Magic Box Voice Amp & Magic Box Gold Installation Guide
9.
Connect the External GPS antenna to the GPS connection port on the side of the Sprint
Magic Box Voice Amp, under the cap.
Figure 21: External GPS Connection
10. Place the GPS antenna base on a flat surface next to a closed window.
11. Plug the Sprint Magic Gold Box power supply cable (provided with the Magic Box Gold) into
the DC IN port of the Sprint Magic Box Voice Amp.
Figure 22: Ready to Connect to Power Outlet
12. Plug the other end of the Sprint Magic Box Gold power supply cable into an available
electrical outlet. (Sprint recommends a surge protected outlet)
Note:
The Sprint Magic Box Gold must be connected to the Sprint network in order for the Sprint
Magic Box Voice Amp to work.
DUG01373-SP
Airspan Commercial and Internal Use
15
