- Page 1 FRS3004C02 QUAD SD-SDI DIGITAL VIDEO FRAME SYNCHRONIZER WITH BYPASS RELAYS Version 1.0 Albalá Ingenieros, S.A. 23 January 2017 - © Albalá Ingenieros S.A. - All rights reserved Medea, 4 - 28037 Madrid - Spain...
- Page 2 FRS3004C02...
-
Page 3: Table Of Contents
4.2. Configuration from the front panel ..................19 4.3. Functional description ....................... 19 4.4. Module remote control and supervision ................21 4.4.1. Details of the FRS3004C02 registers ................22 5. GLOSSARY ........................27 6. REGULATIONS ........................29 7. VERSIONS ......................... 31... - Page 4 FRS3004C02...
-
Page 5: Description
SNMP management and the ability to record events in a file including date and time information for further analysis. The FRS3004C02 is a TL3000 terminal line module and can be housed in a three rack unit (3 RU) UR3000 mounting frame or a 1 RU UR3100 mounting frame. -
Page 6: Features
• Module control and supervision can be done remotely when the mounting frame is equipped with a communications controller module. • One UR3000 mounting frame can house up to 12 FRS3004C02 modules. If power supply redundancy is required and FA3000 or FA3001 modules are used then only 10 modules can be housed in the mounting frame. -
Page 7: Block Diagram
Albalá Ingenieros | Manual FRS3004C02 1.3. Block diagram... - Page 8 Albalá Ingenieros | Manual FRS3004C02 FRS3004C02...
-
Page 9: Specifications
Albalá Ingenieros | Manual FRS3004C02 2. SPECIFICATIONS SD-SDI digital video signal input Connector Impedance 75 Ω ± 1 % Return loss >15 dB up to 270 MHz Input return loss when bypass is active >15 dB up to 270 MHz... - Page 10 Albalá Ingenieros | Manual FRS3004C02 Approximate weight 350 g...
-
Page 11: Installation
ELECTROSTATIC DISCHARGE. Always use antistatic bags clearly identified with a high degree of shielding for storage and transportation. The FRS3004C02 module is composed of two parts: one FRS3004P01 main board and one FRS3004P02 rear board. Both parts must be installed in a UR3000 or UR3100 mounting frame following the instructions in the corresponding section of this chapter. -
Page 12: Environmental Considerations
3.4. Power considerations The UR3000 and UR3100 mounting frames can house as many FRS3004C02 modules as will fit in them. 3.5. Module configuration The FRS3004C02 contains microswitches that should be configured before installing the module into mounting frame. -
Page 13: Installing The Module In The Mounting Frame
FRS3004C02 3.6. Installing the module in the mounting frame The steps needed to install the FRS3004C02 module with the rear board in the mounting frame are: 1 - Disconnect all power cords from the power supplies of the mounting frame. -
Page 14: Interconnection
The following figure shows the FRS3004C02 module rear board connector layout. Rear view of the FRS3004C02 The FRS3004C02 provides four digital video inputs (SDI IN1, SDI IN2, SDI IN3 and SDI IN4), two synchronized digital video outputs for each of the inputs (SDI OUT1, SDI OUT1p, SDI OUT2, SDI OUT2p, SDI OUT3, SDI OUT3p, SDI OUT4 and SDI OUT4p) and one input with loop-through for analog or digital references (REF. -
Page 15: Electrical Sdi Video Connections
All coaxial cable used must be Belden 8281 or similar. This type provides the greatest lengths because it is used to calculate the equalizers in the FRS3004C02. Cables carrying signal between the module and the devices should use single piece construction, avoiding spliced sections with double BNC female or barrel connectors. - Page 16 Albalá Ingenieros | Manual FRS3004C02 FRS3004C02...
-
Page 17: Operation
Albalá Ingenieros | Manual FRS3004C02 4. OPERATION This section describes the significance of the front panel indicators of the FRS3004C02 module and their remote control and monitoring ability. 4.1. Front panel description The appearance of the front panel and the elements it contains are shown in the following illustration. - Page 18 Albalá Ingenieros | Manual FRS3004C02 In the REFERENCE box: LOCKED: Blue. This LED lights up when the module is properly synchronized to the reference. ANALOG/DIGITAL: Green. This LED lights up when the module expects to receive an analog reference. It stays off when the module expects a digital reference.
