User Guide
8ft x 12ft Oval Trampoline
Model: JK812
The trampoline / enclosure is designed for users weighing 90kg (200lbs) or less.
Got a Problem building your trampoline?
Call us on 1-877-927-8777 8am - 5pm CT Monday to Friday and we can help
WARNING: Read these assembly instructions carefully
before attempting to assemble or use this product. Keep
this user guide in a safe place for future reference.
®
Jumpking
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Jumpking JK812
Summary of Contents for Jumpking JK812
- Page 1 User Guide 8ft x 12ft Oval Trampoline Model: JK812 The trampoline / enclosure is designed for users weighing 90kg (200lbs) or less. Got a Problem building your trampoline? Call us on 1-877-927-8777 8am - 5pm CT Monday to Friday and we can help WARNING: Read these assembly instructions carefully before attempting to assemble or use this product.
- Page 3 8ft x 12ft Oval Trampoline Model: JK812 your Support...
- Page 4 Climb on and off the trampoline. It is a dangerous Adequate overhead clearance is essential. A practice to jump from the trampoline to the floor or minimum of 7.3m (24ft) above the ground is ground when dismounting, or to jump onto the recommended.
- Page 5 Stop bouncing by flexing knees as feet come in contact with the trampoline bed. Learn this skill before attempt- ing others. Please do NOT wear jewelry when jump on trampolines.
- Page 6 Thank you for selecting a Jumpking trampoline / enclosure. “Jumpking” is designed and crafted to provide many years of fun and fitness. This trampoline/enclosure comes equipped with warnings and instructions for the assembly, care, maintenance and use of the trampoline/enclosure. This information must be...
-
Page 15: What You Will Need
BUILDING YOUR TRAMPOLINE 1. This is a 2 person build. 2. Time for build is approximately 2 hours. 3. Choose a good location: (wood chippings, sand or grass). (7.3m) from ground level, away from wires, trees and other possible hazards. (2.5m) around sides, away from walls, fences, structures, asphalt and other hard surfaces and play areas. -
Page 16: Parts List
PARTS LIST Part Part Part Part Part Description: Description: Top Tube with Top Tube with Description: Description: T-Connector + T-Connector + Description: Leg extensions Center legs welded tube Springs welded tube Quantity: 8 Quantity: 4 Quantity: 64 6 top 2 bottom 6 top 2 bottom Quantity: 2 Quantity: 6... -
Page 17: Step 1 : Assembling The Frame
STEP 1 : ASSEMBLING THE FRAME You will need the following parts to complete Top tube step 1: 6 x Top Tubes with T-connector - Part A 2 x Top Tubes with T-connector - Part B 4 x Center legs - Part C Top tube 8 x Leg extensions - Part D Center leg... - Page 18 Insert another leg extension into the other end of the center leg. Important: The frame is held together under tension so you will have to use some force to insert certain parts. Place your feet on the top tubes and grip the leg extension with both hands.
- Page 19 STEP 2 : ASSEMBLING THE FRAME This step will require 2 people who must be wearing gloves. Slot two of the frame section together as shown in the diagram. While one person holds the assembled sections upright, the other person can insert a second section onto the end of the assembled sections.
- Page 20 STEP 3 : FITTING THE STITCHED BED This step will require 2 people who must be wearing gloves and protective eye wear. Lay the stitched bed (with the V-Rings) out inside the frame of the trampoline with the warning labels facing upwards.
- Page 21 Attach a spring to the opposite yellow stitched V-Ring. Important: You will now need to use the spring tool to attach the spring to the frame. Hook the spring tool onto end of spring, and pull until the spring can be slotted into the spring slot on the top of the frame.
- Page 22 STEP 4 : FITTING THE FRAME PAD Enclosure Frame Opening This step will require 2 people. Lay the frame pad - Part G out over the edge of the frame with the ties facing downwards. Notches Align the openings in the frame pad with the T-connector+welded tubes on the frame.
- Page 23 STEP 5 : FITTING THE ENCLOSURE TUBES Top enclosure tube You will need the following parts to complete step 5: - Part H 8 x Bottom enclosure tubes Bottom enclosure tube - Part I 8 x Top enclosure tubes 8 x Self tapping screws - Part L Self tapping screw and washer You will also need a phillips-head screwdriver (not supplied).
- Page 24 Insert the bottom enclosure tube into the tubes in the T-connector+welded tubes visible through the slots in the frame pad. Assemble the remaining enclosure tubes using the remaining self tapping screws and the phillips-head screwdriver. Insert each enclosure pole into an enclosure pole cover to protect the foam sleeves.
- Page 25 STEP 6 : FITTING THE ENCLOSURE NETTING You will need the following parts to complete step 6: 2 x Black G3 poles - Part J Black G3 poles 1 x Enclosure netting - Part K Enclosure netting Lay the enclosure netting out on the trampoline. Find the sleeves that run along the top of the enclosure netting.
- Page 26 Insert one of the Black G3 poles through three of the sleeves on the top of the enclosure netting. Insert the remaining Black G3 poles through the three other sleeves on the top of the enclosure netting. You will now join the two ends of the Black G3 will require two people.
- Page 27 Attach the exposed sections of the FRP rods to the enclosure tubes in the order shown in the diagram. The enclosure net is now and you have completed step 6.
- Page 28 STEP 7 : ATTACHING THE BOTTOM OF THE NET You will need the following parts to complete step 7: 2 x Cords - Part N. Tie the non-plastic end of the cord around a V-Ring. Push the red plastic end through a hole in the bottom of the netting.
-
Page 29: Using The Trampoline
USING THE TRAMPOLINE Before using your trampoline, check again that there is enough clearance around it. Maintain a clear space of 2.5 meters (8.2 feet) on all sides of the trampoline. 2.5m Also check that the area is free from walls, structures, fences, tarmac and other hard surfaces 8.2ft and other play areas. - Page 30 17 to 28...
- Page 31 Top Tube (With Welded T-connector) 8 Enclosure Bottom Tube Top Tube (With Welded T-connector) Enclosure Top Tube Welded T-connector Plastic Cap ( This part has been attached Leg extension to the top of the top curve pole) W leg Foam Sleeves 1 Stitched Bed with V-rings Netting with attached Hardware Self-tapping Screw...
