Installing the Dialogic® Vision™ Server TIGI2U Vision Server TIGI2U models AC model number DC model number Description VHW-001-005 VHW-002-005 No line card or signaling interfaces. VHW-001-004 VHW-002-004 One line card interface. VHW-001-003 VHW-002-003 Two line card interfaces. VHW-001-002 VHW-002-002 One line card interface and one SS7 signaling interface.
Page 4
Installing the Dialogic® Vision™ Server TIGI2U Telecom, Ethernet, and SS7 interfaces The Vision Server TIGI2U may include the following Dialogic-specific interfaces: Interface Quantity Description Dialogic® MD1 RJ-45 T1/E1 interface for up to eight telecom trunks (two each on line card and optional line card).
Installing the Dialogic® Vision™ Server TIGI2U Ethernet LEDs The following illustration shows speed and activity LEDs on line card Ethernet RJ-45 interfaces: Speed Activity Ethernet Line card Ethernet interface speed and activity LEDs provide the following indications: Description Speed Data rate of the Ethernet link.
Installing the Dialogic® Vision™ Server TIGI2U Installation overview Warning: Observe the following precautions when handling Vision Server TIGI2U equipment: Server power ON/OFF: The push-button on/off power switch on the front panel of the server does not turn off the power. To remove power from the server, you must unplug the power cord from either the power supply or wall outlet.
Page 7
Installing the Dialogic® Vision™ Server TIGI2U The following table summarizes the steps required for installing the Vision Server TIGI2U: Step Action Refer to... Install the Vision Server TIGI2U. Intel Server Deployment Toolkit CD Make a good low impedance connection to earth ground. This is...
Installing the Dialogic® Vision™ Server TIGI2U Connecting to a power source If you are installing an AC server, connect a power cord to the AC connector on the back of the server and plug the cord into an AC outlet.
Connecting SS7 signaling cables is not applicable in an ISDN deployment. Use shielded cables to connect telecom trunks or SS7 signaling connections to Dialogic® MD1 RJ-45 interfaces. Trunk interfaces are combined in dual-trunk jacks. If necessary, you can separate the dual-trunk jacks using the following components: •...
Installing the Dialogic® Vision™ Server TIGI2U Pin assignments The following illustration shows pin assignments for the Dialogic® MD1 RJ-45 dual T1/E1 interfaces: P i n 8 : ( P o r t 2 ) R - R e c e i v e f r o m n e t w o r k...
Page 11
Installing the Dialogic® Vision™ Server TIGI2U T1/E1 cabling Variations are based on the number of trunks that are installed. If the server includes more than one line card interface, maximize redundancy by distributing the trunk connections evenly between the line cards:...
The foregoing declaration is subject to the following: • Dialogic Corp Inc. claims RoHS exemption 7b. (Lead in solders for servers, storage and storage array systems, network infrastructure equipment for switching, signaling, transmission as well as network management for telecommunications).
Installing the Dialogic® Vision™ Server TIGI2U Hardware limited warranty Please refer to the following Dialogic web site for information on hardware warranty information, which applies unless different terms have been agreed to in a signed agreement between yourself and Dialogic Corporation or its subsidiaries. The listed hardware warranty periods and terms are subject to change without notice.
