SIP SILVERCUT Series Instruction For Work page 120

– Place the mower into work position.
– Open the linking belts on the curtain of the front
flexible protection (1).
– Release the lever (2) for opening the front flexible
protection (1) and lift it up in order to reach the
discs.
– Replace or turn the blade with the purpose key as
shown in the figure. Pay attention to the left, right
direction of the blade mark (5) and the direction
of the disc rotation when mowing.
– Place the front flexible protection (1) into
protective position.
– Close the linking belts on the curtain of the front
flexible protection (1).
– Deposit the new blades seperately left right into
the box with cover (4). Hold the cover open with
one hand!
The correct blade position is the blade
–
with direction in the disc turning
direction.
– When one cutting edge is worn out
turn the blade and use the other
cutting edge.
– Inserted blade must be fixed in
movably.
7.4 Replacing the protective curtain
Check regularly the damage of the protective
curtain.Possible raggedness and worn out can not
stop throw outs of hard pieces out of the mower. Such
curtains must be replaced with new ones.
– Repair works, maintenance, periodical
overhauls, cleaning and elimination of
funtctional disturbances must be
performed with the switched off drive
and stand still engine! Remove the
ignition key!
