- Page 1 MASTER INSTALLATION GUIDE REV F TOWER SERIES COMPLETE SETUP For help call PowerGistics toll free (844) 205-1217 or visit www.powergistics.com/contact Check out our YouTube videos for tips and tricks.
- Page 2 Unplug when not in use. Power Strip Specifications Read the electrical specifications of any electronic equipment you are using with your PowerGistics products. Failure to read these specifications and follow their instructions could result in damage to your equipment or personal injury.
- Page 3 CABLE MANAGEMENT GUIDE (Figure 1.0) (See Figure 1.0) Run power cable from inside the back of the Tower spine (a). Continue running cable through rear of shelf (b) following the inside of the shelf. Pull the power cable through the shelf (Figure 1.1) hole (c) in the front.
- Page 4 MOVING POWER STRIP IPAD ONLY If you are using the PowerGistics Towers to charge and store iPads, the included power strip must be moved from center to the side of the Tower spine. (Figure 1.2) (See Figure 1.2) Firmly pull power strip to detach from the two snap-in brackets.
- Page 5 ATTACHING POWER BRICKS (Figure 1.5) (See Figure 1.5) Insert cable tie through holes (a) and (b) from inside spine through hole (a), looping around through hole (b). (See Figure 1.6) Bundle power brick and excess cable using the provided cable ties. (Figure 1.6) Insert bundled power brick into loop and secure...
- Page 6 Drive in screw with plastic collar and hang tower. WARNINGS • DO NOT PLUG POWERGISTICS TOWERS INTO OTHER TOWERS. MUST BE PLUGGED DIRECTLY INTO THE WALL OUTLET. • TOWER MUST HAVE THE BASE RESTING ON THE FLOOR.
- Page 7 SWITCHING DOOR Depending on your device’s charging port location, the locking door may need to be fl ipped to the other side. (Figure 1.8) If your device’s charging port is on the LEFT side when placed on shelf NO DOOR SWITCH IS NECESSARY. If your device’s charging port is on the RIGHT side when placed on shelf you must fl...
- Page 8 Restriction of the use of certain hazardous substances in electrical and electronic equipment (RoHS) Directive, 2011/65/EU. For a copy of the official Declaration of Conformity, please send an email to compliance@powergistics.com with the marking name and model number for relevant product(s)
