- Page 1 DVD-3205P...
-
Page 2: Table Of Contents
CONTENTS Page Disassembly Instructions ............................. 3 Disassembly Diagram............................4 Block Diagram ..............................5 Printed Circuit Board............................6 Exploded View ..............................12 Exploded View Parts List ........................... 13 Schematic Diagram ............................14 Electrical Parts List ............................21 Specifications..............................25... -
Page 3: Disassembly Instructions
DISASSEMBLY INSTRUCTIONS 1. Remove three screws (A) from located on the rear of the rear bracket then remove the Rear Bracket. 2. Remove two screws (B) from each side of the bottom covet then remove the Top Cover. 4. Remove two screws (C) and two screws (D) from located on the bottom cover. 5. -
Page 4: Disassembly Diagram
DISASSEMBLY DIAGRAM... -
Page 5: Block Diagram
BLOCK DIAGRAM... -
Page 6: Printed Circuit Board
PRINTED CIRCUIT BOARDS MAIN BOARD TOP VIEW... - Page 7 MAIN BOARD BOTTOM VIEW...
- Page 8 KEY BOARD TOP VIEW...
- Page 9 KEY BOARD BOTTOM VIEW...
- Page 10 REMOTE BOARD TOP VIEW...
- Page 11 REMOTE BOARD BOTTOM VIEW...
-
Page 12: Exploded View
EXPLODED VIEW... -
Page 13: Exploded View Parts List
EXPLODED VIEW PARTS LIST Ref. No. Description RS Part No. Mfr’s Part No. Top Cover (S. OPC1202) 61-E2402-80S Bottom Cover (S. OPC1202) 61-E2401-80S Rear Bracket (S. OP1202/Black) 61-E2403-81B Panel (S. PMS8002/PMS430C) 51-E2420-81Y Main PCB Paper 43-E2402-00 Main Board 11-02460-007 Front Bracket 39-E2401-00 DVD MECH. -
Page 14: Schematic Diagram
SCHEMATIC DIAGRAM (SERVO) - Page 15 SCHEMATIC DIAGRAM (MPEG)
- Page 16 SCHEMATIC DIAGRAM (POWER)
- Page 17 SCHEMATIC DIAGRAM (D/A)
- Page 18 SCHEMATIC DIAGRAM (AV/POWER-IN/OUT)
- Page 19 SCHEMATIC DIAGRAM (KEY BOARD)
- Page 20 SCHEMATIC DIAGRAM (REMOTE BOARD)
-
Page 21: Electrical Parts List
Ref. No. Parts No. Description Q’ty PC BOARD ASSY, MAIN BOARD Q2,7,16/7/9,24/5 01-00106-00 KRA106S (SOT-23) Q3,5,14/5 01-00106-10 KRC106S (SOT-23) Q9,20/1 01-00231-00 KRC231S (SOT-23) QQ1,2,QV1,2 01-01298-00 KTA1298 (SOT-23) 01-01385-00 KTA1385D-Y (DPAK) Q1,8,QQ4 01-03265-00 KTC3265-Y (SOT-23) Q10/3 01-04375-00 TR. KTC4375-Y (SOT-89) 02-04001-01 CHIP IN4001 (SOD-106) D4,6,7,9~17,DD2,3,6,8 02-04148-02... - Page 22 Ref. No. Parts No. Description Q’ty C38,41 05-63151-00 CHIP CAP 150PF ±5% NPO 0603 SMT C249 05-63200-00 CHIP CAP 20PF ±5% NPO 0603 SMT C20/1,248 05-63330-00 CHIP CAP 33PF ±5% NPO 0603 SMT C3,9,CC8,59 05-63470-00 CHIP CAP 47PF ±5% NPO 0603 SMT C24/6~8,196/7,CC16/7 05-63471-00 CHIP CAP 470PF ±5% NPO 0603 SMT...
- Page 23 Ref. No. Parts No. Description Q’ty R192,RR19 07-63222-01 CHIP RES 2.2kΩ ±5% 0603 SMT RV8,R45,53 07-63223-00 CHIP RES 22kΩ ±5% 0603 SMT R296 07-63271-00 CHIP RES 270Ω ±5% 0603 SMT R44,RR18,98 07-63330-00 CHIP RES 33Ω ±5% 0603 SMT R12~4,20,46/9,50/4,101,RA5,6 07-63332-00 CHIP RES 3.3kΩ...
- Page 24 Ref. No. Parts No. Description Q’ty 03-06312-00 IC PT6312LQ ANGUS 03-07805-02 KIA 78L05F (SOT-89) CF3~5 05-63101-00 CHIP 100PF ±5% NPO 0603 SMT CF6~8 05-63104-02 CHIP CAP 0.1µF ±20% Y5V 0603 SMT CF1,2 06-10476-01 E. CAP 47µF 10V (Ø4X7 MINI) RF13 07-63102-00 CHIP RES 1kΩ...
-
Page 25: Specifications
SPECIFICATIONS Current Consumption ........................... Less than 2.0A Signal System ................Competitive video 1.0Vp-p 75Ω RCA pin jack Audio Output Level ......................600Ω (2CH 2.0Vrms) Audio Signal Output Characteristics: Frequency Response........................20 Hz - 20 kHz S/N Radio............................90 dB (JIS) Wow and flutter ......................Below Measurable Limits Note: Specifications and design are subject to modification, without notice, due to improvements in technology.
