Flash memory MCU PROGRAMMER
FLASH2
USER'S MANUAL
For the Operation Procedures
Windows Japanese Environment
COVER&CONTENTS
IMPORTANT ......................................................................................... 1
MATTERS ON SAFETY ............................................................................... 1
THINGS OF IMPORTANCE ......................................................................... 1
LIMITED GUARANTEE ................................................................................ 1
WHAT THIS GUARANTEE DOES NOT INCLUDE ...................................... 1
FLASH2 Features ................................................................................ 2
Product and contained accessories ............................................................. 2
The provided CD includes ............................................................................ 2
Specifications ............................................................................................... 3
Parts Name .................................................................................................. 4
Connectors & Cables ................................................................................... 5
How to Purchase the Upgrading Control Software ....................................... 5
Preparation -Control Software Install- ............................................ 6
Programming Procedure .................................................................... 7
Operation Flow ............................................................................................. 7
Control Software Open ................................................................................. 7
Parameters................................................................................................... 8
File Loading.................................................................................................. 9
Execute programming ................................................................................ 10
Ending Control Software Operation ............................................................ 10
Programming Expanded Memory of ROM-less MCU ................................. 10
◆ About programming onto V850 series ..................................................... 13
◆ Command line option ............................................................................... 14
Dealing with Errors ........................................................................... 15
Error Message Table - F2WinV2-............................................................. 15
LED Status of FLASH2 and Trouble Shootings .......................................... 16
Timing chart of boot mode control .............................................................. 17
Correspondence MCU ....................................................................... 18
Version upgrade ................................................................................ 18
Optional items ................................................................................... 18
Includes .............................................................................................. 18
FLASH2 control software requires WindowsXP, WindowsVista, Windows7 ,
Windows8.1, Windows10 Japanese version as OS environment, Microsoft products.
Contents
REV.2.4.0.0
HOKUTO DENSHI CO.,LTD.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FLASH2 and is the answer not in the manual?

Questions and answers

Related Manuals for Hokuto Electronic FLASH2

Summary of Contents for Hokuto Electronic FLASH2

  • Page 1: Table Of Contents

    ◆ Command line option ................14 Dealing with Errors ................15 Error Message Table - F2WinV2-............. 15 LED Status of FLASH2 and Trouble Shootings .......... 16 Timing chart of boot mode control .............. 17 Correspondence MCU ............... 18 Version upgrade ................18 Optional items ...................

  • Page 2: Important

    The FLASH2 is to be used by connecting with systems containing the Renesas Electronics made MCU ● with flash memory built-in microcomputer. The FLASH2 is not to be used for any other purpose other than that which is specified in the manual.

  • Page 3: Flash2 Features

    We would like to thank you for the purchase of our on-board programmer FLASH2. This FLASH2 has been designed for the on-board programming of Renesas Electronics’s Flash memory MCU enhanced Microcomputer. FLASH2 circuit management at programming to flash memory is fully automated.

  • Page 4: Specifications

    (*1) When using with Windows 95, 98, Me Copy F2WinV2.exe in "Japanese/for_Windows95_98_Me" to PC storage and execute. As of 2020/2, it is difficult to maintain an old OS machine for verification, so we will remove it from support. HOKUTO DENSHI CO;LTD; FLASH2 株式会社...

  • Page 5: Parts Name

    (-) of the battery holder could come into contact with positive terminal (+) inside of the flexible insulating label as shown in the diagram below. It causes electrical short-circuit. Please do not use the batteries described above. Electrical short-circuit may cause smoke and fire. HOKUTO DENSHI CO;LTD; FLASH2 株式会社...

  • Page 6: Connectors & Cables

    UserVcc LED indicates the status of FLASH2 power on/off. Both 2 dry alkaline cells and AC adapter can be used as a power supply for the FLASH2 itself. And also FLASH2 needs UserVcc from the connected target board. UserVcc LED can light when the both power supply are enough to operate.

  • Page 7: High Speed Clocked Synchronous Communication Of Flash Mate 5V1

    Clocked synchronous mode writing cannot be carried out by FLASH2. Only our FLASH MATE 5V1 can realize the fast transfer in writing. As for FLASH2 and FLASH MATE 5V1 you can choose both solution without modification about connector, signal and reference circuit diagram; these are in common.

