PIPE(TUBE) CUTTER Of Best Technology

Manual

(

)

-100LT /

-150LT /

-200LT

SAFETY PRECAUTIONS

Thanks for choosing the S-Cutter.

Make sure that you carefully read and fully understand the Manual to use the device correctly

and keep yourself and your properties safe.

Table of Contents

Need help?

Do you have a question about the S LT Series and is the answer not in the manual?

Questions and answers

Summary of Contents for DCSENG S LT Series

Page 1 PIPE(TUBE) CUTTER Of Best Technology Manual -100LT / -150LT / -200LT SAFETY PRECAUTIONS Thanks for choosing the S-Cutter. Make sure that you carefully read and fully understand the Manual to use the device correctly and keep yourself and your properties safe.
Page 2 PIPE(TUBE) CUTTER Of Best Technology CONTENTS 1. SAFETY PRECAUTIONS 2. Must-Follow Rules 3. Instruction Before Use 4. How to Use S-LT Series 5. Quality Warranty...
Page 3 SAFETY PRECAUTIONS Keep workplace clean and well-lit at all times. An untidy or dark workplace may cause accidents. Consider your work environment. Do not let it wet. Do not use in humid place. Install bright lighting in the work place. Do not use the machine near the flammable liquids or gases.
Page 4 PIPE(TUBE) CUTTER Of Best Technology Do NOT abuse the cord. Do not drag the product by pulling the electric cord. Do not unplug the cable by pulling the cord itself. Keep the cord safe from heat, oil and sharp edges. Secure the workpiece.
Page 5 Be cautious all the time. Observe work process and process accordingly. Do not use this product if the concentration is blurred, Do not operate by force the cutting speed and rotational speed. Make sure that there is no damage on the product. Check the safety device and examine thoroughly that the mildly damaged parts now function normally before resuming the use of the tool.
Page 6: Must-Follow Rules
PIPE(TUBE) CUTTER Of Best Technology Must-Follow Rules The instructions in this user manual contains information that is important to the safe use of this product. Not following these instructions can cause death, serious injury, and massive property damage. For safety, the instructions are divided into ‘WARNING’ and ‘CAUTION’ depending on degree of risk, and the details are as follows: Symbol Description...
Page 7 WARNING ● Make sure the power is connected to the ground. Leakage current due to electric shock may occur if the product is not connected to the grounding. ● Do NOT pour water or cutting fluid. Due to water or other liquids on the electric motor, electric shock, or death may occur. Use cutting fluid until tools are slightly wet.
Page 8: Instruction Before Use
PIPE(TUBE) CUTTER Of Best Technology Instruction Before Use 1. Check the electric leakage breaker Make sure the system is powered on the circuit breaker is installed. Check if an electric leakage breaker(ELB) with rated capacity is installed in all electric units. Make sure that the ground wire is connected to the powered system.
Page 9 100LT / 150LT / 200LT The most cost-effective orbital cutting machine! The world best convenience and work speed! Equipment capacity : 1/4 – 8inch (Pipe O.D 6mm - 220mm) S-Cutter...
Page 10: Table Of Contents
PIPE(TUBE) CUTTER Of Best Technology How to Use S-LT Series How to use S-LT Series Instructions before use Please read about how to use manual provided by the headquarter or suppliers. Users must be educated before use. Make sure to remove the power when changing the cutting or beveling blade. Be sure to use consumables(such as cutting and beveling blades) for this equipment that are provided by us.
Page 11: Name Of The Parts And Controls
1. Name of the parts and controls ● Name of the parts Name Description Machine Pipe cutting and beveling machine S-LT Series_MT Machine table S-LT Series_RS Pipe transfer device S-LT Series_VS Long-pipe support and transfer device(adjustable) Fixing lever Positioning bolt according to the diameter Toolbox Box for storing tools S-Cutter...
Page 12 PIPE(TUBE) CUTTER Of Best Technology ● Name of the function parts Name Name Vise jaw Cutting handle gear box Vise handle Cutting head fixing nut Cutting head Folding bracket Cutting motor Rotating handle lock Motor control part Beveling stopper Cutting handling Rotating handle Cutting handle fixing hole Rotating oil nipple...
Page 13: Mounting Of The Cutting And Beveling Blade
2. Mounting of the cutting and beveling blade Right-side nut Washer Cutting blade Washer Left-side nut ① To push the cutting head aside, loosen the cutting head fixing nut (A), move it in the arrow direction, hold the head with hand, and turn it in the folding bracket direction (B).
Page 14 PIPE(TUBE) CUTTER Of Best Technology ● When beveling, mount the beveling blade on the shaft and tighten with the nut(firmly with a 22mm spanner). - Do not use cutting washer For inner side For outer side 2-1. Fixing the brush 1) Fix the stainless brush to be close to the cutting blade and then firmly fixed with a wing bolt (ⓐ) on the outside and a knurled bolt (ⓑ) on the inside as shown in the figure below.
