Magic Box Voice Amp & Magic Box Gold Installation Guide
2 Connecting the Magic Box Voice Amp to Your
Magic Box Gold
This section provides a description of how to connect the Sprint Magic Box Voice Amp to your already
owned Sprint Magic Box Gold, including:
 Turn off your Sprint Magic Box Gold
 Unplug the Power Supply Unit (PSU) from the wall outlet
 Carefully remove the Sprint Magic Box Voice Amp from the packaging
 Position the Sprint Magic Box Voice Amp next to your Sprint Magic Box Gold
 Connect the Cables
 Connect PSU to the Sprint Magic Box Voice Amp
 Plug the PSU into the wall outlet
Follow these step-by-step instructions to connect the Sprint Magic Box Voice Amp to your (already
owned) Sprint Magic Box Gold.
1. Ensure that the Sprint Magic Box Gold is turned off, and then disconnect the Power Supply
Unit (PSU).

Figure 1: Sprint Magic Box Gold (unplugged) - front

2. Carefully remove the Sprint Magic Box Voice Amp from its packaging.

Figure 2: Sprint Magic Box Voice Amp

DUG01373-SP Airspan Commercial and Internal Use 6