-
Page 19: Configuration From The Front Panel
4.3. Functional description The FRS3004C02 includes a module for synchronizing to the reference signal as well as four identical sections for synchronizing and processing each input. Each input signal is deserialized and if the data received is valid then it is stored in the frame memory. - Page 20 Albalá Ingenieros | Manual FRS3004C02 the digital stream for error detection as per SMPTE RP 165. If one of the input signals is lost, the module can operate as a line synchronizer or frame synchronizer. In each of these two modes the detection of a sync error in the input signal stops the writing of data to the frame memory.
-
Page 21: Module Remote Control And Supervision
Albalá Ingenieros | Manual FRS3004C02 4.4. Module remote control and supervision The FRS3004C02 can optionally be remotely controlled/supervised. In order to perform remote configuration and supervision of the module an optional TL3000 family remote communications controller must be installed in the mounting frame. -
Page 22: Details Of The Frs3004C02 Registers
- Supervision of the status of the reference input an the inputs to be synchronized. 4.4.1. Details of the FRS3004C02 registers The FRS3004C02 module provides control and status registers that can be read and written by means of specific commands described in the communication control module user manuals. - Page 23 Albalá Ingenieros | Manual FRS3004C02 CHROMA_GAIN_1 0x07 0xFF Allows adjusting the chorma gain (Section 1) = x/128 BLACK_OFFSET_1 0x08 0xFF Allows adjusting the black offset (Section 1) = 0.781*x mV H_DELAY_2 0x09 0x07FF Allows adjusting the video horizontal delay (Section 2) = 37.037*x ns...
- Page 24 Albalá Ingenieros | Manual FRS3004C02 ACT_EDH_REF 0x02 0x01 Reference active picture EDH bit status 0=OK,1=Fail ACT_EDA_REF 0x02 0x02 Reference active picture EDA bit status 0=OK,1=Fail ACT_IDH_REF 0x02 0x04 Reference active picture IDH bit status 0=OK,1=Fail ACT_IDA_REF 0x02 0x08 Reference active picture IDA bit status...
- Page 25 Albalá Ingenieros | Manual FRS3004C02 FULL_UES_3 0x07 0x10 Full field UES bit status (Section 3) 0=OK,1=Fail EDH_PCK_ERR_3 0x07 0x20 Valid EDH packet status (Section 3) 0=OK,1=Fail EDH_PRES_3 0x07 0x40 EDH packet presence (Section 3) 0=No, 1=Yes EDH_ERROR_3 0x07 0x80 Indicates error in SDI signal (Section 3)
- Page 26 Albalá Ingenieros | Manual FRS3004C02 FRS3004C02...
-
Page 27: Glossary
Albalá Ingenieros | Manual FRS3004C02 5. GLOSSARY Error Detection and Handling. A system for detection of errors in SD-SDI signal transmission. It consists of the insertion of a CRC (Cyclic Redundancy Check) packet at the end of each video field to check the data in that field. The receiving equipment calculates the CRC for the data received and compares it with the CRC received in the packet to determine if errors are present in the transmission. - Page 28 Albalá Ingenieros | Manual FRS3004C02 FRS3004C02...
-
Page 29: Regulations
Albalá Ingenieros | Manual FRS3004C02 6. REGULATIONS ITU-R BT.470-6 (1998) Conventional analogue television systems. See also: ITU-R BT.1700, SMPTE 170M SMPTE RP 165 (1994) Error Detection Checkwords and Status Flags for Use in Bit-Serial Digital Interfaces for Television. SMPTE ST 259 (2008) SDTV Digital Signal/Data Serial Digital Interface. - Page 30 Albalá Ingenieros | Manual FRS3004C02 FRS3004C02...
-
Page 31: Versions
Albalá Ingenieros | Manual FRS3004C02 7. VERSIONS Ver. Date Description 13-06-2013 Preliminary Version 23-01-2017 First version... - Page 32 Albalá Ingenieros, S.A. Medea, 4 - 28037 Madrid Spain +34 913274453 www.albalaing.com info@albalaing.com...
