Summary of Contents for Dialogic Vision AQR1U
- Page 1 ® Installing the Dialogic Vision™ AQR1U Server September 15, 2010 64-0605-01 Rev C www.dialogic.com...
-
Page 2: Copyright And Legal Notices
9800 Cavendish Blvd., 5th Floor, Montreal, Quebec, Canada H4M 2V9. Any authorized use of Dialogic's trademarks will be subject to full respect of the trademark guidelines published by Dialogic from time to time and any use of Dialogic’s trademarks requires proper acknowledgement. -
Page 3: Table Of Contents
One SS7 Interface, No Digital Line Interface ............. 25 Pin Assignments ....................26 RJ-45 Ethernet Interface ..................26 RJ-48C Interface ....................26 Dialogic® MD1 RJ-45 Interface ................26 Dialogic® MD1 Mini RJ-21 Interface ..............27 Detailed Dimensions .................... 28 Field Replaceable Units and Accessories .............. 29... -
Page 4: Introduction
Dialogic Corporation or its subsidiaries. The listed hardware warranty periods and terms are subject to change without notice. For purchases not made directly from Dialogic please contact your direct vendor in connection with the warranty period and terms that they offer. -
Page 5: Server Configurations
® Installing the Dialogic Vision™ AQR1U Server Server Configurations The Dialogic Vision™ AQR1U Server is available as a single or dual processor model. ® Single processor, dual disk, no power supply configurations: Product number Description VHW-007-015 No line interface or SS7 signaling interfaces. -
Page 6: Physical Description And Specifications
Rack mount kit and screws 4.15 lbs (1.9 kg) 0.65 lbs (0.3 kg) Note: The weight for the Vision AQR1U Server and the rack mount kit and screws does not include the weight for the shipping box and materials. Vision AQR1U Server dimensions... -
Page 7: Power Specifications
® Installing the Dialogic Vision™ AQR1U Server Power Specifications The following table lists the Vision AQR1U Server absolute maximum power specifications: Power supply Power component Specification Current 10 - 5 A Voltage 100 - 240 V AC Frequency 50-60 Hz... -
Page 8: Front Panel
Front Panel The following illustration shows the front panel of the Vision AQR1U Server (with the front bezel removed): Status panel The status panel consists of LEDs, panel switches and a USB connector. The status LEDs change from green to red when a fault is triggered. The P Fault LED is off unless a fault is triggered. -
Page 9: Rear Panel
Note: If a power failure occurs, the server will return to the same operational state it was in when power failure occurred. Rear Panel The following illustration shows the rear panel of the Vision AQR1U Server configured with one line interface and one SS7 signaling interface:... -
Page 10: Telecom, Ethernet, And Ss7 Interfaces
ETH4, ETH5, ETH9, ETH10 10/100/1000 Base-T Ethernet interfaces. ETH8 10/100 Base-T Ethernet interface. USB 2.0 interface. The Vision AQR1U Server may include the following interfaces: Interface Description Dialogic® MD1 Mini RJ-21 T1/E1 interface for up to eight telecom trunks. Dialogic® MD1 RJ-45 Interfaces for up to four SS7 signaling connections (on SS7 board). -
Page 11: Ss7 Interface Leds
® Installing the Dialogic Vision™ AQR1U Server SS7 Interface LEDs If your particular AQR1U configuration includes an SS7 interface, refer to the following table for a description of the LEDS: Description Ethernet ACTIVITY Ethernet link status: Yellow Steady yellow (or green) -
Page 12: Line Interface Leds
Line Interface LEDs If your particular AQR1U configuration includes a line interface, refer to the following table for a description of the LEDS: Description Ethernet There is activity on the Ethernet link. When the Ethernet has established ACTIVITY link integrity, and there is transmit or receive activity on the link, the LED flickers on. -
Page 13: Safety Precautions
Otherwise, personal injury or equipment damage can result. Maintenance: There are no user-serviceable parts inside the Vision AQR1U Server. Only technically qualified personnel should perform service and maintenance tasks. Avoid injury: Lifting the server and attaching it to the rack is a two-person job. If needed, use an appropriate lifting device. -
Page 14: Installing The Rack Mount Kit
Before you install the server, you must install a rack mount kit to support the server in the rack. The Vision AQR1U Server comes with a tool-less rail mount system and a conversion kit so that the tool-less system can be used in a rack with either square holes or M5 round holes. -
Page 15: Four-Post Rack With Square Holes
® Installing the Dialogic Vision™ AQR1U Server The following illustration shows the slide rail assembly: Four-Post Rack with Square Holes If the four-post rack at your site has square holes, refer to the instructions included in the box with the Tool-Less Blade Slide Kit. - Page 16 5. Mount the rail slides to the rack and secure them with two M5 screws at each end. There are a total of 8 screws, you will use two screws at each end of the rails. Torque to 4.5~5.0 kgf-cm (3.9 ~ 4.3 lbf-in). 6.