Page 15: Pipe Setting
3. Pipe setting 3-1. S-LT Series_VS : Height adjustment of the Pipe 1) If the pipe is long, extend a vise support device(S-LT Series_VS) mounted at the back of the table with aligning to pipe length as shown in the figure. 2) A standard table(S-LT Series_MT) is applicable to a maximum pipe length of 4m;...
Page 16 PIPE(TUBE) CUTTER Of Best Technology 3-2. S-LT Series_RS : Pipe transfer device 1) S-LT Series_RS, a pipe feeder, is designed to fix a pipe to the machine and then adjust its height(up and down) to bring the urethane into close contact with the bottom of the pipe and turn the handle to feed the pipe forward or backward to situate it to a desired cutting position.
Page 17 2) Align the side of the preset stopper with the line that is marked on a pipe for its cutting position(memory function), as shown in the figure below; and, it must be restored to its original position so it is not interrupted by pipe when it is unused. Default position of the stopper 4-2.
Page 18 PIPE(TUBE) CUTTER Of Best Technology 2) Turn and place the cutting handle in the cutting handle fixing hole, as shown in the left figure, and hold and move the cutting head(motor) up and down while pulling the cutting handle clutch, as shown in the right figure. Cutting handle (pull clutch forward in order to move cutting head down...
Page 19 4-3. How to cut the pipe 1) Separate the cutting handle from the fixing hole making sure that the cutting blade should have an adequate distance from the pipe. 2) Adjust the cutting position of the pipe(refer to Section 4.2) and turn the vise handle to fix it firmly.
Page 20 PIPE(TUBE) CUTTER Of Best Technology 4) Move the rotating handle lock upward to release it, as shown in the figure below, and then turn the rotating handle in the direction as shown in the figure on the right to begin with the cutting work(be noted that the rotating handle turns only to one direction).
Page 21: How To Bevel The Pipe
5. How to bevel the pipe 5-1. How to use stopper for beveling Stopper Cutting handle Beveling blade Stopper Beveling blade 1) Turn the cutting handle downward, as shown in the figure (a) above, and place it in the fixing hole. 2) Turn the stopper bolt left and right while adjusting a pipe to allow the part to be beveled to situate itself at a given section of the beveling blade, as shown in the figure (b) above(Refer to Section 4.2)
Page 22 PIPE(TUBE) CUTTER Of Best Technology 5) Finely tune the stopper according to the result of the temporary beveling work, as shown in the figure, before the stopper is returned to its home position and the work proceeds. * Note) Finely tune it several times until a desired beveling result is obtained. Beveling Beveling amount decrease amount increase...
Page 23: How To Use The Handle Clutch
6. How to use the handle clutch 6-1. How to use the handle clutch 1) The handle clutch is used when the cutting(beveling) blade mounted on the cutting head needs fine tuning(entry or retraction). 2) When the handle clutch is settled in its fixing hole, the fine scale marked on the handle clutch is matched the standard scale of the cutting handle gear box.
Page 24: Adjustment Of The Cutting And Rotating Speed
PIPE(TUBE) CUTTER Of Best Technology 7. Adjustment of the cutting and rotating speed Cutting speed adjustment Step Work Pipes used Special mode Aluminum, PVC, Titanium, Inconel, Duplex, etc Cutting Stainless steel, Carbon steel, etc All kinds of pipes made of materials Beveling mentioned above Rotating speed adjustment...
Page 25 C. Check the handling of the major operation part ⦁ Supply grease oil regularly on the side of rotation gearbox and main gearbox. - Inside gears of rotation gearbox can wear out and must be replaced regularly. ⦁ Check and supply indicated(synthetic gasoline engine oil) in the upper surface of cutting gearbox.
Page 26: Product Specifications
PIPE(TUBE) CUTTER Of Best Technology 10. Product specifications ● Machine Specifications Item Unit Specification Min./Max. O.D note 1) mm (inch) 6 (1/4) / 120 (4) Cutting / Beveling Min./Max. Thickness note 2) 0.2 / 8.2 Capacity Beveling Angle ° 30/32/35/37.5/40/45 Size(D×L×H) 143 x 366 x 383 Machine...
Page 27 ● Motor Specification Items Unit Cutting motor Rated output 1000 Rated voltage AC 200 – 220V / 50 - 60Hz Rated current Operating -20℃ - 40℃ / 20 - 80%RH Environment ● Standard Accessory All-in-one tool box : Standard accessory ●...
Page 28 □ S-100LT □ S-150LT □ S-200LT...
Page 29 PIPE(TUBE) CUTTER Of Best Technology DCSENG CO., LTD. 23-22, Jukjeon-3gil, Hyeondo-myeon, Seowon-gu, Cheongju-si, Chungcheongbuk-do, 28214, Republic of Korea T +82-43-256-0945 F +82-43-256-0946 W www.dcseng.co.kr www.s-cutter.co.kr...
