10ft x 14ft Rectangle Combo
Got a Problem building your trampoline?
Call us on 0344 800 4060 and we can help
Patent no: DE602006006495D1, EP1721640B1 and US7628731
WARNING: Read these assembly instructions carefully
before attempting to assemble or use this product. Keep
this user guide in a safe place for future reference.
User Guide
Advertisement
Table of Contents
Related Manuals for Jumpking JKR1014G16
Summary of Contents for Jumpking JKR1014G16
- Page 1 User Guide Made In China 10ft x 14ft Rectangle Combo Got a Problem building your trampoline? Call us on 0344 800 4060 and we can help Patent no: DE602006006495D1, EP1721640B1 and US7628731 WARNING: Read these assembly instructions carefully before attempting to assemble or use this product. Keep this user guide in a safe place for future reference.
- Page 2 IMPORTANT INFORMATION . WARNING! ADULT SUPERVISION & GUIDANCE REQUIRED AT ALL TIMES. . Recommended age 6+ years. . No somersaults or flips - can cause serious injury. WARNINGS! . Only for domestic use. . Maximum user weight limit 140 kg. .
-
Page 3: Important Precautions
IMPORTANT PRECAUTIONS surface. 1 user allowed at any one time. This can result in serious injury to head, neck, arms or legs. JUMPING INSTRUCTIONS Fundamental Bounce Knee Drop Hand and Knee Drop Start bouncing from a standing Start from a standing position with Start bouncing from a standing your head erect and your eyes on the position, keeping your eyes on the... -
Page 4: Care And Maintenance
CARE & MAINTENANCE Regular care and maintenance of your trampoline is required. This will help prolong its life and reduce the possibility of injury. Neglecting this can lead to a risk for users. Inspect your trampoline before each use using the checklist below as a guide. Take particular care in doing this at the start of each season and at regular intervals. -
Page 5: What You Will Need
BUILDING YOUR TRAMPOLINE 1. This is a 2 person build. 2. Time for build is approximately 2 hours. 3. Choose a good location: (wood chippings, sand or grass). (7.3m) from ground level, away from wires, trees and other possible hazards. (2.5m) around sides, away from walls, fences, structures, tarmac and other hard surfaces and play areas. -
Page 6: Parts List
PARTS LIST Part Part Part Part Part Description: L-Top tube Description: Description: Description: Description: Quantity: 4 Top Tube Top Tube Leg extensions Centre legs 2 x ABL - Top Tube A, D marking B, C marking Quantity: 8 Quantity: 4 2 x CDL - Top Tube Quantity: 2 Quantity: 2... -
Page 7: Step 1 : Assembling The Frame
STEP 1 : ASSEMBLING THE FRAME You will need the following parts to complete L-Top tube section 1a: 4 x L-Top tube with Welded connector - Part A & Q (2 pcs one side A marking and one side B marking, 2 pcs one side C marking and one side D marking) - Part B Top tube B, C marking... - Page 8 Important: The frame is held together under tension so you will have to use some force to insert certain parts. Place your feet on the top tubes and grip the leg extension with both hands. Pull the extension until it can be slotted into the T-connector.
- Page 9 STEP 2 : ASSEMBLING THE FRAME This step will require 2 people who must be wearing gloves. Slot two of the frame section together as shown in the diagram. You will now need to slot the frame together, this will take some force. The easiest method is if the two people face each other.
- Page 10 STEP 3 : FITTING THE STITCHED BED Part H This step will require 2 people who must be wearing gloves and protective eye wear. Lay the stitched bed (with the V-Rings) out inside the frame of the trampoline with the warning labels facing upwards.
- Page 11 Attach a spring to the corner V-ring. Important: You will now need to use the spring tool to attach the spring to the frame. Hook the spring tool onto end of spring, and pull until the spring can be slotted into the spring slot on the top of the frame.
- Page 12 STEP 4 : FITTING THE FRAME PAD This step will require 2 people. Lay the frame pad - Part I out over the edge of the frame with the ties facing downwards. Align the openings in the frame pad with the T-connector+welded tube's on the frame.
- Page 13 STEP 5 : FITTING THE ENCLOSURE TUBES Bottom enclosure tube You will need the following parts to complete step 5: - Part J 8 x Bottom enclosure tubes Top enclosure tube 8 x Top enclosure tubes - Part K 8 x Self tapping screws & washers - - Part N Self tapping screw and washer You will also need a cross-head screwdriver (not supplied).
- Page 14 Slot the bottom enclosure tube into the tubes in in the frame pad. Repeat this step for the remaining seven enclosure poles. Slot the eight enclosure tubes into the T -connector+welded tube's on the frame. Screw the enclosure poles into the T-connector+welded tube, securing them to the frame.
- Page 15 STEP 6 : FITTING THE ENCLOSURE NETTING You will need the following parts to complete step 6: 2 x Black G3 poles - Part L and R (2 x Long Sections 2 x Short Sections) 1 x Enclosure netting - Part M Black G3 poles Enclosure...
- Page 16 Attach the seven other exposed sections of the G3 rods to the other enclosure tubes in the order shown in the diagram. Ensuring the four corners of the FRP Rods are in the exposed sections. The enclosure net is now and you have completed step 6.
- Page 17 STEP 7 : ATTACHING THE BOTTOM OF THE NET You will need the following parts to complete step 7: 8 x Cords - Part P. Tie the non-plastic end of the cord around a V-Ring. Push the plastic end through a hole in the bottom of the netting.
-
Page 18: Using The Trampoline
USING THE TRAMPOLINE Before using your trampoline, check again that there is enough clearance around it. Maintain a clear space of 2.5 metres (8.2 feet) on all sides of the trampoline. Also check that the area is free from walls, structures, fences, tarmac and other hard surfaces 2.5m and other play areas. -
Page 19: Spare Parts
2 pcs C marking, 2 pcs D marking) W-Leg Leg Extention Stitched Bed with V-ring Frame Pad 7” Length Springs Spring pulling tool For a full range of accessories and replacement parts call 0344 800 4060 or visit our web site at: www.jumpking.eu...