-
Page 17: Installing The Server
3. Connect Ethernet cables. Ethernet configurations including the number of connections and IP addressing are deployment specific. To initially configure the server, connect Eth0 and refer to Dialogic Vision™ Video Gateway Administration Manual and the Dialogic Vision™ ® ® Programmable Media Platform User’s Manual. To connect to a 10Base-T, 100Base-T, or 1000Base-T network, use shielded twisted pair (STP) Category 5 or better Ethernet cables. - Page 18 CSU or by connecting the CSU to a functioning Vision AQR1U Server. The best way to provide a loopback is to unplug the cable from the Vision AQR1U Server to the CSU. The modular connector on most CSUs loops back the transmit signal to the receive signal when nothing is plugged in.
-
Page 19: Mapping Ethernet Interfaces To Mac Address
Vision™ AQR1U Server Mapping Ethernet Interfaces to MAC Address The following illustrations show the Ethernet interfaces on the Vision AQR1U Server. Refer to these illustrations to identify the interface you are mapping the MAC address to. Refer to the compliance label on the bottom of the server for the MAC address for your... -
Page 20: Mac Address Mapping
MAC address mapping The MAC addresses listed on the compliance label correspond to the Ethernet interfaces. Use this table to determine the MAC address for a particular Ethernet interface: Note: MAC addresses shown in bold are obtained from the compliance label. Label MAC address with offset Ethernet interface... -
Page 21: Cabling Components
Installing the Dialogic Vision™ AQR1U Server Cabling Components The cabling components used for the Vision AQR1U Server may vary based on the particular configuration. This topic lists some of these components. Signal Entry Panel Dialogic® offers a signal entry panel (SEP) to simplify T1/E1 trunk termination. The signal entry panel (P/N 83252) contains two Dialogic®... -
Page 22: Cables
Cables Depending on your specific configuration, you may use one or more of the cables shown here. Dual T1/E1 120 ohm adapter cable (P/N 83230) Use the dual T1/E1 120 ohm adapter cable with the SS7 interface to split the RJ-45 interface into two RJ-48C connectors: DC power cables A 500 mm DC power pigtail cable is included with servers that come with a DC power... -
Page 23: Ac Power Cables
® Installing the Dialogic Vision™ AQR1U Server AC power cables The following table lists the available AC power cables: Part number Description ACC000001 North America Pwr crd, 2.5M, IEC 320 C13/NEMA 5-15P, 15A/125VAC: NA, Asia ACC000002 United Kingdom Pwr crd, 2M, IEC 320 C13/BS 1363, 10A/250VAC: GB... -
Page 24: Cabling The Server
Cabling the Server Vision AQR1U Server cabling is specific to the particular configuration of the server. Servers with a digital line interface may require a signal entry panel (SEP) for trunk termination. Servers with only an SS7 signaling interface have T1/E1 interfaces to terminate SS7 trunks directly. -
Page 25: Two Digital Line Interfaces
Installing the Dialogic Vision™ AQR1U Server Two Digital Line Interfaces The following illustration shows the two digital line interfaces on the Vision AQR1U Server, connecting to the rear of a signal entry panel. One SS7 Interface, No Digital Line Interface... -
Page 26: Pin Assignments
Pin Assignments The particular configuration of the Vision AQR1U Server may vary; therefore, your particular model may not have all of interfaces listed here. RJ-45 Ethernet Interface RJ-45 Ethernet interfaces use the following pin assignments: RJ-48C Interface The RJ-48C interface uses the following pin assignments: Dialogic®... -
Page 27: Dialogic® Md1 Mini Rj-21 Interface
® Installing the Dialogic Vision™ AQR1U Server Dialogic® MD1 Mini RJ-21 Interface The Dialogic ® MD1 Mini RJ-21 interface uses the following pin assignments: Trunks Transmit to network pin Receive from network pin assignments assignments 1 and 2 13 and 14... -
Page 28: Detailed Dimensions
Detailed Dimensions The following illustrations provide detailed dimensions of the Vision AQR1U Server:... -
Page 29: Field Replaceable Units And Accessories
® Installing the Dialogic Vision™ AQR1U Server Field Replaceable Units and Accessories If a component on your Vision AQR1U Server fails, field replaceable components are available for order. The following table lists the field replaceable units (FRUs) and accessories: Description...
