Magic Box Voice Amp & Magic Box Gold Installation Guide
3 Connecting Magic Box Voice Amp to the Magic
Box Gold
This section provides a description of how to connect your new Magic Box Gold with your Magic Box
Voice Amp, including:
Carefully remove the Sprint Magic Box Gold from the packaging
Carefully remove the Power Supply Unit (PSU) from the packaging
Carefully remove the Sprint Magic Box Voice Amp from the packaging
Position the Sprint Magic Box Voice Amp next to Sprint Magic Box Gold
Connect the Cables
Connect PSU into the Sprint Magic Box Voice Amp
Plug the PSU into the wall outlet
Note:
Do not open your delivery until both packages arrive. The Sprint Magic Box Gold and the
Sprint Magic Box Voice Amp may ship from different warehouses and be delivered separately.
Follow these step-by-step instructions to connect the Sprint Magic Box Gold to the Sprint Magic Box
Voice Amp.
1.
Carefully remove the Magic Box Gold from its packaging.
Figure 12: Sprint Magic Box Gold - front
2.
Carefully remove the Power Supply Unit (PSU) from its packaging and place aside to be
used later.
3.
Carefully remove the Sprint Magic Box Voice Amp from its packaging.
DUG01373-SP
Airspan Commercial and Internal Use
11
