12ft (3.66m) Jumpking Classic Premium
Got a Problem building your trampoline?
Call us on 0344 800 4060 and we can help
Patent no: DE602006006495D1, EP1721640B1 and US7628731
WARNING: Read these assembly instructions carefully
before attempting to assemble or use this product. Keep
this user guide in a safe place for future reference.
User Guide
Advertisement
Table of Contents
Related Manuals for Jumpking JumpPOD Classic Premium
Summary of Contents for Jumpking JumpPOD Classic Premium
- Page 1 User Guide Made In China 12ft (3.66m) Jumpking Classic Premium Got a Problem building your trampoline? Call us on 0344 800 4060 and we can help Patent no: DE602006006495D1, EP1721640B1 and US7628731 WARNING: Read these assembly instructions carefully before attempting to assemble or use this product. Keep...
- Page 2 IMPORTANT INFORMATION . WARNING! ADULT SUPERVISION & GUIDANCE REQUIRED AT ALL TIMES. . Recommended age 6+ years. . No somersaults or flips - can cause serious injury. WARNINGS! . Only for domestic use. . Maximum user weight limit 115 kg. .
-
Page 3: Important Precautions
IMPORTANT PRECAUTIONS surface. 1 user allowed at any one time. This can result in serious injury to head, neck, arms or legs. JUMPING INSTRUCTIONS Fundamental Bounce Knee Drop Hand and Knee Drop Start bouncing from a standing Start from a standing position with Start bouncing from a standing your head erect and your eyes on the position, keeping your eyes on the... -
Page 4: Care And Maintenance
CARE & MAINTENANCE Regular care and maintenance of your trampoline is required. This will help prolong its life and reduce the possibility of injury. Neglecting this can lead to a risk for users. Inspect your trampoline before each use using the checklist below as a guide. Take particular care in doing this at the start of each season and at regular intervals. -
Page 5: What You Will Need
BUILDING YOUR TRAMPOLINE 1. This is a 2 person build. 2. Time for build is approximately 2 hours. 3. Choose a good location: (wood chippings, sand or grass). (7.3m) from ground level, away from wires, trees and other possible hazards. (2.5m) around sides, away from walls, fences, structures, tarmac and other hard surfaces and play areas. -
Page 6: Parts List
PARTS LIST Part Part Part Part Description: Description: Description: Description: op Tube with Top Tube with Leg extensions Centre legs POD-connector T-Connector Quantity: 10 Quantity: 5 Quantity: 5 Quantity: 5 Part Part Part Part Description: Description: Description: Description: Stitched bed 7”... -
Page 7: Step 1 : Assembling The Frame
STEP 1 : ASSEMBLING THE FRAME Top tube You will need the following parts to complete section 1: Top tube 5 x Top Tubes with POD-connector - Part A 5 x Top Tubes with T-connector - Part B 5 x Centre legs - Part C Centre leg 10 x Leg extensions - Part D Leg extension... - Page 8 Slot another leg extension onto the other end of the centre leg. Important: The frame is held together under tension so you will have to use some force to insert certain parts. Place your feet on the top tubes and grip the leg extension with both hands.
- Page 9 STEP 2 : ASSEMBLING THE FRAME This step will require 2 people who must be wearing gloves. Slot two of the frame section together as shown in the diagram. At this point you will need to ensure you can see spring holes in the gaps of the POD-connector.
- Page 10 Green Locate the 5 V-rings with Green webbing. webbing These will be at 72 to each other. Slot one of the springs Part G onto one of the green webbing V-rings as shown. Important: springs must be slotted on the right way around.
- Page 11 gold green webbing green webbing On the right side of each POD connector POD-connector using Gold Springs. Once you have the 5 Green V rings attached continue attaching the rest of the Gold springs to the left side of the POD connector.
- Page 12 STEP 4 : FITTING THE FRAME PAD This step will require 2 people. Lay the frame pad - Part H out over the edge of the frame with the ties facing downwards. Align the openings in the frame pad with the POD-connector's on the frame.
- Page 13 STEP 5 : FITTING THE ENCLOSURE TUBES Top enclosure tube You will need the following parts to complete step 5: 5 x Top enclosure tubes - Part I Bottom enclosure tube 5 x Bottom enclosure tubes - Part J 5 x Self tapping screws and washers - Part K Self tapping screw and washer You will also need a cross-head screwdriver (not supplied).
- Page 14 Slot the bottom enclosure tube into the tubes in the POD-connector tubes visible through the slots in the frame pad. Assemble the remaining enclosure tubes using the self tapping screws and the cross-head screwdriver. Slot the remaining enclosure tubes into the 4 remaining POD-connector's on the frame.
- Page 15 STEP 6 : FITTING THE ENCLOSURE NETTING You will need the following parts to complete step 6: 2 x Black G3 poles - Part L Black G3 poles 1 x Enclosure netting - Part M Enclosure netting Lay the enclosure netting out on the trampoline. Find the sleeves that run along the top of the enclosure netting.
- Page 16 Slot one of the Black G3 poles through three of the sleeves on the top of the enclosure netting. Slot the remaining Black G3 poles through the three other sleeves on the top of the enclosure netting. You will now join the two ends of the Black G3 will require two people.
- Page 17 You may need to slide the connected poles around in the nettings sleeves until the thin black sections are aligned with the gaps between sleeves. With the netting hanging on the inside of the enclosure poles, stand on the trampoline and insert one of the exposed sections of the Black G3 pole into a plastic grip on top of one of the enclosure tubes.
- Page 18 STEP 7 : ATTACHING THE BOTTOM OF THE NET You will need the following parts to complete step 7: 8 x Cords - Part N. Tie the non-plastic end of the cord around a V-Ring. Push the plastic end through a hole in the bottom of the netting.
-
Page 19: Using The Trampoline
USING THE TRAMPOLINE Before using your trampoline, check again that there is enough clearance around it. Maintain a clear space of 2.5 metres (8.2 feet) on all sides of 2.5m the trampoline. 8.2ft Also check that the area is free from walls, structures, fences, tarmac and other hard surfaces and other play areas. -
Page 20: Spare Parts
To order replacement parts, you can email us on: customerservice@yjeurope.co.uk, or call our Customer Helpline on: 0344 800 4060. To help us assist you, please provide the following information when calling: 12 FT (3.66M) JUMPKING CLASSIC PREMIUM TRAMPOLINE (see parts list below). T-Connector...
