Ugo ZEPHIR 2.0 User Manual page 3

Auto take o / Land
Quadcopter Dimension
Blade Protection
Auto hover First Person View
Auto Hover/Auto Trim
Max Flight Speed 5 m/s
One Key Return/Headless Mode
Removable Battery Pack
Dimension: 75 x 70 x 26 mm
1. Speed
3. Photo/Video
(optional)
5. Throttle
7. Headless/Return
9. Unlock/one key
take o /land
11. Emergency Stop
13. Power on/o
No. Functions
1. Speed
2. Flips
3. Photo/Video (optional)
4/8. Forward/Backward trim
Throttle
5.
6. Rudder
7. Headless/Return
9. Unlock/one key/take o / land
10/12. Rightward/Lefrward trim
11. Emrgency stop
13. Power on/o
14. Indicator
Adjust the aircraft left / right / forward / backward / left / right side y speed.
This button is for 360 degree ip function , control the aircraft achieve the 3D ip function.
Touch to enter the camera function, and then tap to cancel the function. (optional)
In the vehicle to the forward (backward) movers to the backward (forward) light, press this key can make
the vehicle stable.
Up/down, left/right turn.
Forward/backward, left/right.
Touch this button, the drone can operate without recognizing the direction, and then touch
the cancel function. no return
Push up and down the remote control throttle lever to perform up and down operations.
In the vehicle to the left (right) movers to the right (left) light, press this key can make the vehicle stable.
Touch this key to quickly drop the aircraft.
Remote controls power, press the remote control power supply is turned on, press o the power.
The lamp ashes - during pairing. The lamp is constantly on - successful pairing.
Charging time: 60 min
Flight time up to 8 min
Battery - 3.7V / 240mAh Li-Po
Weight: 23g
PILOT:
Frequency 2.4GHz DSSS
Max. Communication Range 80 meters
Power by 3 x AAA dry battery (not incl.)
Dimension 11.2 x 7.7 x 5 cm
E ect
EN PL CZ SK
2. Flip
4. Forward Trim
6. Rudder
8. Backward trim
10. Leftward trim
12. Rightward trim
14. Indicator
