- Page 1 Instruction Manual PEUGEOT2017 RCC TD for PEUGEOT...
-
Page 2: Table Of Contents
INDEX Specifications Main Spec. ---------------------------------- Diagram ------------------------------------- Components -------------------------------- Exterior -------------------------------------- Settings Dip Switch ---------------------------------- Original button ----------------------------- Touch(DVD, DTV control) ------------------- Key board ----------------------------------- OSD Menu ---------------------------------- Installation LVDS Installation --------------------------- Caution ------------------------------------- GU Electronic... -
Page 3: Specifications
- Consumption Power : 12Watt, Max 1-4 Switch Input mode - Possible to switch input mode through original button 2. Features Possible to register IR code of DVD/DTV Display dynamic PAS(Parking assistance system) Easy installation by Jack by jack GU Electronic... -
Page 4: Diagram
Specification 2. Diagram INTERFACE COMMAND EEPROM SYSTEM RECEIVER LVDS LVDS LVDS Scaler NAVIGATION LVDS RELAY (PIP) SYSTEM NAVIGATION LVDS SYSTEM LVDS RGB888 FRONT CAMERA REAR CAMERA REAR CAMERA POWER TFT-LCD LVDS GU Electronic... -
Page 5: Components
Specification 3. Components OSD Board 1 EA Touch Cable(KD-900) 1EA Power Cable 1EA RGB NAVI Cable(7pin) 1EA LVDS Cable 1 EA NAVI Power Cable(300mm) 1 EA GU Electronic... -
Page 6: Exterior
③ CAN-H (Orange) ③ Y+ ③ B DATA (Blue) ③ N.C ④ CAN-L (Green) ④ X+ ④ SYNC (White) ④ GND ⑤ REAR DET (Brown) ⑤ GND (Black) ⑥ GND (Black) ⑥ DVB-T IR (Green) ⑦ DVD IR (Orange) GU Electronic... -
Page 7: Settings
2017 Citroen C4 PICASSO OFF : 2017 Peugeot 3008, Car Model 2017 Citroen C4 PICASSO ON : 2017 Peugeot 3008 OFF : 2017 Citroen C4 PICASSO * Example 2017 Citroen C4 PICASSO 2017 Peugeot 208 2017 Peugeot 3008 GU Electronic... - Page 8 - AV Setting – For DTV or DVD “RearCam-Type” should be set as “OEM” and “AV Mode” should be set as “ON” in OSD Menu when video device is connected to Rear input DTV(AV1) NAVI or DVD(AV2) (DTV or DVD) GU Electronic...
-
Page 9: Original Button
Long Press or Short Press : Switching Mode ※ You can choose the Switching mode type (Long Press or Short Press ) from the OSD Menu (P.17) ※ The screen is switched in order as the pictures below - Long Press - Shot Press GU Electronic... - Page 10 2. Original button Peugeot 208 (Switching Mode) 2017 Peugeot 208 Long Press : switching mode ※ Possible to set the use of MENU buttons ON or OFF in OSD menu (P.16) ※ The screen is switched in order as the pictures below NAVI GU Electronic...
- Page 11 2017 Peugeot 3008 2017 Citroen C4 PICASSO Long Press : switching mode ※ Possible to set the use of SRC button ON or OFF in OSD menu (P.16) ※ The screen is switched in order as the pictures below NAVI GU Electronic...
-
Page 12: Touch(Dvd, Dtv Control)
3. Touch screen – Touch calibration Touch OEM screen in any mode more than 7sec. Touch the “+” correctly For calibration (This function can be activated only one time after switching mode) - DVB-T/DVD Control Press Touch (Anywhere) Press Icon DVB-T GU Electronic... - Page 13 [MIC] [DVD up] [DVD down] [Play/pause] [Power] [FF] [Rewind] [Play Next chapter] [Play Previous chapter] ※ To use this function, It is necessary to offer the remote IR code to manufacturer or setting OSD IR – Ctrl（P. 21） GU Electronic...
-
Page 14: Key Board
※Press “MENU” button on Key board Config - NAVI-RGB : Setup for the type of NAVI-RGB Config - DVB-T(DMB) : Setup for the type of DVB-T(DMB) Config - DVD : Setup for the type of DVD Reset : Reset all value GU Electronic... - Page 15 AV Mode : Change “Rear” input as Video input • ON – Video input (Rearcam TYPE in OSD menu should be “OEM”) OFF – Rear input FrontCam-Type : Setup for front camera • ExtDevice - External rear camera OEM - Original camera GU Electronic...
- Page 16 Button : Setting for Original Button (Peugeot 208 Switching Mode) • ON - ON OFF – OFF UI DVB-T(DMB) : Setting UI ICON - ON or OFF • UI DVD : Setting UI ICON - ON or OFF • GU Electronic...
- Page 17 ※Press “MENU” button on Key board Option NAV Btn : Setting for Original Button (Peugeot 3008, PICASSO Switching Mode) • SHORT - Short Press LONG - Long Press OFF - OFF NAVI COM (N.C) • Reset : Reset all value • GU Electronic...
- Page 18 NAVI Config Horizontal Vertical Option Scale X Up Image Scale X Down Screen Screen Scale X Up Parking - DVD, DVBT, NAVI-AV, REAR, FRONT Image MENU IMAGE Rear Config Brightness Option Contrast Image Image Saturation Screen Parking Sharpness GU Electronic...
- Page 19 Possible to adjust the position of line by Keypad in Horizontal / Vertical menu ※ Pressing this Horizontal / Vertical menu, The OSD screen automatically disappears. Please adjust from the parking line Screen. MENU DOWN Left Right Down GU Electronic...
- Page 20 OSD – Display : Setting time for displaying OSD menu • OSD – Transparency • OSD – Language : Setting language of ODS menu • - IR – Ctrl (p.21) - Utility - 170612 Utilityy– INTERFACE SOFTWARE • GU Electronic...
- Page 21 ③ Press a button on the remote control separately of DVD/DTV then the IR code will be appeared on “New code” menu. Press the same button one more time to confirm the IR code. (Cfm code = confirm code) GU Electronic...
-
Page 22: Installation
Installation 1. LVDS Installation [BACKSIDE OF OEM COMMAND] Provided LCD Cable Provided Power Cable Monitor Touch cable for KD900 GU Electronic... -
Page 23: Caution
LVDS cable must be connected correctly according to the manual • Insulate the end of wire by using electrical tape • The installation should be done by expert • GU electronic does not take any responsibility for any problem • caused by wrong installation... - Page 24 GU Electronic For your better driving...
