Bugflector
For proper installation and best possible fit, please read all instructions BEFORE you begin.
For technical assistance or to obtain missing parts, please call Customer Relations at 1-800-241-7219.
Important Safety Information
• CAUTION - Before driving, ensure that the hood shield is properly anchored to vehicle.
• Do not use automatic "brush-style" car washes.
• Do not use cleaning solvents of any kind.
• Periodically check all components for tightness.
Contents
NOTE: Actual product may vary from illustration.
Screw x4
Tools Required
Car Wash Supplies
Preparation Before Painting / Installation
• A trial fit is recommended to ensure proper positioning and fit.
• Check fit of parts before painting as we will not accept the return of modified or painted parts.
• Wash your vehicle's hood to remove any debris and/or dirt.
• Dry the hood with a clean towel.
Installation Instructions
- Bugflector II
®
Hood shield
Washer x4
Clean Towel
Page 1 of 3
I - Sheet Number BF45 Rev.A
- Carflector
®
Well Nut x4
Bump On x4
Phillips head screwdriver
™
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for AVS Bugflector
Summary of Contents for AVS Bugflector
- Page 1 Installation Instructions I - Sheet Number BF45 Rev.A Bugflector - Bugflector II - Carflector ® ® ™ For proper installation and best possible fit, please read all instructions BEFORE you begin. For technical assistance or to obtain missing parts, please call Customer Relations at 1-800-241-7219. Important Safety Information •...
-
Page 2: Installation Steps
Installation Steps NOTE: Actual application may vary slightly from illustrations. Assemble fasteners by inserting screw through Open Hood. Remove (2) bumpers before installation. hood shield and into well nut. Hand tighten. Well nut Hood shield Washer Center part on front edge of hood and With well nut inserted into hole in hood, secure align holes hood shield to hood by tightening screw to... - Page 3 655 Raco Drive, Lawrenceville, GA 30045 800-241-7219 • Fax 770-339-5839 • Visit us at lundinternational.com © 2004 Lund International, Inc. All rights reserved. ™ Auto Ventshade , the Auto Ventshade logo and the AVS logo are trademarks of Lund International, Inc. Page 3 of 3...
-
Page 4: Instructions D'installation
Instructions d’installation I – Feuille numéro BF45 Rév.A Bugflector - Bugflector II - Carflector ® ® ™ Pour obtenir une installation correcte et le meilleur ajustement possible, lire toutes les instructions AVANT de commencer. Pour toute assistance technique ou obtention de pièces manquantes, appeler le service des relations avec la clientèle au 1-800-241-7219. -
Page 5: Étapes D'installation
Étapes d’installation REMARQUE : La méthode d’application peut être légèrement différente de celle représentée par les illustrations. Ouvrir le capot. Enlez (2) les butoirs avant installation. Assembler les fixations en passant la vis dans le trou du capot et en la vissant dans l’écrou Well-Nut. Serrer à... - Page 6 800-241-7219 • Fax 770-339-5839 • Visitez notre site lundinternational.com © 2004 Lund International, Inc. Tous droits réservés. ™ Auto Ventshade , le logo Auto Ventshade et le logo AVS sont des marques déposées de Lund International, Inc. Page 3 de 3...
-
Page 7: Instrucciones De Instalación
Instrucciones de instalación Hoja informativa N.° BF45 Rev.A Bugflector - Bugflector II - Carflector ® ® ™ Para una instalación adecuada y el mejor ajuste posible, lea todas las instrucciones ANTES de comenzar. Si desea recibir asistencia técnica u obtener piezas faltantes, llame al Servicio al cliente al 1-800-241-7219. Información importante de seguridad •... -
Page 8: Pasos De Instalación
Pasos de instalación AVISO: La colocación real puede variar con respecto a las ilustraciones. Abra el capó. Quite (2) los topes antes de la instalacion. Instale los sujetadores insertando un tornillo a través de la cubierta para capó y dentro de la tuerca hueca. Apriete con la mano. - Page 9 800-241-7219 • Fax 770-339-5839 • Visite nuestro sitio Web: lundinternational.com © 2004 Lund International, Inc. Todos los derechos reservados. ™ Auto Ventshade , el logo de Auto Ventshade y el logo de AVS son marcas comerciales de Lund International, Inc. Página 3 de 3...
