Universal Explore home 987922 Instruction Sheet

987/988 922-923-968-969
Thank you for purchasing this quality product. Be sure to check all packing material carefully for small
parts that may have come loose inside the carton during shipment.
Caution: (1) These parts are cumbersome and heavy. This product can best be assembled with the
assistance of one or more persons in order to prevent personal injury and to insure parts are not damaged
during the assembly process. If dirty, clean finished parts with mild dishwashing liquid and water solution
applied on damp cloth. Cloth should not be excessively wet. Polish finish with soft cloth and an industry
recognized furniture polish.
(2) To prevent damage to your floor or carpet, please check the bottom of each piece of furniture for
stain residue and rough surfaces and also check for staples or nails left after removing the packaging material.
The manufacturer will not be held responsible if preventative steps are not taken prior to installation.
(3) Unpack and dispose of all packing material but be careful not to throw away any assembly parts or
hardware. Read the instruction sheet and parts list carefully. Remove all staples and screws used for
packaging carefully using pliers and or screwdrivers to prevent injury and scratching or damaging flooring.
(4) During normal use every day, screws, bolts, nuts and wooden plugs may loosen up. They should be
periodically inspected and re-tightened to prevent damage to the furniture and (or) personal property or cause
injury. Always check to be sure all hardware on this list and the above mentioned components is attached to
the furniture properly and kept tightened at all times.

PARTS LIST:

# Description
A Hutch -969
C Left Pier - 923
E Side panels
G Top frame unit
I Upper strips
K Hardware pack
M Hardware pack
Note: The tipping restraint kits are located on the back of left bookcase pier (C) and right bookcase
pier (B). Always use tipping restraint kits for safety.

Assembly Procedure

Step 1: Unpack, inspect, and read assembly instruction carefully. Lay out the parts and hardware. Make sure
the quantity of each is correct.
Step 2: Disregard this step when the hutch (A) is not in use. Connect the two middle back panels (F) with the
screws (5) by a phillips head screwdriver (not provided). Then attach the side panels (E) to the
assembled middle back panel (F) with allen head bolts (2) and allen wrench (4) from hardware pack
(K), attach the top frame unit (G) to the base of hutch with allen head bolts (1) and allen wrench (4)
as shown, attach the sliding doors (H) to the top frame unit (G). Secure the back rail with allen head
bolts (3) by allen wrench (4) as shown. Tighten all bolts with allen wrench (4). Now the hutch (A) is
assembled.
Step 3: Disregard this step when left pier (C) and right pier (D) are in use. Attach the upper strips (I) to
entertainment console (B) by hand. Attach the bottom strips (J) to console (B) with phillip head
bolts(1), lock washers (2) and flat washers (3) by wrench (4) from hardware pack (L). Disregard the
following steps when the piers (C&D) and hutch (A) are not in use.
Step 4: Put the entertainment hutch (A) on the entertainment console (B) as shown. Secure them with
mending plates (1) and screws (2) from hardware pack (M) by a phillips head screwdriver (Not
provided). Disregard the following steps when the piers (C&D) are not in use.
INSTRUCTION SHEET
Qty. #
1pc B
1pc D
2pcs F
1pc H
2pcs J
1bag L
1bag
: (Please follow the sketches below.)
Page 1 of 4
Entertainment Wall System
Description
Entertainment console - 968
Right Pier -922
Middle back panels
Top sliding doors
Bottom strips
Hardware pack
Qty.
1pc
1pc
2pcs
2pcs
2pcs
1bag
