacement part number applicable to your system configuration. Refer to www.cattron.com/contact for the telephone numbers and email addresses. MCU Fault / Status Messages...

  • Page 41: Appendix V: Rf Compliance And Operating Frequency Selection

    Due to continuous product improvement, the information provided in this document is subject to change without notice. Cattron Support For remote and communication control systems support, parts and repair, or technical support, visit us online at: www.cattron.com/contact Cattron North America Inc., 655 N River Rd NW, Suite A, Warren, OH 44483 9M02-7641-A003-EN Version 1.0...
