hepco & becker Sportrack 670403 00 01 Manual

Yamaha fz 1 fazer ab baujahr 2006 / from date of manufacture 2006

Advertisement

YAMAHA FZ 1 Fazer
ab Baujahr 2006 / from date of manufacture 2006
Artikel Nr.: / Item-no.:
670403 00 01
schwarz/black
INHALT

CONTENTS

1
700007887 Gepäckplatte
1
700007888 Hakenplatte
1
700007889 Schlossplatte
4
Senkkopfschrauben M6 x 20
4
selbstsichernde Muttern M6
4
Verschlußstopfen ø8 mm
4
U-Scheiben ø6,4
1
Logo Hepco & Becker ø30mm
1
Dichtband 20x40 - Länge 120 cm
VORBEREITUNG

PREPARING

Soziussitzbank abnehmen. Dismantle passenger seat.
WICHTIG
IMPORTANT
Die Voraussetzung für die Montage ist natürlich eine gewisse technische Erfahrung. Wenn Sie sich nicht sicher sind, wie man eine
bestimmte Arbeit ausführt, sollten Sie diese Ihrer Fachwerkstatt überlassen. Ziehen sie alle zugänglichen Schrauben zuerst nur locker
an. Nachdem alles montiert ist, werden die Schrauben dann auf das entsprechende Anzugsmoment festgezogen. Dadurch wird
sichergestellt, dass das Produkt spannungsfrei angebaut ist. Anzugsmomente beachten! Nach der Montage alle Verschraubungen
auf festen Sitz kontrollieren!
Of course, the assembly requires a certain technical experience. If you are not sure how to execute a determined action, you should
ask your local distributor to do it. First, tighten all screws only loosely. After mounting all parts, the screws should be tightened to
the torque specified. This guarantees, that the product is mounted without tension. Observe the tightening torques of the manufacturer!
Control all screw connections after the assembling for tightness!
Weiteres Zubehör auf unsere Homepage. More accessories: see our homepage.
Hepco & Becker GmbH
An der Steinmauer 6
D-66955 Pirmasens
Germany
1
700007887 sportrack plate
1
700007888 holding plate
1
700007889 lid plate
4
countersunk head screw M6 x 20
4
self lock nuts M6
4
plastic plug Ø8 mm
4
washer ø6,4
1
emblem Hepco & Becker ø30mm
1
Seal strip 20x 40 mm - lenght 120 cm
Tel.:
Fax:
eMail: vertrieb@hepco-becker.de
www.hepco-becker.de
BENÖTIGTE WERKZEUGE

TOOLS REQUIRED

Inbusschlüssel / allen key
Größe/Size 4
Schraubenschlüssel / wrench
Größe/Size 10
+49 (0)6331 - 1453 - 100
+49 (0)6331 - 1453 - 120
