We thank you and congratulate you for choosing BOS products, designed and developed by
enthusiasts, and handmade with care in France.
Please refer to the user manual available in the download section at www.bosmtb.com. It contains
the important safety, maintenance, and warranty information you will need in order to safely install
and use your BOS suspension as well as detailed set-up, tuning, and service information.
Good knowledge of your BOS product will make its day to day usage more enjoyable.
Air pressure
Whatever your weight, the air pressure should be between 100 and 220 psi.
Note : Given pressures are for guidance only. You can adjust it ± 10 psi according to your use and your riding stile
Weight (kg/lbs)
60/132
Recreational Use :
Pressure (psi)
Racing Use :
Pressure (psi)
Balancing air chambers
It is important to balance the pressure of the air chambers after each pressure adjustment to ensure
optimum performance. To do this, compress and slowly release your fork for the first 10 mm of travel
a dozen times.
Starting adjustments: from the fully closed position
Rebound (A) :
Recreational use : 10 clicks
Racing use : 8 clicks
Compression (B) : 3 Positions
-­‐  Soft  :  comfort
-­‐  Intermediate  :  hydraulic  and  grip  control
(Adjustable  intensity  :  refer  to  the  user
manual).
-­‐  Hard  :  pedaling  efficiency
65/143
120
130
125
135
70/154
75/165
140
150
145
155
Important  :   R efer   t o   t he   u ser   m anual
for   instructions   to   mount   the   axle.
This  is  essential  for  your  security.
Handmade in France
80/176
85/187
160
170
165
175
A
B
Quickstart
.
90/198
180
185
Hard