  • Page 8: Programming Procedure

    □ Power On To start the operation, FLASH2 power status must be checked, that is indicated with the UserVCC LED on the programmer body. It is necessary to supply both power into programmer itself with AC adapter or alkaline dry cells and with UserVcc from the target.

  • Page 9: Parameters

    Terminal State window. If user would like to manage into boot mode before the operation with the own idea, those ports do not have to connect with FLASH2. Refer to the advices for arrangements in “User’s Guide”.

  • Page 10: File Loading

    For each mat, the program must be arranged form the begging. □ Third file When the MCU which has the user boot mat and the date flash was selected, the file menu and the file information box is indicated as follows. HOKUTO DENSHI CO;LTD; FLASH2 株式会社...

  • Page 11: Execute Programming

    Select “exit” from “File” in menu bar. ＊ All the parameters are saved at closing the control software.  Programming Expanded Memory of ROM-less MCU FLASH2 can program the expanded memory of the following ROM- less MCU. Available MCU Type H8SX/1650, H8SX/1651...
  • Page 12 The programming control program can’t be selected, if the MOT/HEX file doesen’t exist in the appropriate folders like in the right description. C:¥Program Files(x86)¥FLASH 2¥FMWR¥H8Sx1650¥ The interface of the target board See the description in H8SX/1650 in the User’s Guide. HOKUTO DENSHI CO;LTD; FLASH2 株式会社...

  • Page 13: About Programming Onto R8C,M16C,R32C,M32C Series

    Please refer to MCU hardware manual for examples of connection Serial Programmer and MCU. Please refer to “E8a Emulator user’s manual” for this pin assign. Please use programming tools with appropriate version of control software. Please refer to the instruction manual for each connection on the target board. HOKUTO DENSHI CO;LTD; FLASH2 株式会社...

  • Page 14: Writing Restriction By On-Chip Oscillator Of R8C Group

    （conversion unit only） how to connect Cable Name 20-16pin V850 Attached cable 20<->16pin V850 Conversion unit FLASH2 Included － Group of V850ES/Jx2,Jx3-L supported V850E/Ix3 Target board Conversion unit Price ¥2,000 Please use “F2WinV2.exe” for control software. HOKUTO DENSHI CO;LTD; FLASH2 株式会社...

  • Page 15: Command Line Option

    Please do the designation of the file referring to the following example. <path>” C:/Program△Files(x86)/FLASH2/F2WinV2.exe”△”△-o1=XXXX△-o2=YYYY△-o3=ZZZZ△-e” The definition of F2WinV2 User Mat -o1=XXXX User Boot Mat -o2=YYYY Data Flash -o3=ZZZZ No error output （△= space, XXXX,YYYY,ZZZZ=MOT/HEX file name） HOKUTO DENSHI CO;LTD; FLASH2 株式会社...

  • Page 16: Dealing With Errors

    Note 2: In the same situation of the target board, cables and PC, if FLASH2 often have error #6 but sometimes success, we recommend to examine the status of supplied power voltage, or miss-arrangement of required MCU port. See the User’s Guide of the arrangement about the proper reference circuit diagrams for the target board.

  • Page 17: Led Status Of Flash2 And Trouble Shootings

    FLASH2 output. No answer from the target MCU. In spite of the correct communications from FLASH2, the target MCU makes no reply. Check the circuit around the MCU in writing, especially the port MD/FWE/RESET and SCI port are controlled correctly. Sometimes, Xtal oscillation failures influence in transferring.

  • Page 18: Timing Chart Of Boot Mode Control

    MCU. If this error rate is more than above recommended 0.16%, the rate can’t be raised at the target program transfer. FLASH2 can control the target MCU into boot mode in programming procedure. For this automatic control function, the user’s interface must be organized for the connections to MCU ports that specified in Renesas Electronics hardware manual for the concerned MCU.

  • Page 19: Correspondence Mcu

    *Upgrading compatible to 3v and R8C/M16C MCU series are included in this upgrade. Upgrading Control Software information Only upgrading the control software, FLASH2 can adapt to every new MCU of Flash memory MCU Microcomputers. For the series of single power supply, we present the new version for all Flash memory MCU Microcomputers releasing one after another.
